- Page 1 S i g N E T 2 0 0 / 3 0 0 S e r i e s U s e r G u i d e E L A B 1 5 4 3...
- Page 2 Further Europlex reserve the right to revise this publication and to make changes from time to time in the contents hereof without the obligation of Europlex to notify any person of any such revision.
-
Page 3: Table Of Contents
SigNET 200/300 User Guide Table of Contents INTRODUCING THE SIGNET 200/300 SYSTEM ......................4 USING THE KEYPAD .................................4 ............................5 SING THE EYPAD NTERFACE SETTING, UNSETTING, AND RESTORING THE SYSTEM..................6 : FULLSET ...........................6 ETTING THE YSTEM : PARTSET A..........................6 ETTING THE YSTEM : PARTSET B..........................6 ETTING THE YSTEM... -
Page 4: Introducing The Signet 200/300 System
SigNET 200/300 User Guide 1. Introducing the SigNET 200/300 System The SigNET 200/300 system must be installed by a qualified installation engineer. When the installation has been completed, the engineer provides users with passwords to set or unset and configure the system as required. 2. -
Page 5: Using The Keypad Interface
SigNET 200/300 User Guide Using the Keypad Interface Figure 2 – Keypad Interface TOP LINE OF DISPLAY BOTTOM LINE OF DISPLAY In the normal state, displays the current date and time. In the normal state, this line is blank. In Programming Mode, this line displays options available In Programming Mode, this line displays one of the following: to the user. -
Page 6: Setting, Unsetting, And Restoring The System
SigNET 200/300 User Guide 3. Setting, Unsetting, and Restoring the System The following functions are available to users by entering a user code; these …FULLSET?... functions do not require menu navigation on the Keypad. User codes comprise 4, 5, or 6 digits, depending upon the programming grade of the EXIT SELECT system. -
Page 7: Failing To Set The System
SigNET 200/300 User Guide Failing to Set the System The system fails to set if there is an open or fault condition detected on an alarm zone when the FULLSET or PARTSET A/B option is selected. The Keypad displays the zone number and description. -
Page 8: Coded Restore
SigNET 200/300 User Guide 3. Press the right menu key to restore the alert. The message ALL ALERTS RESTORED displays and the flashing Alert LED turns off. For system or communications type alert conditions (Mains failure or E-BUS disconnect), locate the source of the alert condition and check that all wires and cables are properly connected. -
Page 9: Using X10 Features
SigNET 200/300 User Guide If Manager and/or Standard Users’ profiles are configured for such device and functionality, access to keypad is allowed using the PACE. Presentation of the device within 1cm of the Keypad’s receiver area logs in the user and prompts menu options. For additional security measures, engineers have the option to set the PACE configurations to PIN and PACE. -
Page 10: User Menu Options
SigNET 200/300 User Guide 4. User Menu Options The following functions are available to users under MENUS on the Keypad. In navigation mode following input of user code, the user selects one of a number of pre-defined programming options from a list. Pressing the up/down arrow keys scrolls the list of options available for selection. An ellipsis (…) on accompanying graphics denotes when there is a choice of menu selection by scrolling. -
Page 11: Perform Tests
SigNET 200/300 User Guide Perform Tests …TEST… Tests can be performed on the system to determine if bells, buzzers, and other EXIT SELECT audible devices operate correctly. To perform a test on the system: 1. Scroll to the TEST option and press SELECT (right soft key). …BELL TEST…... -
Page 12: Changing A User Code
SigNET 200/300 User Guide Changing a User Code If users have the right to change their user code, this can be done through the …CHANGE CODE… Keypad. EXIT SELECT Note, if the system is set for 5-digit user codes, a new 5-digit code must be entered. The system will not accept a code with fewer numbers than it is set to receive. -
Page 13: Sms Control
SigNET 200/300 User Guide …SMS EVENTS… Enable phone number for SMS [receipt] within SMS Events menu: EXIT SELECT 1. Scroll to the SMS EVENTS option and press SELECT. 2. Select EDIT. …EDIT… 3. Using the up/down arrow keys, scroll to the appropriate registered number EXIT SELECT and press SELECT. -
Page 14: Sms Commands
SigNET 200/300 User Guide 4.9.3 SMS Commands Once the SMS setup and configuration is complete, SMS features may be activated. Commands, depending on SMS configuration are sent using a code or caller ID. The type of code depends on the system SMS Authentication. -
Page 15: Allowing Engineer/Manufacturer Access
SigNET 200/300 User Guide Additional commands are available for X-10 functionality from the qualified installation Engineer if the system is configured for such use. Note 4.10 Allowing Engineer/Manufacturer Access When engineer or manufacturer access has been allowed, the Keypad displays …GRANT ACCESS…... -
Page 16: Appendix A: Standard User Settings
SigNET 200/300 User Guide Appendix A: Standard User Settings The operational features of the SigNET 200/300 system are described below. The installation engineer informs users of their user rights assigned to each user profile. Depending on how the system has been programmed, users may have rights to all or some of these features. -
Page 17: Appendix B: User Configuration And Test Options
SigNET 200/300 User Guide Appendix B: User Configuration and Test Options User Profile Operation Description Default ISOLATE Manager Isolating a zone deactivates that zone until such time as the zone is de-isolated again. All zone types on the SigNET 200/300 can be isolated. Use of this feature to deactivate faulty or open zones should be considered carefully;... -
Page 18: Appendix C: Zone Chart
SigNET 200/300 User Guide Appendix C: Zone Chart Zone # Description ELAB 1543...
