- Page 1 Bischoff & Bischoff Instruction manual Rollator RL-smart Enjoy mobility.
-
Page 2: Table Of Contents
Contents 1| Declaration of Conformity 2| Indications / Contra-indications 3| Safety instructions 4| Unfolding 5| Folding up 6| Installing the functional bag 7| Adjusting the handles 8| Brake application and adjustment 9| Wheels and tyres 10| Technical data 11| Storage/shipping 12| Re-use 13| Repairs 14| Disposal... -
Page 3: Declaration Of Conformity
Rollator RL-smart Rollator RL-smart walking aid) Dear customer, by purchasing this B+B wheeled walker you have a first-class German product that has been proven and tested thousands of times in professional use. This instruction manual shall make you more familiar with the operation and handling, and thus enable safer use of your B+B wheeled walker. -
Page 4: Safety Instructions
Running wheel Fig. 1 3. Safety instructions • Max. capacity Rollator RL-smart 136 kg • Please note there is a danger of trapping fingers and/or clothing when folding and unfolding. Do not catch any clothing or body parts between the moving parts. -
Page 5: Unfolding
Rollator RL-smart 4. Unfolding Position the B+B Rollator in front of you in the direction of travel. • Apply the parking brakes. • To unfold the rollator, push the frame of the sit downwards (Fig. 2). Make sure that the frame is laid out correctly and that it clicks into place. -
Page 6: Brake Application And Adjustment
• Now insert the handles so they are at the height of your wrists. • Secure the screw and tighten the nut. • Repeat the process for the other side. Make sure that both handles are at the same height. 8. -
Page 7: Wheels And Tyres
9. Wheels and tyres Your rollator is fitted with puncture resistant PU wheels with sizes 190 x 43 mm at the front and 170 x 43 mm at the back. 10. Technical data Type: Rollator RL-smart 4026 platin Colour: 4027 metallic blue Height:... -
Page 8: Storage/Shipping
11. Storage/shipping In the event that the rollator will be stored or shipped, it is advised to keep the original packaging to store in it for this purpose, so that it is on hand if necessary. Then your rollator can be optimally protected against environmental influences during storage or transport. -
Page 9: Disposal
Bischoff & Bi- schoff instruction manual As of 13.01.2011 Just as with all technical products, the Rollator RL-smart should also undergo regular checking or maintenance by authorised specialists. First and foremost, these tests should guarantee the safety of the users. In addition, through regular care of the product, faultless operation should also be guaranteed after extended use. - Page 10 a) Care instructions Cleaning can be carried out with warm water and with the aid of a sponge. With more stubborn dirt, a commercially available cleaning agent can be added to the water. Note: Under no circumstances should aggressive cleaning pro- ducts, such as solvents / abrasives or hard brushes be used.
- Page 11 Rollator RL-smart Cleaning plan and risk assess- ment of B+B medical products before treatment. 1. Product walking aid 2. Risk classification Uncritical medical device Medical device, which only comes into contact with intact skin 3. Frequency of cleaning At the latest, after every change of user 4.
- Page 12 Maintenance table When What Before each use Performance test of the braking system Press the brakes to a stop. In normal use, when the brakes are applied, the wheels must no longer rotate. Wear test of the pressure brake Move the brake lever sideways. Secure locking of all screws.
- Page 13 Rollator RL-smart Please note Carrying out of the test by the user or an assistant. In the event of faulty brakes, repairs should be carried out by an authorised specialist workshop. Carrying out of the test by the user or an assistant. In the event of large slackness of the braking lever, the brake re- pair should be carried out by an authorised specialist workshop.
-
Page 14: Warranty Certificate
16. Warranty certificate Guarantees refer to all faults of the product that are attri- buted to material of manufacturing faults. In the event of complaints, the complete, filled in warranty certificate shall be submitted. For the rollator, we assume a warranty of 5 years. For all attachment parts, we assume a warranty of 1 year. - Page 15 Rollator RL-smart Warranty section (General terms and conditions apply) Type: B+B Rollator RL-smart Serial number: (To be filled out by the specialist supplier) Specialist supplier: Date and stamp Bischoff & Bischoff GmbH • As of 27.09.2011...
- Page 16 Bischoff & Bischoff GmbH Becker-Göring-Straße 13 • D-76307 Karlsbad Tel.: +49 700/60000 7070 • Fax: +49 700/60000 8080 www.bischoff-bischoff.com info@bischoff-bischoff.de...
