Page 1 CC 9060 Time Index Introductory information 1. General 2. Security guidelines Installation of the hands-free car kit 3. Scope of supply 4. Positioning and mounting 5. Connections on the electronics box 6. Installation of the loudspeaker switch box AC 5120 Operating guidelines 7.
Page 2: Introductory Information
Introductory information 1. General Dear customer, Congratulations on purchasing a BURY hands-free car kit. You have chosen a high quality product that is extremely easy to use. Please read the operating manual carefully so that you can fully enjoy your BURY hands-free car kit. If you have any further questions concerning installation or operation of your car kit, please contact your dealer.
Page 3 Intended use We shall not be liable for damages or malfunctions due to improper use of the hands-free system. Therefore, do not expose the device to mois- ture, extreme temperatures or shocks and carefully follow the proce- dure described in the installation and operating guidelines. Use while driving Operate the system only when the situation allows it and when you do not endanger, harm, constrain, or annoy other road users.
Page 4: Installation Of The Hands-Free Car Kit
Installation of the hands-free car kit 3. Scope of supply 150 cm 150 cm...
Page 5 The hands-free car kit (HFCK) is supplied with different combinations of components, depending on the sales regions (countries). The operating manual refers to all versions. Description of the components: 1) Electronics box 2) Monitor, holder and installation pad 3) Mounting accessories Fixing screws for electronics box, rider, screws for the holder and rubber cover, cleaning cloth 4) Microphone 5) Installation and Operating manual, software on DVD, printed Quick user guide...
Page 6: Positioning And Mounting
Installation of the hands-free car kit 4. Positioning and mounting Step 1: First of all, please choose the most convenient position for the attached monitor on the holder and the installation pad in your vehicle by check- ing different positions in the vehicle. If you would like to use the device during your journey, positioning it in the front area on the driver’s side is advisable.
Page 7 After having found a suitable position for the monitor in the vehicle you can mount / attach the the installation pad / the holder accordingly. Please use a cleaning cloth for degreasing the surfaces you want to attach the installation pad to. The end of the cable with the small Molex plug is ideally suited for placing through small openings in the dashboard area.
Page 8 Installation of the hands-free car kit Step 2: Depending on the vehicle type and its equipment (e.g. airbags), it is reasonable to install the micro- phone either at the A-pillar, at the sun shield or at the roof interior. For details about the equipment features please refer to the vehicle documents.
Page 9: Connections On The Electronics Box
The additional components of the hands-free car kit are connected to the electronics box. The follow- ing connections are provided: Connection options: Power supply / Mute basePlate System 9 adapted for CC 9060 Time Internal loudspeaker switch box (with or without an internal switch box, depending on version) External loudspeaker Mikrophone...
Page 10 If you hear two clicking noises, the clamp snapped in properly. Now insert one of the fuses and then repeat the procedure with the other cables. Connection 2 - for System 9 basePlate compatible with the CC 9060 Time This is where you connect the basePlate for the System 9. This basePlate is specially adapted for the electronics box of the HFCK.
Page 11 Connection 3 - Internal loudspeaker switch box The cable provided serves the purpose of transferring the voice output to one of the loudspeakers in the car. In the best case scenario, this speaker should be on the passenger side of the vehicle in order to pro- vide sufficient distance from the microphone and to prevent possible echoes from occurring.
Page 12 Installation of the hands-free car kit 4 - Voice output of the hands-free car kit Version 1: Refer to separate chapter: Installation of the audio switch box AC 5120 Version 2: Connect the external loudspeaker here if you do not want to or are not able to make use of the vehicle’s own sound system.
Page 13: Installation Of The Loudspeaker Switch Box Ac 5120
6. Installation of the loudspeaker switch box AC 5120 With the AC 5120 speaker switch box, you get the possibility of being able to mute the feedback of your car radio / CD player etc. and to transfer the voice output of your conversation partner during a tele- phone call to your vehicle’s speakers.
Page 14 Installation of the hands-free car kit Now disconnect the (a) and/or the (b) loudspeaker connector from the speaker socket on the radio at the back. Connect this connector with the suitable socket (3) on the AC 5120. Now con- nect the plug (4) with the radio. Depending on the switcher position (5), the voice of your conversation partner will be fed back through either the front right speaker, the front left speaker, or through both of the front loud- speakers.
Page 15 Different connections of the ISO plug on the radio The layout of the pins on the ISO plug used in a car depends on the type of car. Before using the switch box, you should make sure that the connections are correct in order to prevent possible damage to the device.
Page 16 Installation of the hands-free car kit In the operating manual of the radio device, you can find the pin assignment for the “mute” signal. This signal can occur on one of three cables marked with “mute1”, “mute2”, or “mute3”. mute 1 mute (yellow) mute 2 radio device...
Page 17: Using The Hands-Free Car Kit For The First Time
Operating guidelines 7. Using the hands-free car kit for the first time After power supply of the hands free car kit (HFCK) is sucessful con- nected, the HFCK is activated when you have started the vehicle. After this, you have to select the menu language if several are available for you to select.
Page 18: Handling Possibilities
Operating guidelines 8. Handling possibilities The system can be operated in two ways: 1. Operation using voice control The „VOICE COMMANDS“ are high- Voice dial lighted in the further explanatory notes. commands 2. Handling via the touch screen Touch screen 9.
Page 19 In addition to these commands, the HFCK recognises the numbers from zero to nine. Numbers which are larger than nine must be spoken individually (e.g. 10 = one, zero). To search in the phone book, the HFCK recognises the letters „A“ to „Z“ as well as the NATO alphabet. For the entry of telephone numbers abroad, the command „PLUS“...
Page 20: Handling Via Touch Screen
Operating guidelines 10. Handling via Touch screen The functions of the HFCK can also be called via the touchscreen. Every available command is pre- sented as text (sometimes with supporting graphics) on the display. The operation can be carried out via possibly existing arrow keys. With the red symbols you can cancel an action or go a step back.
Page 21: Establishing A Bluetooth Connection
11. Establishing a Bluetooth connection If you wish to establish a Bluetooth connection between your mobile and the HFCK for the first time, you have to activate the Bluetooth function of your mobile phone and search for Bluetooth devices. In this case, search for a device labelled „CC 9060...“.
Page 22: Menu Navigation
Operating guidelines In addition it is possible that you must delete all devices connected to your mobile phone first in order to enable a correct identification of the HFCK and the establishment of a connection. If you have que- ries regarding the menu navigation, functions and operation of your mobile phone, please refer to the operating guidelines of your mobile phone.
Page 23: Dial Joe Bloggs
If the voice control function is active then the corresponding menu ap- pears in the display, or the details of the particular function that has been activated. In the following the individual menu points will be ex- plained. Dial Joe Bloggs With this voice command (is not shown on the display) you can immedi- Dial Joe Bloggs ately call a contact from your telephone book with active voice control.
Page 24: Dial Number
Operating guidelines Dial number Dial number It makes sense to divide telephone numbers in short number blocks of 3-4 digits and to say them this way. At each break, the HFCK repeats the number block and waits for the next number block. After the signal tone you can respectively continue your announcement.
Page 25 <Joe Bloggs> is a placeholder for an entry from your phonebook. Dial Joe Bloggs If you select a name, you go directly to the respective entry. Note: Depending on the type of mobile phone, it is possible that the order of the first names and surnames may have swapped around after the telephone book has been trans- ferred.
Page 26 Operating guidelines If your contacts are stored in the telephone’s memory, then depending Dial home on the type of mobile phone, you can allocate four or more telephone numbers to a single contact. The terms are not standard and may have different designations depending on the manufacturer of the mobile Dial mobile phone, or can be set by you yourself*:...
Page 27: Call Lists
In addition you can allocate a phonebook entry with an own voice com- Voicetag mand (voice tag). This is recommended for names which are difficult to pronounce. In these instances, the use of nicknames or abbreviations is recommended. Store Clearly speak the command into the microphone, the HFCK repeats this Delete and you can then make a call to the desired discussion partner from the head menu with e.g.
Page 28 Operating guidelines Music Music If your mobile telephone possesses the Bluetooth profile A2DP, you can play music (e.g. MP3 files) in stereo quality via the HFCK. Note: A corresponding adaptor cable needs to be connected to the A2DP connection on the HFCK and to the radio. This is available from specialist retailers.
Page 29 The following functions are available for playing and are shown on the display: |   Back (title by title) |  Skip (title by title) Pause Play Stop  Via the loudspeaker symbol, you reach the plus and minus button for controlling the volume.
Page 30 Operating guidelines The name of the sender is shown in the upper line and underneath this, the date and time of when the message was received by your mobile phone. With emails, the subject line is separated from the message text. If the All messages message is read out, the HFCK automatically turns to the next page if the end of the page has been reached.
Page 31 Please note: This menu item can only be deactivated if no mobile tele- A2DP active phone is connected with the HFCK. Under the Phones entry you can find the sub-points Phone list, Clear list, Pin code, Auto connect and Multipoint. Phones In the Phone list, the telephones are listed which have already been successfully connected with the HFCK via Bluetooth .
Page 32 Operating guidelines In the DSP menu item you control the settings for every telephone Disable DSP individually as regards the processing of the audio signals. The HFCK has an integrated digital signal processor (DSP). This serves the func- tions of voice recognition and voice synthesis and is activated as stand- Phone DSP ard.
Page 33 If a call is received by both mobile phones at the same time, preference is given to the primary mobile phone. You will be displayed the incom- ing call on the other mobile after accepting or declining the first call. You are then able to end the first call at short notice and to also decline the second call (pressing to the right of the red receiver both times), or to end the first call and to accept the second call directly (press the...
Page 34: Voice Dial
Operating guidelines Voice dial Voice dial In this submenu you can carry out the following settings: Activation or deactivation of the magic word: Activate voice dial If you activate this function you can start the voice controlled operation of the HFCK straight from the main menu with the pre-set voice com- mand „ACTIVATE VOICE DIAL“.
Page 35 Audio Audio In this area you have the possibility to change the audio settings of the HFCK. The HFCK is sold with four Ringtones from which you can respec- tively select one. With „NEXT“ or „PREVIOUS“ you can navigate in Ringtones the list.
Page 36 Operating guidelines Display Display This menu point makes it possible for you to adjust the display in a range of different ways. In order to avoid the blinding effect especially when driving at night, Sleep mode you can activate the Sleep mode. This causes the display to shut off after either 15, 30 or 60 seconds.
Page 37 Device Device In the Call answering menu item, you can make the settings concerning the answering of calls, the menu languages, the telephone book op- tions, for the system itself, and for the willingness to answer calls. With the Call answering function you can specify as to whether you Call answering want to answer an incoming call manually via the touchscreen, by voice command, or automatically.
Page 38 Operating guidelines You can also import the telephone book manually here once more, Sync phone book if, for example, you saved a new telephone number / contact in your mobile phone during a Bluetooth with the HFCK. If the telephone book on your mobile phone has only been partially loaded, you are able to send the data from your telephone book to the HFCK via the Bluetooth OPProtocol.
Page 39 Using the On-call duty menu item, you are able to activate the HFCK’s On-call duty internal standby switch. When activated for the first time, this is set at 5 minutes. It can be changed to 10 or 15 minutes, however. On-call duty is useful if you stay in your vehicle after reaching your destination or switch the engine off when waiting at level crossing, for instance.
Page 40 Operating guidelines If you activate the speed control you must enter a value stating the speed from which you would like to be warned by the HFCK. Values below 10 are not accepted and values from 10 are automatically raised to the value 20.
Page 41 Memo Memo If you want to make a note of something important either after or dur- ing a trip or maybe during a telephone call, it is often the case that you don’t have anything to write with at hand or the traffic situation pre- vents you from doing so.
Page 42 Operating guidelines As soon as the mobile telephone is deleted from the list of telephones, the private voice memos are also deleted. Examples of private memos are addresses, telephone numbers or inter- net sites which you want to make a note of for later during your journey or during telephone calls.
Page 43: Electronic Driver's Logbook
13. Electronic driver‘s logbook The HFCK possesses a GPS receiver for registering vehicle positions based upon GPS coordinates. Us- ing road map data, these coordinates can then display a specific route along which the vehicle has travelled. This serves the purpose of setting an electronic log book which you can then subsequently edit or supplement with a special PC software (BURY Time Suite) programme.
Page 44 Operating guidelines Advice: Depending on the number of your appointments and contacts visited, it can be advis- able to sort and maintain the data using the management software every week at the latest. Install the BURY Time Suite on a PC or laptop. Follow the instructions during installation. Technical requirements for the administrative programme: Processor: Intel Pentium (or equivalent) with 1.5 GHz Operating system: Microsoft Windows XP with Service Pack 2 or higher, Windows Vista, Windows 7...
Page 45: Accepting, Making, Ending Calls
14. Accepting, making, ending calls You will be alerted of an incoming call via the voice output and the ring tone. Your vehicle‘s sound system will switch onto mute. If the caller sends their telephone number with the call, this will be shown in the display unless the number is saved in your phone.
Page 46: Transferring Calls
Operating guidelines 15. Transferring Calls Transferring calls is to be understood as being the acceptance of a call during a telephone call and alternating between two conversations. Note: Please remember that your range of functions can vary depending on the type of mobile phone. Please find the relevant details in the instructions manual for your mobile phone.
Page 47: Conference Mode
16. Conference Mode The hands-free car kit provides you with the possibility of merging up to seven conversations to create a conference. This means that all participants can talk to each other at the same time. If you receive a further call during an active telephone conversation, you can merge both conversations into a conference.
Page 48: Further Information
Further Information 17. Service In case of general or technical queries, suggestions and comments, please do not hesitate to contact our team at any time. Suggestions and feedback are always welcomed: Administration: Producer: BURY GmbH & Co. KG BURY Spółka z o.o. Robert-Koch-Straße 1-7 ul.
Page 49: Appropriate Use Of This System
18. Appropriate use of this system This hands-free car kit is only intended for use with Bluetooth mobile telephones and music playback systems in motor vehicles. When using this system, please comply with the regulations and laws spe- cific to the country in which you are driving and the instructions provided in the guidebook for the mobile telephone that you are using.
Page 50 Federal Communications Commission (FCC) Compliance Statement - United States This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: 1 This device may not cause harmful interference, and 2 the device must accept any interference received, including interference that may cause undesired operation.
