Hardware Features - Socket Bluetooth GPS Receiver Quick Start Manual

Power Switch
Power ON
Power Jack
The power jack lets you connect to either a DC (included) or AC power
charger to recharge the internal battery. You can either use the included DC
adapter or an iPAQ-compatible AC adapter. Please note that the adapter rating
is 5V, 1A, positive pole center.
External Antenna Port
If you have an external antenna with a male MCX connector (available
separately), you can use it instead of the Bluetooth GPS Receiver's internal
antenna. Simply plug your external antenna into the antenna port.
Bluetooth Status LED (Blue)
Blinking — Bluetooth radio is on and ready to transmit.
GPS Status LED (Green)
Blinking — GPS position is fixed.
Steady light — GPS position not fixed.
Battery Status LED (Red/Yellow)
None — Running on battery power, and battery has adequate power
supply.
Red — Running on battery power, which is critically low. Charge
immediately.
Yellow — Connected to power charger. Battery is only partially full.
LED off — Connected to power charger. Battery is fully charged.
To register your product online, visit:

Hardware Features

Power OFF
www.socketcom.com/prodreg/
