Digital Phone Card™
with GSM Software Modem
CompactFlash Card with attached cable for
connecting GSM phones to:
• Windows Powered Pocket PCs
• Windows CE-based Palm-size PCs, Handheld
PCs, and pen tablets
• Windows 9x/Me/2000/XP notebooks
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital Phone Card and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Socket Digital Phone Card

Summary of Contents for Socket Digital Phone Card

  • Page 1 Digital Phone Card™ with GSM Software Modem CompactFlash Card with attached cable for connecting GSM phones to: • Windows Powered Pocket PCs • Windows CE-based Palm-size PCs, Handheld PCs, and pen tablets • Windows 9x/Me/2000/XP notebooks User’s Guide...
  • Page 2 How this Manual is Organized This manual is designed to help you install and the operate the Socket Digital Phone Card. Chapter 1, Introduction, describes key features of the DPC and identifies package contents. Chapter 2, Preliminary Setup, explains the first several setup steps, which are done the same for all Windows versions.

  • Page 3: Table Of Contents

    Installation Steps Summary CHAPTER 2 PRELIMINARY SETUP STEP 1: Register Your Card STEP 2: Activate Data Service for Your Phone STEP 3: Uninstall Old Socket DPC Software STEP 4: Network Information Form CHAPTER 3 WINDOWS CE SETUP STEP 5: Install the Software...
  • Page 4 APPENDIX C TROUBLESHOOTING APPENDIX D ISP RESOURCES APPENDIX E TECHNICAL SUPPORT LIMITED WARRANTY COPYRIGHT NOTICE REGULATORY COMPLIANCE 2 | TABLE OF CONTENTS...

  • Page 5: Chapter 1 Introduction

    When you use the Digital Phone Card, you don’t need a modem, because your data-capable GSM phone simulates one. You can use the Digital Phone Card with any software program that you use with a regular modem.

  • Page 6: Package Contents

    A Socket Digital Phone Card (CompactFlash card Type I) with permanently attached data cable, customized for specific GSM phones • The Socket Digital Phone Card Installation CD • The Quick Start Guide for Digital Phone Card for Pocket PCs • A registration card Digital Phone Card Installation CD...

  • Page 7: How To Use This User's Guide

    Installation Steps Summary PRELIMINARY SETUP STEP 1: Register your card. STEP 2: Activate data service for your mobile phone. STEP 3: Uninstall old Socket DPC software. STEP 4: Complete the Network Information Form. CHAPTERS 3-4: WINDOWS CE STEP 5: Install the software.

  • Page 8: Chapter 2 Preliminary Setup

    STEP 3: Uninstall Old Socket DPC Software Delete any DPC software you may have previously installed on your mobile computer. See the README on the installation CD for uninstall procedures.

  • Page 9: Step 4: Network Information Form

    STEP 4: Network Information Form Contact your office network administrator or Internet Service Provider (ISP) for the information below. If you plan to use ISP services offered by your mobile phone carrier, contact your carrier. For a text-only form that you can email, go to the Docs folder on the installation CD or visit: www.socketcom.com/pdf/dpcform.txt 1.

  • Page 10: Chapter 3 Windows Ce Setup

    Chapter 3 Windows CE Setup This chapter explains the latter part of DPC setup for these Windows CE-based mobile computers: • Windows CE v3.0: Windows Powered Pocket PC and HPC 2000 • Windows CE v2.11: Palm-size PC, Handheld PC and Handheld PC Pro Before you start the steps in this chapter, be sure to complete the instructions in Chapter 2, “Preliminary Setup.”...

  • Page 11: Step 5: Install The Software

    PC via the mobile computer’s serial or USB connection cable or cradle. 2. Insert the Socket Digital Phone Card Installation CD into the host PC. IF YOUR DEFAULT WEB BROWSER IS INTERNET EXPLORER, you can install either the SETUP.HTM or SETUP.EXE: (a) Click Start then Run on the host PC.
  • Page 12 IF YOUR DEFAULT WEB BROWSER IS NETSCAPE, DO NOT run the SETUP.HTM file on Netscape, because it will not work properly. Instead, choose either of two options: OPTION ONE: RUN SETUP.HTM ON INTERNET EXPLORER (a) In the Internet Explorer screen, click File | Open. (b) In the Open screen, type X:\SETUP.HTM (Replace X with your CD drive letter.) Open screen from Internet Explorer 5.5...

  • Page 13: Step 6: Insert The Card And Attach The Phone

    STEP 6: Insert the Card and Attach the Phone With the mobile computer turned ON, insert the DPC into your mobile computer’s card slot. If using a PC Card slot, insert the card into a CompactFlash-to-PC Card adapter first. Then attach the free end of the cable to your mobile phone.

  • Page 14: Step 7: Set Up Remote Networking

    3. In the Make New Connection screen, enter a name for the connection, such as “GSM Phone.” In the Select a modem field, select the Socket DPC GSM Connection. Make sure the Baud Rate is set to 19200 bps. Make New Connection screen 4.
  • Page 15 Make New Connection screen from a Handheld PC 3. The Make New Dial-Up Connection screen will appear. In the Select a modem menu, select the Socket DPC GSM Connection for your GSM phone. (For example, Ericsson is listed below.) Tap on Configure…...
  • Page 16 5. In Call Options, uncheck Wait for dial tone before dialing. Tap OK. Call Options screen from a Handheld PC 6. In Make New Dial-Up Connection, tap on TCP/IP Settings… 7. In the TCP/IP Settings screen, follow your Network Information Form to enter settings appropriate to your office network or ISP.

  • Page 17: Step 8: Make A Data Call

    Does your phone have enough battery power for your data call? Is the Socket GSM program closed? The Socket GSM program uses the same port needed for remote networking (e.g., making a data call).
  • Page 18 4. (Optional) For convenience, you can check the Save password box, but your password will be saved only after you start the connection. 5. For some mobile computers, you need to modify the dial properties so the mobile computer can dial properly. For instructions, refer to the mobile computer’s user manual.

  • Page 19: Chapter 4: Sms Messaging For Windows Ce | 17

    Chapter 4 SMS Messaging for Windows CE The GSM version of the Digital Phone Card includes software for SMS messaging. Socket’s SMS program includes two folders: the SMS folder and the Phonebook folder. The SMS folder is for creating, modifying, and storing messages, while the Phonebook folder is for creating, modifying, and storing contact information, including information on your phone’s SIM...
  • Page 20 Create a SMS message from the SMS folder 1. Make sure the SMS folder is open. The Phonebook button will be below the icons. If you would like to send a message to someone in your SIM, Phone or other folder, tap on the icon for that folder. Pocket PC Handheld PC 2.
  • Page 21 4. Select the Coding system compatible for your keyboard (e.g., 7 Bit for normal text, 8 Bit for special characters or UCS2 for Chinese characters). Note: The maximum possible length of your message depends on what coding system you use. Normal text messages with 7 Bit coding can hold up to 160 characters (a space counts as a character).
  • Page 22 Create a SMS Message from the Phonebook 1. Make sure the Phonebook is open. Tap on the Phonebook button. 2. Tap on SIM, Phone, or Contacts, wherever you stored the entry you wish to access. 3. In the next screen, select the entry, then tap File | New SMS. You can also use these shortcuts: •...

  • Page 23: Chapter 5 Windows 9X/Me Setup

    Chapter 5 Windows 9x/Me Setup This section covers the latter part of the setup for Windows 9x/Me. For Steps 1-4, refer to Chapter 2, “Preliminary Setup.” STEP 5: Insert the Installation CD Insert the installation CD into the CD drive of your notebook computer. STEP 6: Insert the Card and Attach the Phone 1.

  • Page 24: Step 7: Install The Software

    STEP 7: Install the Software After inserting the DPC, complete these steps for software installation: 1. The first time you insert the DPC, a new hardware or device driver wizard will appear. Add New Hardware Wizard from Windows 98 2. Follow the wizard to install the DPC drivers, inserting the installation CD and making the appropriate selection below as prompted: a.

  • Page 25: Step 8: Set Up Remote Networking

    Windows Me: Go to My Computer | Control Panel | Dial-Up Networking | Make New Connection. 2. In the top field, enter a name for your wireless connection, such as “GSM Phone.” Select Socket GSM Modem from the modem list. Click Next>. Make New Connection screen from Windows 98 3.

  • Page 26: Step 9: Make A Data Call

    Does your phone have enough battery power for your data call? Is the Socket GSM program closed? The Socket GSM program uses the same port needed for remote networking, (e.g., making a data call).
  • Page 27 Ending a Data Call 1. Double-click on the connection icon in the task tray, shown above. 2. In the connection status screen, click Disconnect. The icon will disappear from the task tray, and the mobile phone will hang up. CHAPTER 5: WINDOWS 9x/Me SETUP | 25...

  • Page 28: Chapter 6 Windows 2000/Xp Setup

    Chapter 6 Windows 2000/XP Setup This section covers the latter part of the setup for Windows 2000/XP. For Steps 1-4, refer Chapter 2, “Preliminary Setup.” STEP 5: Insert the Installation CD Insert the installation CD into the CD drive of your notebook computer. STEP 6: Insert the Card and Attach the Phone 1.

  • Page 29: Step 7: Install The Software

    STEP 7: Install the Software After inserting the installation CD and the DPC, complete these steps for software installation: 1. The first time you insert the DPC, a device driver or new hardware wizard will appear. Click Next>. 2. Follow the wizard to install the DPC drivers, making the appropriate selection below as prompted: a.

  • Page 30: Step 8: Set Up Remote Networking

    (a) Windows 2000 — • Network Connection Type: Select Dial-up to the Internet • Select a Device: Select Socket GSM Modem. (b) Windows XP — • Network Connection Type: Select Connect to the Internet • Getting Ready: Select Set up my connection manually •...
  • Page 31 Entering TCP/IP Settings 1. Windows 2000 — After completing the wizard, you will return to the Network and Dial-up Connections screen. Right-click on the icon for your new connection. In the pop-up menu, select Properties. Windows XP — After completing the wizard, the Connect screen will appear for your new connection.

  • Page 32: Step 9: Make A Data Call

    STEP 9: Make a Data Call Preliminary Checklist Is the DPC properly inserted into the mobile computer and connected securely to the phone? Is the phone receiving a digital signal? A or equivalent will appear on the display of some phones. Is the mobile phone’s signal strength sufficient? A minimum strength of two bars is recommended, but some phones can send data with one.

  • Page 33: Chapter 7 Sms Messaging For Windows 9X/Me/2000/Xp

    Chapter 7 SMS Messaging for Windows 9x/Me/2000/XP The GSM version of the Digital Phone Card includes software for SMS messaging. Socket’s SMS program includes two folders: the SMS folder and the Phonebook folder. The SMS folder is for creating, modifying, and storing messages, while the Phonebook is for creating, modifying, and storing contact information, including information on your phone’s SIM card.
  • Page 34 1. Make sure the SMS folder is open. To open it, click on the SMS button. When the SMS folder is open, the Phonebook button will be at the bottom of the screen, and the title bar will say Socket DPC – SMS. button SMS folder .
  • Page 35 Make a Phonebook Entry 1. Make sure the Phonebook is open. To open it, click on the Phonebook button. The Phonebook button should move right below the SMS button, and the title bar will say Socket DPC - Phonebook. Phonebook button Phonebook folder 2.
  • Page 36 Create a SMS Message by Accessing a Phonebook Entry 1. Make sure the Phonebook is open. Click on the Phonebook button. 2. Select SIM, Phone, Contacts, or wherever else you stored the entry you wish to access. 3. In the next screen, select the entry. Click once on the recipient’s name. IMPORTANT! Make sure the SMS number begins with “+”!!! Phonebook SIM folder Or go to File | New SMS.
  • Page 37 6. To send the message to other recipients in your phonebook, click on Multiple Recipients. From the contact list, click on the name(s) of each additional recipient, then click on Add numbers. The name of each new recipient will be added to the To field. SMS Message screen for multiple recipients 7.
  • Page 38 Archive a Message 1. Make sure the SMS folder is open. To open it, click on the SMS button. The Phonebook button will move to the bottom of the screen. button SMS folder 2. Select SIM, Phone or Sent Items, wherever the message you wish to archive is currently located.

  • Page 39: Appendix A Specifications

    Appendix A Specifications Physical Characteristics: CF Card Size: 1.43 x 1.69 x 0.13 in (36.4 x 42.8 x 3.3 mm) Interconnect Cable Length: 22 in (559 mm) Power Consumption: Standby: 0 mA (0 mW) Typical: 3 mA (10 mW) Interface Standards: CompactFlash Interface: CompactFlash CF, Type I With PC Card Adapter: PCMCIA, Type II Serial Communications: TTL...
  • Page 40 Compatible Applications: Windows Remote Dialup, ActiveSync, Pocket Outlook, Acrobat Reader, AOL Mail Client, EZOS WAP Browser, MSN Mail Client, PacketVideo Player, movianVPN, FTP, Telnet, AvantGO, Citrix, pcANYWHERE, streaming video, etc. Warranty: CompactFlash Card and Non-removable Cable: Lifetime (Three years if not registered) To register your product online, visit: www.socketcom.com/prodreg.html Certification:...

  • Page 41: Appendix B Hints And Tips

    "Internet Service Provider-Wireless" and "Internet Service Provider-Landline." 2. In the Select a modem box, choose Socket DPC Connection for a wireless connection. Choose your existing modem for a landline connection.

  • Page 42: Appendix C Troubleshooting

    Appendix C Troubleshooting SYMPTOM: My computer ... … does not recognize my GSM phone [modem]. … does not respond to AT commands. … cannot place a call. POSSIBLE REASONS SOLUTION Your GSM phone is turned off. Turn on your GSM phone. Your phone is not communicating Turn your GSM phone off, then properly with your computer.
  • Page 43 SYMPTOM: My computer dials but cannot connect. POSSIBLE REASONS SOLUTION Your software is set up for a Configure your software for your modem other than the GSM phone. GSM phone as the modem. You are dialing the wrong number. Check the number, including the area code.
  • Page 44 SYMPTOM: I get a message like NETWORK NOT RESPONDING or CHECK OPERATOR SERVICES on my phone. POSSIBLE REASON SOLUTION The GSM account needs updating. Call your GSM service provider. SYMPTOM: I get disconnected in mid-session. POSSIBLE REASONS SOLUTION The GSM signal has faded, or you Raise the phone antenna.
  • Page 45 SYMPTOM: The data is transmitting slowly. POSSIBLE REASONS SOLUTION The network has a maximum For advice on efficient usage, visit: connection speed of 9600 bps. www.DigitalPhoneCard.com Due to heavy loads, dial-in or web Connect another time, when your servers are responding slowly. office network or ISP is less busy.
  • Page 46 SYMPTOM: I cannot access my email. I cannot use my web browser. POSSIBLE REASONS SOLUTION You are not connected to your Connect again. corporate network or ISP. Your dial-up networking settings Reconfigure the connection with are incorrect. the correct settings for your office network or ISP.

  • Page 47: Appendix D Isp Resources

    Appendix D ISP Resources Here are a few Internet Service Providers (ISPs) that are known to work with the Pocket PC and other Windows CE-based devices. The information in this listing is subject to change without notice. For the most accurate, up-to-date information on connecting to a specific ISP with a Pocket PC, please contact the ISP directly or go visit: http://www.pocketpc.com Name of ISP...
  • Page 48 Erols Internet DNS: 205.252.116.10 http://www.erols.com/ Alt DNS: 205.252.116.19 POP3 server: pop.erols.com SMTP mail host: smtp.erols.com Note: Add 4-6 commas after dial string if not using K56Flex. MCI WorldCom Internet DNS: 204.70.127.127 http://www.wcom.com Alt DNS: 204.70.127.128 POP3 server: mail.internetmci.com SMTP mail host: mail.internetmci.com MindSpring DNS: 207.69.188.185 http://www.mindspring.com...
  • Page 49 Verio DNS: 129.250.35.250 http://www.verio.com Alt DNS: 129.250.35.251 POP3 server: pop.veriomail.com SMTP mail host: smtp.veriomail.com Verizon Online DNS: 206.124.64.253 http://www.verizon.net Alt DNS: 206.124.65.253 POP3 server: mail.gte.net SMTP mail host: smtp.gte.net Note: Requires GTE/ before user name. APPENDIX D: ISP RESOURCES | 47...

  • Page 50: Appendix E Technical Support

    Appendix E Technical Support If you cannot resolve a technical problem with the Digital Phone Card, contact Socket’s technical support department prepared with the following information: • The part number (including revision level) and serial number of your DPC. Please see the diagram below.

  • Page 51: Limited Warranty

    Incompatibility is not a defect covered by Socket’s warranty. During the warranty period, Socket will, at its option, repair or replace the defective product at no charge when furnished with proof of retail purchase, provided that you deliver the product to Socket or to an authorized Socket Service Center.

  • Page 52: Limited Software Warranty

    90 days from the date of delivery of the SOFTWARE. CUSTOMER REMEDIES. SOCKET’S entire liability and your exclusive remedy shall be, at SOCKET’S option, either (a) return of the price paid or (b) replacement of the SOFTWARE which does not meet SOCKET’S Limited Warranty and which is returned to SOCKET with a copy of your receipt.

  • Page 53: Copyright Notice

    Socket Communications requests that you refrain from any applications of the Socket Digital Phone Card that are not described in this manual. Socket Communications also requests that you refrain from disassembling the Digital Phone Card. Disassembly of this device will void the product warranty.

  • Page 54: Regulatory Compliance

    Regulatory Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. This equipment is also CE EN55024:1998 and C-TICK compliant. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 55 © 2001 Socket Communications, Inc. Printed in U.S.A.
