SETTING UP YOUR THERMOSTAT OPTIONS

The Thermostat has comfort and performance options that can be selected and ad-
justed. These options are in the Thermostat Options Configuration Menu. On the Home
Screen Display, touch the Menu key to display additional key choices.
•
Touch and hold the Installer Config
key for 3 seconds. This displays the
first menu item as shown in the next
or
step. Touch to change a
menu option. Touch to advance
to the next menu item or to return
to the previous menu item. Touch
Run Schedule
at any time to exit the
menu and return to the Home Screen
Display.
•
Select On Demand Dehumidifica-
tion setting. Default is OFF. It can be
set in the range of 40 to 94%. Ideally,
the indoor humidity should be set at
55%.
When On Demand Dehumidification
is selected, the thermostat will indi-
cate the current humidity on the home
screen. The display will show RH with
the humidity %. If the current humidity
is above the selected setting, the
thermostat will send an On Demand
Dehumidification request.
On Demand Dehumidification im-
proves the comfort level in your home
by reducing the humidity level. This
is accomplished by slowing down the
system fan speed and lengthening
the run time. The humidity setting
may not be reached before the call for
cool has been satisfied as the system
priority is to maintain the temperature
in the home.
12
1
2

USING YOUR THERMOSTAT

System Operation
Touch the SYSTEM key to select the
thermostat operating mode desired.
When the system is calling for first stage
heat or cool, "Low" will display on the
touchscreen. When second stage is re-
quired, the display will show "High". The
setpoint temperature can be changed by
touching the or keys.
Auxiliary Heating
The system automatically activates
Auxiliary Heating when the outside tem-
perature is too cold for the heat pump to
efficiently heat the home. When Auxiliary
Heating is called for, the display will show
"Auxiliary Heat".
Emergency Heating
Heat pump malfunction is rare, but
should it happen, Emergency Heat can
be manually activated by touching the
SYSTEM key to Em. This will start the
electric or fossil fuel system to provide
heat. The display will show "Auxiliary
Heat".
Temporary Program Override
This feature will override the program
temperature setting until the next pro-
gram period begins. Touch or keys
to adjust the temperature. The display will
indicate "Temporary Hold At" to the left
of the setpoint temperature. To cancel the
temporary setting before the next period
Run Schedule
begins, touch to return to
the program.
Example: If you turn up the heat during
the Morning program, it will remain at the
new temperature until the time for the
next program period (Day program).
9
