Energy Saving Factory Pre-Program - Rheem Comfort Control 2 System Homeowner User Manual

Choose the System Mode (Cool, Off, Heat, Em, Auto)
SYSTEM
Touch the key to select:
Cool: Thermostat controls only the cool-
ing system.
Off: Heating and Cooling systems are
off.
Heat: Thermostat controls only the heat-
ing system.
Em:
Thermostat controls emergency
heating only.
Auto:
Auto Changeover is used where
both heating and cooling may be re-
quired during the same day. Auto allows
the thermostat to automatically select
heating or cooling depending on the in-
door temperature and the selected heat
and cool temperatures. This thermostat
will not allow you to program a conflict
between Heating and Cooling setpoints.

Energy Saving Factory Pre-Program

This touchscreen thermostat is programmed with the energy saving settings shown in
the table below for all days of the week. If this program suits your needs, simply touch
Run Schedule
the key.
Factory Pre-Programmed heating and cooling schedule for all days of the week
Wake Up Leave For Work
(Morning) (Day)
Heating Program 6:00 AM 70°F 8:00 AM
Cooling Program 6:00 AM 75°F 8:00 AM
If you wish to set your heating and cooling schedule to something other than the factory
pre-programmed settings, please proceed to the
section.
8
Return Home Go To Bed
(Evening) (Night)
62°F 5:00 PM 70°F 10:00 PM 62°F
83°F 5:00 PM 75°F 10:00 PM 78°F
"Programming Your Thermostat"
•
Select continuous FAN speed. De-
fault is Medium. It can be set to High,
Medium or Low. In High, the fan will
run at the highest speed when FAN
key is selected to On. In Low the fan
speed will be approximately 30% of
High speed and Medium will be 60%
of the high speed.
•
Select program days per week.
"PRO-
Scrolling message will show
GRAM TYPE". Default is 7 Days
to indicate individual day program-
ming. It can be changed to 0 Days
to indicate no programs will be run.
When set for 7 Days, the thermostat
will follow the factory program or the
program that you entered.
•
Select Energy Management Re-
covery. Scrolling Message will show
"ENERGY MANAGEMENT RECOV-
ERY". (Will not appear if Program
days per week is set to 0 days.) When
selected On, the thermostat will begin
heating or cooling early to have the
temperature reach the program set-
point at the program period start time.
Example: The heating program is 65° at night and 70° at 7 AM for the Morning
period. The building temperature is 65°, a difference of 5°. Allowing 5 minutes per
°F rise, the thermostat will begin the system at 6:35 AM to reach 70° at 7 AM.
•
Select continuous backlight. Scroll-
ing message will show "BACKLIGHT".
When bL is selected ON the backlight
will be on continuously. Selecting bL
OFF will allow the backlight to turn
on momentarily when any key is
touched. If system power is off, and
thermostat is operating on battery
only, bL ON, will turn the backlight on
momentarily when a key is touched.
1
2
1
2
1
2
1
2
13
