Polar Electro E30 User Manual

E30 manual USA B 18/11/02 12:26 Page 1
1.
How to Put Your Heart Rate Monitor On
2.
How to Start and Stop Your HRM
3. How to Recall Data from the E30
4. Uploading Settings from Your Computer
5.
Post Exercise Care
6. Finding your Target Heart Rate Zone
7. Changing the Battery
8.
Precautions
Heart Rate Monitor
9.
Frequently Asked Questions
Heart Rate Monitor
10.
Technical Specifications
11. Limited Polar International Guarantee
12. Disclaimer
User's Manual
User's Manual Note: Your E30 comes preprogrammed with the
audible out of zone alarm activated and with a target
USA
heart rate zone of 135-180 bpm. Please use the
calculation in the "Finding Your Target Zone" section
and reset the target heart rate zone, if necessary,
before using the E30 with your students or exercising
with the E30 yourself.
2.
How to Start and Stop Your HRM
Time in Zone Indicators
With the watch within
1.
1 solid block = 5 minutes spent
3 feet / 1 meter of your
in target zone (a flashing
transmitter, press the red
block is incomplete), 6 solid
button to start.
blocks = 30 minutes. After 30
minutes, when all the blocks are
solid, the cycle will start again but
will read from right to left.
First the upper and lower limit of your target
2.
zone will be displayed. Then the
To check your exact
heart rate symbol
3.
time in zone while
will flash to the beat of your
exercising, bring the
heart. Your heart rate will
watch near the Polar
appear in 5 seconds. If you
logo on the
go above or below your zone,
the heart rate display will flash transmitter. Your
exact time in zone
and an alarm will beep
will appear for 3 seconds and
(See section 4).
then the display will
automatically revert to
showing heart rate.
Note: When starting the monitor, have your
students stay at least 3 feet / 1 meter apart
4. To stop recording, press the red button.
so that the watch can lock onto its wearer's
The display will read OFF.
heart rate signal. This helps to minimize
interference when the students come close
together during exercise. See section 8 for
specifics.
Contents 1.
How to Put Your Heart Rate Monitor (HRM) On
The Polar E30™
wrist receiver
displays your heart rate
during exercise.
The Polar coded
transmitter
detects your heart rate
and transmits it to the
wrist receiver.
The elastic strap
holds the transmitter in
the correct position.
3.
How to Recall Data from the E30
From the OFF display, press and
1.
hold the red button. The display
will briefly show "File" and then
display the average heart rate
for the exercise.
Press the red button. The display
2.
will show the total time in
target zone.
Press the red button. The display
3.
will show the total exercise time.
Press the red button. The display
4.
will show the upper target zone
limit.
1. Attach one side of elastic strap 3.
Lift the transmitter off your chest and
to the transmitter. moisten the two oval electrode areas
on the backside of the transmitter.
2. Adjust the strap length so that it is snug
4. Check that the wet electrode areas are firmly
but not uncomfortable. Position the
against your skin and the Polar logo is in a
transmitter so that it is just below the
central upright position.
chest muscles, across the sternal notch,
and buckle it.
4.
Uploading Settings from Your Computer to the E30
Press the red button. The display will show the The E30 allows you to program a target zone and turn
5.
the audible out of zone alarm on or off, right from
lower target zone limit. If you keep making
your computer.
short presses of the red button, you will keep
scrolling through the data.
Note: To upload settings you will need a PC with a
sound card (compatible with Sound Blaster™) and
To exit the file mode, press and hold the red
dynamic loudspeakers. 'Dynamic' speakers are also
6.
button. The display will read OFF.
referred to as magnetic or acoustic speakers. These
are common on desktop PC's, but some laptops have
If you want to recall your file later, start with
ceramic speakers, and these will not work. In this case,
step 1. The E30 saves one complete file. When you can buy inexpensive dynamic speakers or
headphones and plug them in. (Before purchasing,
a new exercise recording is started, the new
check with your tech people, they may have some.)
information will be recorded over the old. As
a safety, if the red button is accidentally pushed,
Installing the software:
and either no heart rate is picked up, or if the
1.
Ask your technology person for assistance. You may
recording is interrupted within 5 minutes, no
need an authorization password to install the software
new information will be saved and the old file
on a school computer.
will still be intact.
2.
Place the E30 CD in your CD drive and close.
Note: At any point in the file recall, you can
3.
Wait for the setup screen to appear automatically.
return to OFF by pressing and holding the red
button.
4.
Follow the instructions on your screen.
Uploading settings:
1. Click on the E30 software icon on your desktop.
2.
Set the target zone limits and choose to have the
audible alarm either on or off.
Additional Tips for Working with Children:
1. In small children or children with concave
chests, etc., you might find you get a better
heart rate reading if you put the transmitter
across their backs, with the Polar logo upside
down.
2. Have your students put the transmitter on
and adjust the straps, over their t-shirts.
Then they can slide the straps down and
wiggle them up under their shirts.
3. It may be possible to wear the transmitter
over a T-shirt as long as the area under the
electrodes is thoroughly wetted. If the
E30 does not pick up heart rate, the transmitter
will have to be worn directly against the skin.
3.
From the OFF mode on the E30 HRM, press and hold
the button so the file recall starts and the average
heart rate is displayed.
4.
Hold the E30 less than 7"/18cm from the speaker.
5.
Click the Set HRM button on your computer and hold
the E30 steady. You will hear a series of chirps. If
uploading is successful, the E30 will read Set and OK.
6.
Press and hold the button on the E30 to return to the
OFF mode.
Note: If you are unsuccessful (the HRM does not show
Set and OK), turn the HRM sideways to speaker with
the watch face up, so that the 'P' in 'Polar' is closest to
the speaker, and try again. You can also try adjusting
the volume up or down and varying the distance of
the HRM to the speaker. Louder and closer is not always
better.
Advanced:
If you change the target zone regularly, click the
Advanced button. You can name the zone and save
it for later use.
