REARSIGHT CAMERA SYSTEM
INSTALLATION INSTRUCTIONS
PARTS IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . 2
SYSTEM LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TESTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
REASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
INSTALLATION TIPS . . . . . . . . . . . . . . . . . . . . . . . . . 9
NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
250-8122
CONTENTS
F
#5110, R
ORM
. A, 09-06-07
EV
Advertisement
Related Manuals for Rostra 250-8122
Summary of Contents for Rostra 250-8122
-
Page 1: Table Of Contents
REARSIGHT CAMERA SYSTEM 250-8122 INSTALLATION INSTRUCTIONS CONTENTS PARTS IDENTIFICATION ..... 2 SYSTEM LAYOUT ......3 INSTALLATION . -
Page 2: Parts Identification
PARTS IDENTIFICATION Service UMBER ESCRIPTION REARSIGHT MONITOR/STEM ASSEMBLY 250-8131 & MONITOR HARNESS 250-8511 MONITOR EXTENSION HARNESS 250-8110 REAR CAMERA ASSEMBLY 250-8530 CAMERA RCA & POWER HARNESS 250-8509 SACK PARTS: TIE STRAPS, T-TAPS, SEALING PUTTY, FOAM TAPE, ALCOHOL PADS, CAMERA HARDWARE ARDWARE ONTENTS ESCRIPTION... -
Page 3: System Layout
SYSTEM LAYOUT DIAGRAM A LCD Monitor Monitor Harness Camera Splitter Harness 6 ACCESSORY POWER GROUND REVERSE LIGHT POWER CAMERA 5 VEHICLE PREPARTION Before beginning installation, familiarize yourself with the installation instructions and the REAR SIGHT camera system components. To ensure your safety: A) Apply the emergency brake. -
Page 4: Installation
INSTALLATION STEP 1 HARNESS CONNECTIONS VIDEO 2 1. ROUTE HARNESSES TO BE JOINED WITH (VIDEO 2 ALLOWS REVERSE OVERIDE TO FUNCTION) RCA, AUDIO RCA & DC POWER CONNECTOR HARNESS AS PER FIGURE 1. USE PROVIDED WIRE TIES TO SECURE WIRING HARNESS AWAY FROM MOVING PARTS AND SHARP EDGES. CONNECTIONS VIDEO 2 •... - Page 5 INSTALLATION STEP2: MOUNTING MONITOR FIGURE 2 FIGURE 3 1. REMOVE EXISTING REARVIEW MIRROR FROM VEHICLE. FIGURE 2. 2. MOUNT REARSIGHT MONITOR ON WINDSHIELD LUG AND TIGHTEN SCREW. FIGURE 3. ROUTE CAMERA EXTENSION HARNESS TO THE BACK OF VEHICLE. 3. SECURE HARNESSES WITH WIRE TIES.
- Page 6 INSTALLATION STEP3: MOUNTING CAMERA TOP OF CAMERA MICROPHONE ON RIGHT FIGURE 4 1. WHEN MOUNTING THE CAMERA CHOOSE A LOCATION THAT MEETS SOME VERY IMPORTANT REQUIREMENTS. • CAMERA IS MOUNTED IN MANNER THAT PROVIDES A CLEAR VIEW FOR THE BACK OF THE VEHICLE. THIS VIEW SHOULD INCLUDE A PORTION OF THE VEHICLE AS TO PROVIDE A POINT OF REFERENCE.
- Page 7 2. THIS INSTRUCTION IS BASED ON INSTALLATION PREFERENCE FOR THE BOX TRUCK APPLICATION (SEE CAMERA INSTALLATION FIGURE 5). REMOVE CENTER THIRD BRAKE LIGHT FROM BOX IF MOUNTING IN CENTER OF TOP OF BOX. (FIGURE 5) • REMOVE CENTER BRAKE LIGHT. •...
- Page 8 • ROUTE CABLES INSIDE WALL OF TRUCK BODY TO PREVENT ANY DAMAGE TO CIRCUITS. (FIGURE 7) • ROUTE WITH EXISTING CABLES AT EXITS AT THE BOTTOM OF THE BOX AND ALONG FRAME RAIL INSIDE WIRE TIE CIRCUITS AT A OF WALL MINIMUM AT THE OEM FREQUENCY.
-
Page 9: Testing
TESTING AND REASSEMBLY TESTING 1. R ECONNECT EGATIVE ATTERY ABLE AND TORQUE TO ENTER ANY THEFT DETERRENT INFORMATION IF APPLICABLE 2. T URN THE IGNITION SWITCH ON UT THE VEHICLE IN REVERSE ERIFY THAT THE ’ IGHT MONITOR IS ON AND THE CAMERA S PICTURE APPEARS 3. -
Page 10: Notes
NOTES... - Page 11 NOTES...
- Page 12 Rostra Precision Controls, Inc. Global Automotive Accessories Group 2519 Dana Drive Laurinburg, NC 28352-4000 www.rostra.com Certified QS 9000/ISO 9001 Made in the U.S.A.
