Function Block Diagram; System Overview - TRIGEM NARA-M Micro-ATX Hardware Document

TriGem Computer Inc.
Research & Development Center.
II.

System Overview

Intel Pentium-III
Cu-256K FC-PGA
DIMM Modules
Primary IDE
Secondary IDE
FDD
Super I/O Function
Rear Port
MOUSE
K/B
2 Serial Ports
Parallel Port
4 USB Ports
(2 ports are Option)
Format No: TGDFBD06-A
Host Interface
VIA
VT82C694X(Z)
PCI Interface
CS4297A
VIA
Codec
VT82C686A
Speaker Line In
Rear Port
Page6/18
1 AGP (2X or 4X) Slot
3 PCI Slots
CS4281
Joystick and
MIC
MIDI
