TriGem Computer Inc.
Research & Development Center.
1-3. On Board Audio device function
J1
On Board PCI audio device functionality
1-2(default)
Enable PCI audio controller built in the motherboard
2-3
Disable PCI audio controller built in the motherboard
1-4. OEM/ODM selector
The jumpers (J3, J4 & J5) will be optional parts for the OEM/ODM logo message selector.
Format No: TGDFBD06-A
Page12/ 18
