  • Page 2 Batter Battery W Batter y Warning Instruction arning Instruction arning Instruction arning Instruction Batter Batter arning Instruction Caution If battery is incorrectly replaced there poses a danger of explosion. Replace battery only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer's instructions.
  • Page 3 TriGem Computer, Inc. s Address Manufacturer’ 1055 Shin-gil-Dong, Ansan City, Kyunggi Do, Republic of Korea European Representative Name TriGem Computer (U.K.) Ltd. European Representative Address 69 Bucking Ave. Trading Estate Slough Berkshire SL1 4PN U.K. Equipment Type/Environment Motherboard Model Name...

  • Page 4: Table Of Contents

    CONTENTS Chapter 1 Chapter 1 Chapter 1 Introduction Introduction Introduction Chapter 1 Chapter 1 Introduction Introduction Features ..........................1-1 Motherboard Overview ....................1-3 Chipset..........................1-4 Super I/O Controller ...................... 1-4 Motherboard Connectors ....................1-5 Expansion Connectors ................... 1-6 Diskette Drive Connector (CN20) ..............1-7 Enhanced IDE Connectors (CN22 and CN23) ..........
  • Page 5 Security Menu........................2-16 Supervisor/User ..................... 2-16 Anti-Virus ......................... 2-19 Default Menu ........................2-19 Original ........................2-19 Optimal........................2-20 Exiting the SETUP Program..................2-20 Chapter 3 Chapter 3 Installing Motherboard Options Installing Motherboard Options Chapter 3 Installing Motherboard Options Chapter 3 Chapter 3 Installing Motherboard Options Installing Motherboard Options...
  • Page 6 Appendix A Specifications Appendix A Specifications Appendix A Specifications Appendix A Specifications Appendix A Specifications Power Supply ........................A-3 Appendix B Motherboard Resources Appendix B Motherboard Resources Appendix B Motherboard Resources Appendix B Motherboard Resources Appendix B Motherboard Resources DMA Channels......................... B-1 Interrupts ...........................

  • Page 7: Features

    Chapter 1 Introduction Introduction F F F F F eatures eatures eatures eatures eatures Your mini-ATX motherboard provides the following built-in features: Built-in Slot 1 processor connector (or microprocessor SEC cartridge connector). Support an Intel® Pentium® II processor that runs at an internal speed of 233, 266, 300, or 333 MHz and at an external speed of 66 MHz and Intel Pentium II processor (Deschutes) that runs at internal speed of 300, 350, or 400 MHz and at an external speed of 100 MHz.

  • Page 8: Power Supply

    Three 32-bit PCI bus slots, two 16-bit ISA slots, and one PCI/ISA shared slot for either a PCI or ISA card. AGP (Accelerated Graphics Port) slot that supports AGP cards with its own graphics bus enhancing 3D performance. Four DIMM sockets to expand up to 512 MB using 168-pin SDRAM DIMMs. 512 KB of pipelined burst level 2 (L2) cache included within the Pentium II Single Edge Contact (SEC) cartridge.

  • Page 9: Motherboard Overview

    Motherboard Over Motherboard Over view view Motherboard Over Motherboard Over Motherboard Over view view view The illustration below shows the components on the motherboard. Slot 1 proc essor ATX auxiliary power connector connector ATX power connec tor DIMM sockets (DIMM0, DIMM1 PS/2 keyboard/mous e DIMM2, DIMM3) connectors (stacked)

  • Page 10: Chipset

    Chipset Chipset Chipset Chipset Chipset The Intel 443BX chipset is the third generation of desktop PCIset and is designed for the Pentium II processor. It consists of the Intel 82443BX PCI/AGP controller (PAC) and the Intel 82371EB PCI/ISA IDE Xcelerator (PIIX4E) bridge chip. Intel 82443BX PCI/AGP Controller (PAC) The PAC provides bus-control signals, address paths, and data paths for transfers between the processor’s host bus, PCI bus, Accelerated Graphics Port (AGP), and...

  • Page 11: Motherboard Connectors

    Motherboard Connectors Motherboard Connectors Motherboard Connectors Motherboard Connectors Motherboard Connectors The illustration below shows the connectors on the motherboard. Slot 1 proc essor ATX auxiliary power connector (CN35) connector (CN9) ATX power connec tor (CN24) PS/2 keyboard/mous e DIMM sockets (CN16, CN15, connectors (stacked) CN 17, CN18) (CN14)

  • Page 12: Expansion Connectors

    Expansion Connectors Your motherboard contains two 16-bit ISA option slots, three 32-bit PCI option slots, one PCI/ISA shared slot (CN3 and CN4), and one AGP slot. You can install a maximum of six option cards, since one PCI and ISA slot share the same chassis I/ O panel.

  • Page 13: Diskette Drive Connector (Cn20)

    Diskette Drive Connector (CN20) You can connect up to two diskette drives to the diskette drive connector. After connecting the one end of the diskette drive ribbon cable to the motherboard, connect the two connectors on the other end to the diskette drives. Figure 1-3.
  • Page 14 The BIOS in the motherboard supports bootup from IDE CD-ROM drive, floptical drive, SCSI drive or network drive. So, you can select a CD-ROM drive or floptical drive as a boot device by setting CD-ROM or Floptical in the Advanced Setup menu of the SETUP program.

  • Page 15: Atx Primary Power Connector (Cn24)

    ATX Primary Power Connector (CN24) You can connect an ATX-compliant power supply to the 20-pin block ATX power connector. Connect the cable from the power supply to this connector. Make sure that the cable from the power supply is aligned with the power connector on the motherboard and then firmly push down the cable.

  • Page 16: Front Panel I/O Connectors

    Front Panel I/O Connectors The motherboard provides header connectors to support functions typically located on the front panel of the computer and the illustration below shows the front panel I/O connectors. power LED HDD LED speaker keyboard lock reset switch suspend switch power switch Figure 1-6.

  • Page 17: Back Panel I/O Connectors

    Back Panel I/O Connectors The illustration below shows back panel connectors that are located on the edge side of the motherboard. USB connectors parallel port (CN11) (CN13) PS/2 mouse connector (CN14) PS/2 keyboard serial port 1 connector connector (CN14) (CN10) serial port 2 connector (CN12) Figure 1-7.

  • Page 18: Figure 1-8. Connecting Peripherals To The Back Panel Connectors

    PS/2 Keyboard Connector (CN14) The PS/2 keyboard is connected to the connector. PS/2 Mouse Connector (CN14) The PS/2 mouse is connected to the connector. mouse keyboard modem (serial device) printer (parallel device) CCD camera (USB device) Figure 1-8. Connecting Peripherals to the Back Panel Connectors Introduction 1-12...

  • Page 19: Chapter 2 Using The Setup Program

    Chapter 2 Using the SETUP Program Using the SETUP Program About the SETUP Program About the SETUP Program About the SETUP Program About the SETUP Program About the SETUP Program Using the SETUP Program...

  • Page 20: Figure 2-1. System Setup Window

    Star Star Star ting the SETUP P ting the SETUP P ting the SETUP P ting the SETUP P rogram rogram rogram rogram Star Star ting the SETUP P rogram Figure 2-1. System Setup Window Using the SETUP Program...

  • Page 21: Selecting Options

    Selecting Options Selecting Options Selecting Options Selecting Options Selecting Options → ← ↑, ↓ Using the SETUP Program...

  • Page 22: Setup Menu

    Setup Menu Setup Menu Setup Menu Setup Menu Setup Menu Standard Setup Menu Pri Master/Pri Slave/Sec Master/Sec Slave Type Using the SETUP Program...
  • Page 23 LBA/Large Mode Block Mode 32Bit Mode PIO Mode Using the SETUP Program...

  • Page 24: Advanced Setup Menu

    Date/Time Floppy A and B Advanced Setup Menu Quick Boot 1st Boot Device 2nd Boot Device Using the SETUP Program...
  • Page 25 3rd Boot Device BootUp Num-Lock PS/2 Mouse Support Primary Display Password Check Boot To OS/2 Using the SETUP Program...

  • Page 26: Chipset Setup Menu

    Internal Cache C000 / C400, 16K Shadow C800 / CC00 / D000 / D400 / D800 / DC00, 16K Shadow Chipset Setup Menu Memory Hole Graphics Aperture Size Using the SETUP Program...

  • Page 27: Power Control Setup Menu

    Power Control Setup Menu Power Management / APM Power Button Function Note Note Note Note Note Using the SETUP Program...
  • Page 28 AC Power Default Status Remote Power On LAN Remote Power On Modem Suspend Time Out Device 6 (Serial port 1) Device 7 (Serial port 2) Device 8 (Parallel port) Using the SETUP Program 2-10...

  • Page 29: Pci/Pnp Setup Menu

    Device 5 (Floppy disk) Device 0, 1, 2, 3 (Primary master IDE, Primary slave IDE, Secondary master IDE, Secondary slave IDE) Note Note Note Note Note PCI/PnP Setup Menu Plug and Play Aware O/S Using the SETUP Program 2-11...
  • Page 30 PCI Latency Timer (PCI Clocks) PCI VGA Palette Snoop Allocate IRQ to PCI VGA Allocate IRQ to USB DMA Channel 0, 1, 3, 5, 6, and 7 IRQ 3, 4, 5, 7, 9, 10, 11, 14, and 15 Using the SETUP Program 2-12...

  • Page 31: Peripheral Setup Menu

    Peripheral Setup Menu OnBoard FDC OnBoard Serial Port 1 OnBoard Serial Port 2 Serial Port 2 Mode Using the SETUP Program 2-13...
  • Page 32 Duplex Mode OnBoard Parallel Port Parallel Port Mode Parallel Port IRQ Parallel Port DMA Channel Using the SETUP Program 2-14...

  • Page 33: Utility Menu

    OnBoard IDE Utility Menu Utility Menu Utility Menu Utility Menu Utility Menu Detect IDE Color Set Using the SETUP Program 2-15...

  • Page 34: Security Menu

    Security Menu Security Menu Security Menu Security Menu Security Menu Supervisor / User Supervisor and User password functions Using the SETUP Program 2-16...
  • Page 35 Setting a Password Note Note Note Note Note Deleting or Changing a Password Using the SETUP Program 2-17...
  • Page 36 Accessing Your Current Password Using the SETUP Program 2-18...

  • Page 37: Anti-Virus

    Anti-Virus Default Menu Default Menu Default Menu Default Menu Default Menu Original Using the SETUP Program 2-19...

  • Page 38: Optimal

    Optimal Exiting the SETUP Program Exiting the SETUP Program Exiting the SETUP Program Exiting the SETUP Program Exiting the SETUP Program Figure 2-2. Exit Setup Window Using the SETUP Program 2-20...
  • Page 39 Using the SETUP Program 2-21...

  • Page 40: Chapter 3 Installing Motherboard Options

    Chapter 3 Installing Motherboard Options Installing Motherboard Options Before Y Before Y ou Begin ou Begin Before Y Before Y Before Y ou Begin ou Begin ou Begin You need a standard ATX chassis for you to install your motherboard in. The power supply for the motherboard should be an ATX type that uses DC power.

  • Page 41: Changing The Dip Switch Settings

    Caution Caution Caution Caution Caution Electrostatic discharge (ESD) can damage components on the motherboard. To prevent static damage, discharge static electricity from your body by touching a metal part of the computer chassis. Changing the DIP Switch Settings Changing the DIP Switch Settings Changing the DIP Switch Settings Changing the DIP Switch Settings Changing the DIP Switch Settings...

  • Page 42: Figure 3-2. Dip Switch Setting

    Switches control various circuits or functions in the motherboard. The switches on the motherboard are rocker type of dual in-line package (DIP) switches. Each of these switches has two settings (on and off). To change the settings of the DIP switches, use a small, pointed object such as a small screwdriver or a straightened paper clip to press down on the appropriate side of the switch.

  • Page 43: Microprocessor

    Microprocessor Microprocessor Microprocessor Microprocessor Microprocessor The motherboard provides a Slot 1 processor connector for a single Pentium II processor packaged in a Single Edge Contact (SEC) cartridge. You can install an Intel Pentium II (Klamath) processor with MMX technology operating at 233, 266, 300, or 333 MHz or an Intel Pentium II (Deschutes) processor with MMX technology operating at 300, 350, or 400 MHz in the Slot 1 processor connector.

  • Page 44: Installing The Retention Mechanism

    Installing the Retention Mechanism Type A To install the type A retention mechanism on the motherboard, follow these steps: See the illustration in "Motherboard Overview" in Chapter 1 to locate the Slot 1 processor connector on the motherboard. Position the retention mechanism so that the tab on the connector can fit into a notch in the base of the mechanism.

  • Page 45: Figure 3-4. Installing The Processor Retention Mechanism (Type B)

    Type B To install the type B retention mechanism on the motherboard, follow these steps: See the illustration in "Motherboard Overview" in Chapter 1 to locate the Slot 1 processor connector on the motherboard. Position the retention mechanism so that the tab on the connector can fit into a notch in the base of the mechanism.

  • Page 46: Installing The Passive Heatsink Support Base

    Installing the Passive Heatsink Support Base Note Note Note Note Note If you are installing a Pentium II processor with active fan cooling in the motherboard, refer to the manual that comes with the processor. A passive heatsink support base with two retention pins comes with the motherboard.

  • Page 47: Installing The Processor

    Installing the Processor Follow these steps to install the processor: Locate the processor so that the heatsink will be toward the support base next to the connector. Insert the processor into the Slot 1 connector. Press down on the processor until it is firmly seated in the Slot 1 connector and the latches on the processor lock into place.

  • Page 48: Setting The Dip Switches For The Processor Speed

    Setting the DIP Switches for the Processor Speed Make sure that DIP switches 1, 2, 3 and 4 are set to the correct value for the speed of the processor. See "Changing the DIP Switch Settings" for DIP switch settings for processor speed.

  • Page 49: Installing A Memory Module

    Single sided modules are usually 16 MB or 64 MB and double sided modules are usually 8 MB, 32 MB, or 128 MB. DIMM size ECC configuration Non-ECC configuration 8 MB 1 Mbit x 64 1 Mbit x 72 16 MB 2 Mbit x 64 2 Mbit x 72 32 MB...

  • Page 50: Removing A Memory Module

    Orient a DIMM to the socket so the two notches in the DIMM connector are aligned with the crossbars in the socket. Press the DIMM straight into the socket until the retaining clips snap into place around the ends of the DIMM. notches DIMM 3 crossbars...

  • Page 51: Figure 3-10. Removing A Dimm

    Press the retaining clips outward simultaneously until the DIMM disengages from the socket. Figure 3-10. Removing a DIMM Replace the computer cover. R R R R R eplacing the Batter eplacing the Batter eplacing the Batter y y y y y eplacing the Batter eplacing the Batter The 3 V, coin-cell CR2032-type battery on the motherboard provides power to the...

  • Page 52: Figure 3-11. Removing The Battery

    Pry the battery out of its socket by pushing from the position marked with “PUSH” with your fingers to remove the battery. Figure 3-11. Removing the Battery Insert the new battery into the battery socket with the "+" side facing up. battery battery socket Figure 3-12.

  • Page 53: Chapter 4 Update On Installing Windows 95

    Chapter 4 Update on Installing Windows 95 Update on Installing Windows 95 If you have USB devices connected to your system and (re)installed Windows 95, you must install the Microsoft USB Supplement for Windows 95 after installing Windows 95. The USB Supplement is included in your Windows 95 CD. After installing USB Supplement for Windows 95, you must install the Bus Master IDE driver for Windows 95.
  • Page 54 Installing the USB Supplement for W Installing the USB Supplement for W indows 95 indows 95 Installing the USB Supplement for W Installing the USB Supplement for W Installing the USB Supplement for W indows 95 indows 95 indows 95 You must install the Microsoft USB Supplement for Windows 95 to configure the USB ports on the motherboard correctly.

  • Page 55: Installing The Bus Master Ide Driver For Windows 95

    Installing the Bus Master IDE Driver for W Installing the Bus Master IDE Driver for W Installing the Bus Master IDE Driver for W indows 95 indows 95 indows 95 indows 95 Installing the Bus Master IDE Driver for W Installing the Bus Master IDE Driver for W indows 95 For detail information on driver installation and verification, see README.TXT...
  • Page 56 Appendix A Specifications Specifications Processor Processor type Intel Single Pentium II (Klamath) processor that runs at 233, 266, 300, or 333 MHz internally/66 MHz externally Intel Single Pentium II (Deschutes) processor that runs at 300, 350, or 400 MHz internally/ 100 MHz externally L1 cache 32 KB level 1 cache (16 KB data cache;...
  • Page 57 Core chipset Intel 82443BX Processor host bus speed up to 66/100 MHz PCI/AGP Accelerated Graphics Port controller controller (PAC) Integrated PCI bus mastering controller Intel 82371EB Supports up to four IDE drives or devices PCI/ISA/IDE Multifunction PCI-to-ISA bridge Xcelerator USB and DMA controllers (PIIX4E) Two fast IDE interfaces Real-time clock...
  • Page 58 P P P P P ower Supply ower Supply ower Supply ower Supply ower Supply At least a 200 W power supply should be used for the motherboard. The power supply must provide sufficient +5VSB current (720mA) to support the motherboard's optional Wake On LAN feature and meet the following requirements: Rise time for power supply: 2 ms to 20 ms...

  • Page 59: Dma Channels

    Appendix B Motherboard Resources Motherboard Resources DMA Channels DMA Channels DMA Channels DMA Channels DMA Channels Data width System resource 8 or 16 bits 8 or 16 bits Parallel port 8 or 16 bits Diskette drive controller 8 or 16 bits Parallel port (for ECP or EPP) Direct memory access controller 16 bits...

  • Page 60: Interrupts

    Interrupts Interrupts Interrupts Interrupts Interrupts System resource I/O channel check Reserved, interval timer Reserved, keyboard buffer full Reserved, cascade interrupt from slave PIC Serial port 2 Serial port 1 Parallel port 2 Diskette drive controller Parallel port 1 Real time clock (RTC) Reserved Reserved Reserved...
