Add Virtual Host - AXIMCom MR-102N User Manual

8.2.2 Add Virtual Host

1. Click on [Add] tab. You will see the following screen.
2. Configure [Add Virtual Host] Settings following the instructions below
Sequence Number
Rule Name
Rule Enable
External Interface
External IP Address
Mapped LAN IP
Address
This defines the sequences (priorities) of the Virtual Host rule. If a packet fits
the conditions setup by the Virtual Host rule rules, the packet will then be
forwarded according to the 1st rule from the top of the list.
Enter the name of the Virtual Host rule.
Enable/Disable this Virtual Host rule.
WAN1 as the External port forwarding interface.
The external IP addresses offered by the ISP.
Assign the LAN IP intended to map the specified external WAN IP.
63
