Inaxsys IN-DO2MIRVSLL Installation Manual

Outdoor dome flat surfaced ceiling mounted exterior dome (face down)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Outdoor Dome
Flat Surfaced Ceiling Mounted
Exterior Dome (Face Down)
Installation Guide
For Models:
IN-DO2MIRVSLL, IN-DO4MF, IN-DO4M36A, IN-DO1MIRF, IN-DO2MIRF,
IN-DO3MIRF, IN-DO5MIRF, IN-DO1MIRV, IN-DO2MIRV, IN-DO3MIRV &
IN-DO5MIRV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN-DO2MIRVSLL and is the answer not in the manual?

Questions and answers

Related Manuals for Inaxsys IN-DO2MIRVSLL

Summary of Contents for Inaxsys IN-DO2MIRVSLL

  • Page 1 Outdoor Dome Flat Surfaced Ceiling Mounted Exterior Dome (Face Down) Installation Guide For Models: IN-DO2MIRVSLL, IN-DO4MF, IN-DO4M36A, IN-DO1MIRF, IN-DO2MIRF, IN-DO3MIRF, IN-DO5MIRF, IN-DO1MIRV, IN-DO2MIRV, IN-DO3MIRV & IN-DO5MIRV...

  • Page 2: Table Of Contents

    Step 8: Close the Dome Cover ..............15 Appendices ............... 16 Accessing the Camera Live View ............16 Focus and Viewing Angle Adjustments ..........24 Safety Information ............30     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 3: Installation Procedures

    Route the network cable to pass this hole from the ceiling.  If the cables will be routed along the ceiling, skip to the next step.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 4: Step 2: Open The Dome Cover

    3. Carefully lift to open the dome cover and place it on the side of the camera. NOTE: Do not abruptly lift the dome cover; it is attached to the camera with a spring wire.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 5: Step 3: Prepare For Waterproof Installation

    The bundled conduit gland may vary. Check the conduit gland that came with your package to determine if 3/8” or 1/2" is the suitable flexible conduit size.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 6: Waterproof Solution With Naked Cable

    1. Disassemble the cable gland as shown below: Sealing Insert Body Clamping with Claw (with Washer) 2. Insert the clamping nut into the Ethernet cable. 3. Insert the sealing insert with claw.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 7 Make sure the clamping nut is tightly attached to the cable gland body and the sealing insert is squeezed tightly. 6. Proceed with Step 4: Install the Camera to the Ceiling on page 12.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 8: Waterproof Solution With Conduit

    Check the conduit gland that came with your package to determine if 3/8” or 1/2" is the suitable flexible conduit size. 2. Disassemble the bundled conduit gland as shown below:     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 9 The connectors will be attached later after the cables pass through the conduit hole of the camera. 4. Insert the clamping nut through the flex conduit.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 10 7. If the cable will be routed along the ceiling, skip to step 8. If the cable will pass through the ceiling, do the following: a. Pull the network cable and other cables (if any) through the bottom conduit hole.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 11 Installation Guide b. Insert the sealing nut into the conduit gland body and then attach the clamping nut to complete the cable solution.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 12: Step 4: Install The Camera To The Ceiling

    Since electric screwdrivers vary in sizes, speed, and force, they may bruise and damage the internal camera components. DISCLAIMER: Inaxsys Security Systems Inc. will not be responsible for camera damage caused by improper installations or the misuse of equipment for installation. ...

  • Page 13: Step 5: Connect The Cable(S)

    Once cables pass through the conduit hole of the camera, attach the bundled connectors. For more information on connecting these cables, please refer to the camera model hardware manual downloadable from the website (www.inaxsys.com).  ...

  • Page 14: Step 6: Access The Camera Live View

    Based on the Live View, adjust the viewing angle and orientation of the camera. Adjustments vary per model, for detailed information, please refer to the following sections:  For IN-DO1MIRF, IN-DO2MIRF, IN-DO3MIRF & IN-DO5MIRF camera models, see page  For IN-DO2MIRVSLL, IN-DO1MIRV, IN-DO2MIRV, IN-DO3MIRV & IN-DO5MIRV camera models, see page 25.   ...

  • Page 15: Step 8: Close The Dome Cover

    1. Align the position of the dome cover shroud to the direction of the lens. 2. Tighten the three (3) screws to attach the dome cover to the camera body.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 16: Appendices

    It is necessary to know the IP address of the camera in other to be able to access it by using a Web browser.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 17 By double-clicking the mouse button on the camera model it is possible to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 18 The IP Utility can be downloaded for free from: http://www.inaxsys.com/en/support/downloads/software-downloads.html With just one click, you can launch the IP Utility and there will be an instant report as follows: You can quickly notice the camera model in the list.
  • Page 19 In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below:     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 20 This way, the Web browser will not be confused about two devices having the same IP address at the same time.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 21: Access The Camera

    When using Internet Explorer browser, the ActiveX control for video stream management will be downloaded from the camera directly – the user just has to accept the use of such control when     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 22 HTTP port of the camera is 80, which can be omitted from the address for convenience. Before logging in, you need to know the factory default Account and Password of the camera. Account: admin Password: 123456     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 23 Installation Guide To check the firmware version through the Web Configurator, access the Setup page and click System > System Info. For further operations, please refer to the Firmware User Manual downloadable from the website (www.inaxsys.com).    ...

  • Page 24: Focus And Viewing Angle Adjustments

    This section describes the procedures in adjusting the viewing angle, focus, and pan direction of the different camera models under the 4” Outdoor Dome series. IN-DO1MIRF, IN-DO2MIRF, IN-DO3MIRF, IN-DO5MIRF Camera Parts Overview Adjustment Procedures     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 25 3. Loosen the pan adjustment screw, move the pan direction, and then tighten back the screw to fix the pan position. 4. Attach the bundled lens focus tuner unto the lens and turn left or right to adjust the focus. IN-DO2MIRVSLL, IN-DO1MIRV, IN-DO2MIRV, IN-DO3MIRV, IN-DO5MIRV Camera Parts Overview ...
  • Page 26 4. Move the zoom and focus levers left or right to adjust the focus and the viewing angle. IN-DO4MF Camera Parts Overview     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 27 4. Loosen the focus adjustment screw, and move the lens left or right to adjust focus, and then tighten back the screw to fix the lens position. IN-DO4M36A Camera Parts Overview     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 28 1. Loosen the tilt adjustment screws, adjust the tilt, and then tighten back the screws to fix the tilt position. 2. Move the rotation adjustment to rotate the viewing orientation. 3. Move the pan direction left or right.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 29 If you need to tighten or loosen the pan adjustment knob and adjustment by hand is not enough, insert the bundled pan bracket wrench into the hole on the knob and then push it to the left or to the right.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...

  • Page 30: Safety Information

    Only install this device in a dry place protected from weather Servicing Do not attempt to service this video product yourself. Refer all servicing to qualified service personnel.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
  • Page 31 Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition.     8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com...
