Seorim Technology Micro DVR AKR-200 Quick Manual

Micro dvr
Hide thumbs
1
2

Advertisement

Table of Contents

LED
REC LED : Green LED blinks while recording
STATUS LED :
Yellow LED blinks when an error occurs or while
recording is proceeding.
POWER LED : Red LED lights when power is on.
MICRO DVR

Installation

1. Insert SD card.
2. Connect camera (VIDEO IN) and monitor (VIDEO OUT).
3. Connect microphone (AUDIO IN) and Speaker (AUDIO OUT).
4. Connect power cable (DC 12V) and supply power.
Remarks
* Audio is mute on live mode, but it is activated on playback mode.
* In case of displaying no image on the monitor,
disconnect power cable and reconnect it.
* Before inserting SD Card, it should be formatted in 'FAT32' on PC.
* Sandisk Card has been tested with MICRO-D.
The compatibility with other brands is not guaranteed
-up to SD/ SDHC SandDisk 4GB/ 8GB/ 16GB/ 32GB

Menu Mode

Press 'MENU' button of the remote control in order to access OSD menu
Enter password. Default password is '0000'.
Press 'ENT' button 4 times in a consecutive way to enter the password.
SD Card
IR Receiver
Reset Button
GROUND
ALARM OUT
GROUND
ALARM IN
MODEL
MICRO-D
VERSION
1.x
PASSWORD
* * * *

Language Setup

OSD MENU > SYSTEM SETUP > LANGUAGE SETUP
LANGUAGE SETUP
: English
VIDEO OUTPUT
: NTSC
BRIGHTNESS
: Normal
Setect Language : English, French, Dutch, German,
Spanish, Japanese, Chinese
* Refer to the manual for more details.
