I N S T A L L A T I O N

Features:

• 4 Independent Outputs
• 4 Independent Timers
• All Outputs Assignable by Code
• On board 5 Amp Form C Relay
• 120 Users
• Remote Triggering Input
• Keypad Programmable

Memory

Non-volatile EEPROM memory means your codes and
Programming will be there whether you remove power for
5 minutes or 5 years.

Programming

All programming is accomplished entirely from the
front of the keypad. LED or Sounder guidance makes
programming easy, and changing codes a matter of
seconds for an authorized user.

Codes

The RCI keypads allow up to 120 individual user codes
to be valid. Codes may be from 1-6 digits in length
and digits may be repeated. The Master Code is always
assigned to user location one (1).

Main Relay

This is a 5 Amp (10 Amp surge) Form-C relay which can
be toggled or timed from 1 to 90 seconds-by code.

Auxiliary Outputs

Auxiliary outputs can be individually timed from 1 to 90
seconds or act as a toggle switch, and may be triggered
individually or in combination-by code. The three auxiliary
outputs provide a 50mA sink to ground when activated.

Remote Triggering Input

This normally open loop that by default operates the Main
Relay upon activation and can be programmed to trigger
any combination of outputs. Upon a momentary closure,
Voltage
Current Rating
12-24 VAC/VDC
@ 12VDC 8mA typ – 35mA w/ relay energized
@ 24VDC 16mA typ – 45mA w/ relay energized
NOTE: As with any electronic product, the 9212i may be subject to irregularities in the AC power line. This can cause malfunction or unstable operation.
Connecting the 9212i to a suitable DC power supply will limit the effects of AC fluctuation on the keypad.
IS9212i
USA: 2517 SQUADRON COURT, SUITE 104, VIRGINIA BEACH, VA 23453 • CANADA: 210 SHEARSON CRESCENT, CAmBRIDGE, ON N1T 1j6
PHONE • 1.800.265.6630 • 519.621.7651 • FAX: 1.800.482.9795 • 519.621.7939 • E-mAIl: SAlES@RUTHERFORDCONTROlS.COm
Instructions
the selected outputs will energize for their programmed
time. The main relay (if selected) will energize for the
same time period as the Master Code. This feature is
especially useful when controlling an electric locking
device.
Keypress Feedback / Audible Keypress
The RCI keypads will acknowledge a keypress by
momentarily illuminating the yellow LED. This can be
turned off through programming.
Keypad Active Output
The RCI keypads can be programmed to energize a
voltage output whenever a key is touched. This can be
used to turn on accessories such as lights, CCTV camera,
or notify a guard.
Auto-Entry
This feature is used when the need for the code not to
be followed by the * key is desired. The user only needs
to enter their code number and the relay will activate for
the programmed relay time. To use this feature, the user
codes must be the same length as the master code.
Technical Notes:
To avoid ESD (Electro-Static Discharge) from interfering
with the operation of the RCI keypad, ground the negative
terminal of the keypad to earth ground. If the power
supply can not be grounded, then the case should be
grounded. For 24VDC operation, remove jumper J2 (see
Fig. 5).
Packing Checklist:
9212i Keypad
Ten (10) Conductor Wiring Harness (1)
Slotted Screws (2)
Security Screws (2)
Installation
Diode (1)
Temperature
-20°F to 130°F (-28°C to 54°C)
©2013 RutheRfoRd contRols • www.RutheRfoRdcontRols.com
9212i
Stand-Alone Keypad
Output
Main relay: 5A; form-C @24VDC; 10A surge
Outputs 2-4 are 50mA neg voltage outputs
Pcn13031
R04/13cA
