Page 1: Installation Guide
INSTALLATION GUIDE A CONTROL MODULE CM3300 CM3300 INSTALLATION GUIDE CM3300... - Page 2 TABLE OF CONTENTS Wiring Diagram Page 4 Installation of Antennas and RPS Page 5 Option Programming for Four Button Remotes Page 6 Remote - Pager Programming Menu Options Page 7 Page 2 Page 3...
- Page 3 Wiring Diagram Output for Parking Lights : Some vehicles, such as Jeep, have negative Parking lights. (+) Siren Output (+) Parking Light An Aux output is a 5sec pulse that can be changed to Latch. 1 2 V Constant See Programming Options. Ground ( - ) 250mA Parking Light ( - ) 250mA Horn Output...
- Page 4 Option Programming For Four Button Remotes With Remote-Pager Programming Menu Options Separate Lock & Unlock Buttons . Enter programming by pressing: Optional Factory Default a. The (lock) button, and the (unlock) button simultaneously until the parking lights Feature Setting - Button Setting - Button flash once.
- Page 5 With this option, the doors will lock after the ignition is turned on and unlock Optional Programming Factory Default when the ignition is turned off. Feature Setting - Button Method Setting - Button You can program the duration between 1 to 99 seconds. You can program the “Latch Mode”...
- Page 6 Setting Access to passive mode through a remote AUX No. Non setting of passive mode Setting of passive mode Button Button Button Button Button Button Button Button Button Button III- Button All outputs are connecting with AUX 1, Channel Expander through AUX1. AUX 2 In order to decrease the chirping volume of the siren, cut the loop located on the siren.
