- Page 1 ANGULAR TILE DRILL RODIA FB750W OPERATING MANUAL...
- Page 2 Keep this Manual in a safe place for future reference. Enter the Serial Number of your new Rodia ® Angular Tile Drill FB750W in the box below. The Serial Number is located on the machine housing PAGE 2 RODIA FB750W OPERATING MANUAL V10/2006R1...
-
Page 3: Table Of Contents
Installation of the diamond bits ..................11 Ventilation Openings in the housing of the machine ..............11 Storage after use ......................11 Defects and Faults ......................11 4. DIAMOND TILE BITS Diamond Bits ........................12 RODIA FB750W OPERATING MANUAL V10/2006R1 PAGE 3... -
Page 4: Rodia Safety
It is important that all instructions within this manual be followed. Failure to follow these instructions can lead to irreparable damage. PAGE 4 RODIA FB750W OPERATING MANUAL V10/2006R1... - Page 5 There will be no warranty claim. FORCING THE TOOL. ● The equipment was designed to do a certain job. Do not force the equipment to do something that it wasn’t designed to do. RODIA FB750W OPERATING MANUAL V10/2006R1 PAGE 5...
- Page 6 Any part of the machinery that is damaged should be checked carefully to determine whether or not it should be used and whether or not it can function properly for its intended use. PAGE 6 RODIA FB750W OPERATING MANUAL V10/2006R1...
-
Page 7: Hazard Symbols
TURN OFF DRILL BEFORE PLUGGING IN ● It is important to make sure that the switch is in the OFF position before plugging in the machine to prevent accidental starting of the machine. RODIA FB750W OPERATING MANUAL V10/2006R1 PAGE 7... -
Page 8: California Proposition 65 Message
Do not touch the diamond bit during operation. ● Do not leave the machine turned “ON” when not in use. ● Unplug the machine before changing tools or performing maintenance. ● Always use coolant water. ● PAGE 8 RODIA FB750W OPERATING MANUAL V10/2006R1... -
Page 9: Machine Specifications
Motor [W/HP/Amp] 750/1/7 No Load Speed (stageless) [RPM] 3,000 - 10,000 Max. Bit Capacity [Inch-Metric] 2 5/8"- 68 Spindle Lock Weight [lbs] Optional Accessories: Dress Stick 70.12.001 Diamond Tile Bits see page 12 RODIA FB750W OPERATING MANUAL V10/2006R1 PAGE 9... -
Page 10: Check Before Use
● water tank to the 5 liter level and pressurize by pumping at least 10 times. Connect the water tank and the hose to the drilling unit. Always use the PRCD Switch ● PAGE 10 RODIA FB750W OPERATING MANUAL V10/2006R1... -
Page 11: Drilling
Styrofoam, stone or Defects and Faults concrete debris. Remove these objects before using the machine. If the ventilation Contact your Rodia Distributor for repair ● openings are not clear it will mean that the work. They can direct you to a service cooling of the motor is diminished and can center. -
Page 12: Diamond Tile Bits
Rodia ® Diamond Tile Bit 7/8” (24 mm) 40.00.230 Rodia ® Diamond Tile Bit 1” (26 mm) 40.00.232 Rodia ® Diamond Tile Bit 1 1/8" [28 mm] 40.00.233 Rodia ® Diamond Tile Bit 1 1/4" [32 mm] 40.00.235 Rodia ® Diamond Tile Bit 1 3/8”...
