Bunn My Café MCA Use And Care Manual

Tea & coffee pod brewer
Hide thumbs Also See for My Café MCA:
Table of Contents

Advertisement

Quick Links

See also: Quick Manual
USE AND CARE OF YOUR
Tea & Coffee Pod Brewer
Model MCA
AUTOMATIC
The Bunn logo is a registered trademark of Bunn-O-Matic Corporation.
My Café is a registered trademark of Bunn-O-Matic Corporation.
RECORD MODEL & SERIAL NUMBER
In order to receive accurate and timely warranty assistance, it is important to
record the Model and Serial Number information located on the bottom of the
brewer. A space is provided below for this information.
MODEL:
SERIAL NUMBER:
41980.0000C 06/11 ©2009 BUNN-O-MATIC CORPORATION
®
My Café
Model MCP
POUR IN
Record these numbers from the
bottom of the brewer, before
fi lling the brewer with water.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the My Café MCA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bunn My Café MCA

Summary of Contents for Bunn My Café MCA

  • Page 1 Model MCP AUTOMATIC POUR IN The Bunn logo is a registered trademark of Bunn-O-Matic Corporation. My Café is a registered trademark of Bunn-O-Matic Corporation. RECORD MODEL & SERIAL NUMBER In order to receive accurate and timely warranty assistance, it is important to record the Model and Serial Number information located on the bottom of the brewer.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNINGS ......................2 USER NOTICES ...................... 3 INTRODUCTION ..................... 3 IMPORTANT HANDLING INFORMATION ..............3 SPECIFICATIONS ....................4 IMPORTANT SAFEGUARDS ................... 5 GENERAL INFORMATION ..................6 FEATURES AND CONTROLS .................. 8 DEFINITIONS ......................9 WATER INLET SET-UP ..................10 PLUMBING REQUIREMENTS ................

  • Page 3: Warnings

    Type ménager et READ THE ENTIRE OPERATING MANUAL BEFORE USING THIS PRODUCT Repair should be done commercial. by authorized Service Les réparations doivent être 00986.0002F 10/07 ©1994 Bunn-O-Matic Corporation Personnel only. confiées aux personnes # 00986.0002 qualifiées. # 37267.0000 WARNING: HOT LIQUIDS # 37280.0000...

  • Page 4: Specifications

    SPECIFICATIONS Electrical (MCA/MCP)- This brewer has an attached, 3-prong grounded cord set and requires 2-wire service with ground, rated 120 volts ac, 12 amps, single phase, 60 Hz. Components include a 1450-watt tank heater. NOTE: Do not operate brewer on the same outlet as other electrical appliances. Electrical (MCAA/MCPA)- This brewer has an attached, grounded cord set and requires 2-wire service with ground, rated 220-240 volts ac, 6 amps, single phase, 50/60 Hz.

  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS Follow these basic safety precautions when using electrical appliances to reduce the risk of fi re, electric shock, and/or personal injury: • Do not insert or remove pod holder • Read all instructions. while brewing. Press the coffee or tea •...

  • Page 6: General Information

    • A power switch is provided on the lower left side to completely shut off all electrical components when your plans take you away from the brewer for three ® or more days. Safety features, designed into the BUNN Pod brewer, make the daily use of this switch unnecessary.
  • Page 7 GENERAL INFORMATION (Cont.) • CAUTION: Never apply force to remove the pod holder. If the holder does not slide out easily, wait 10 minutes and try again. Burns resulting from hot water splash could occur if the holder is forcibly removed from the brewer. •...

  • Page 8: Features And Controls

    FEATURES & CONTROLS A Slide Lid B Pod Holder Release Button C Sprayhead Seal D Sprayhead E Pod Holder Insert F Pod Holder G Drip Tray Grate H Drip Tray Volume Control Lever J Control Panel K Brew Lights (Blue) W ater Inlet (MCA) M Power Switch N Water Reservoir...

  • Page 9: Definitions

    fl avor. The “On-Off-On” water fl ow is normal. Always wait for the blue (brew) lights to go out, and the red BUNN light to come back on before carefully removing the mug or pod holder. Pressing either brew button during this operation will stop the brew cycle.

  • Page 10: Water Inlet Set-Up

    Bunn-O-Matic does not recommend the use of a saddle valve to install the brewer. The size and shape of the hole made in the supply line by this type of device may restrict water fl...

  • Page 11: Initial Brewer Set-Up

    INITIAL BREWER SET-UP (MCP/MCPA) Remove Slide Lid (A) and Water Reservoir (N) Plug in the brewer and turn on the Power Switch (M). NOTE: The “Refi ll Water Indicator” will slowly fl ash until initial setup is complete. Press the Pod Holder Release Button (B) and pull the Pod Holder (F) out.
  • Page 12 INITIAL BREWER SET-UP (MCP/MCPA) Press the “Coffee Brew Button” while Fill the Primer Bulb (O) with water by applying a small amount of downward squeezing the bulb while in the Water pressure on the “Primer Bulb” then Reservoir.* squeeze to dispense the water from the bulb.

  • Page 13: Brewing Delicious Coffee Or Tea

    P2961 NOTE: The red BUNN light will come back 4. Press and hold the on indicating the brew cycle has fi nished. pod holder release 9. Dispose of the used button while sliding pod.

  • Page 14: Routine Cleaning

    URNEX ® Activated Descaler or JavaClean2 Cleaner and Descaler, available on our web site: www.bunn.com. (White vinegar can be used to descale if a descaling product is not available.) Follow the directions as printed on the manufacturer’s package. 1) Fill the reservoir with descaling product as described by the manufacturer’s directions, or 32 oz.

  • Page 15: Cleaning The Sprayhead/Seal

    7) Place the empty container back onto the drip tray grate and press the COFFEE BREW BUTTON to begin a brew cycle. 8) When the cycle has fi nished, empty the container. Repeat step 7 at least two more times to remove the solution from the tank. 9) Clean the pod holder with a mild detergent and rinse thoroughly.

  • Page 16: Inspecting The Sprayhead/Seal

    CAUTION: The seal confi nes the hot liquid to the pod holder. Replace the seal if it becomes damaged. Parts are available at www.bunn.com. CLEANING THE POD HOLDER To prevent residue build up, it is a good idea to periodically disassemble the pod holder/screen assembly and clean it with a mild detergent.

  • Page 17: Troubleshooting

    TROUBLESHOOTING SITUATION EXPLANATION The REFILL WATER INDICATOR Pour-Over only: The WATER RESERVOIR has run low on water. has come on. Slide the lid open and pour additional water into the reservoir, or remove the reservoir and fi ll it at a sink, or other water source. CAUTION: Do not place the brewer in a sink or other water source.
  • Page 18 TROUBLESHOOTING (Cont.) SITUATION EXPLANATION (Continued) again. This is normal and will take about 45 The water shuts off and comes seconds to complete. Wait for the blue lights back on again when brewing. to go out. NOTE: Although the pulse brew process can be used for coffee or tea, it is designed to brew tea.
  • Page 19 ® No action is required. The BUNN brewer is ready to brew. When the brewer enters a sleep mode the POD HOLDER BUTTON will not be glowing.

  • Page 20: Limited Warranty

    Upon receipt of the request for warranty service, Bunn at its sole option may choose to replace the unit, request that the unit be taken to a local Bunn Service center for repairs or request the unit be mailed pre paid to a Bunn repair center for repairs.
  • Page 21 NOTES:...

  • Page 22: User Serviceable Parts

    USER SERVICEABLE PARTS Strainer Assembly Strainer Assy Early 120V Models 230V Models...
  • Page 23 USER SERVICEABLE PARTS 37419.1000 Reservoir Assy, Float/Valve 36264.0000 Reservoir, 46 Oz 39446.0000 Guide/Float Assy 36378.0001 Valve, Check DW 10 36379.0000 Valve, Check DW 11 37521.0000 Kit, Sprayhead/Seal Assembly 37520.0000 Drip Tray & Grate Assy (MCP) 37520.0001 Drip Tray & Grate Assy MCA) 37495.1000 Lid Assy, Pour-In (Includes Decals) 36717.1002...
