Summary of Contents for Safesight SC9003
- Page 1 ™ S A F E S I G H T S C 9 0 0 3 R e v e r s e b a c k u p c a m e r a s y s t e m Installation Guide and User’s Manual Version 1...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction........................................1 1.1 Notes and Warnings ..................................1 2. Installation/Setup .......................................2 2.1 LCD monitor shroud removal..............................2 2.2 Method 1 – Shroud removal using a screwdriver ......................3 2.3 Method 2 – Shroud removal using a credit card ........................4 2.4 Method 2 – Shroud Mounting tabs and receiver........................5 3. -
Page 3: Introduction
1. Introduction Thank you for purchasing the Safesight SC9003 Reverse camera system! This system will help prevent the most deadly type of automobile accidents, reversing accidents. All that’s left is to install and use your system. In the following information we will guide you through installing your system and getting the most out of it. -
Page 4: Installation/Setup
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 2. Installation/Setup We begin by identifying the contents of the back up camera system: 1. LCD Monitor 2. Back up camera 3. Monitor wiring harness 4. Camera wiring harness 5. Extension cable 6. Remote Control 7. -
Page 5: Method 1 - Shroud Removal Using A Screwdriver
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 2.2 Method 1: - Shroud removal using a screwdriver See the picture below for added clarification on the removal of the monitor from its shroud. Note: Carefully insert the screwdriver or pick and gently pry the tab back. -
Page 6: Method 2 - Shroud Removal Using A Credit Card
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 2.3 Method 2: - Shroud removal using a credit card Note: Carefully insert a credit card in between the monitor housing and the shroud Page 4... -
Page 7: Method 2 - Shroud Mounting Tabs And Receiver
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 2.4 Shroud mounting tabs and receivers Note: The rectangular slot and tab lock into one another Page 5... -
Page 8: Monitor Wiring Harness
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 3. Monitor wiring harness The monitor wiring harness is a single harness that has a multi-pin connector on one end and a series of wires and RCA cables on the other. The black box contains a power filter and fuse that prevents damage in the event of a short circuit. -
Page 9: Method Identifying The Rca Cables
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 3.2 Identifying the RCA cables RCA Cable Connection Connect this to a secondary camera or DVD source. This input is not trigger-able Male RCA Cable and can only be used if 12 volts is not applied to the green trigger wire. -
Page 10: Monitor Cable Diagram
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 3.3 Monitor cable diagram Multi-pin connector Red bare wire Male RCA Female RCA Black bare Green Cable Cable wire bare wire Page 8... -
Page 11: Multi-Pin Connector Connection
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 3.4 Multi-pin connector connection Warning: Carefully align the cables so that no damage occurs to the pins, use caution when pressing the connector’s together. Damage to the harness is not covered under warranty. -
Page 12: Back Up Camera
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 4. Back up camera The back up camera that is included in this system is a high sensitivity CCD camera that has excellent low light capabilities. In situations where there is no ambient light the camera has infrared illumination that will illuminate approximately a 10 foot radius in front of the camera for better visibility. -
Page 13: Back Up Camera Cable Diagram
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 4.2 Back up camera cable diagram Red DC Yellow Power RCA video connector output cable Warning: Make sure to make DC Power connection when no power is applied and battery is disconnected, short is possible if not inserted correctly. -
Page 14: Camera Extension Cable
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 5. Camera extension cable The extension cable that is included with this kit is a shielded 60 foot cable that carries composite video and 12 Volts DC power and ground. The cable has two ends, one end has two connectors and the other end has one RCA connector and two bare leads. -
Page 15: Back Up Camera Cable Diagram
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 5.2 Back up Camera Cable Diagram Red bare Black bare Red DC wire wire connector power connector Page 13... -
Page 16: System Connections
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 6. System connections There are several ways to install this system. We will only discuss the way we recommend installing the system so that it can be used in many different ways. You will be able to turn the system on at any time and the system will automatically turn on when the vehicle is placed in reverse. - Page 17 Safesight SC9003 Back up camera system www.qualitymobilevideo.com This is the 12 volt negative power connection for the Black bare wire Extension cable camera. This will connect to the same location you get power from. Connects to the yellow female Yellow male RCA Cable Extension cable RCA cable #8.
-
Page 18: System Diagram
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 6.2 System Diagram Warning: It is always recommended that you place an inline fuse within 6 inches of the main power tap; this protects the system and the wiring in the event of a short. -
Page 19: In-Line Fuse Connection
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 6.3 In-line fuse connection (not included) An inline fuse is recommended to be put in place within 6 inches of the power tap. In-line fuses prevent fires and damage to equipment in the event of a short circuit. In-line fuses and fuse holders can be purchased at any automobile store or electronics store. -
Page 20: Main Power Connection
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 6.4 Main power connection The main power connection can be made many different ways. You can connect main power by: • Using a cigarette lighter cord • Taping the back of a cigarette lighter •... - Page 21 Safesight SC9003 Back up camera system www.qualitymobilevideo.com In-line fuse to protect in the Fuse tap event of a short Warning: It is always recommended that you place an inline fuse within 6 inches of the main power tap; this protects the system and the wiring in the event of a short.
-
Page 22: Reverse Trigger Connection
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 6.5 Reverse trigger connection The reverse trigger is a positive signal that causes the monitor to automatically turn on when the vehicle is placed in reverse. We recommend that you tap this signal at the light bulb connector. - Page 23 Safesight SC9003 Back up camera system www.qualitymobilevideo.com Once you determine which wire is the positive signal you will tap this circuit with a wire tap. You will need to connect this to the green lead of the monitor. Connect reverse...
-
Page 24: Troubleshooting
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 7. Troubleshooting This section of the guide should highlight common issues users may encounter and offer simple solutions. 7.1 Unit will not turn on when the vehicle is placed in reverse Monitor will not power on when the vehicle is placed in reverse. This problem usually stems from an incorrect wire being tapped for the reverse signal. -
Page 25: Unit Will Not Turn On When The Vehicle Is Placed In Reverse
Safesight SC9003 Back up camera system www.qualitymobilevideo.com 7.3 Monitor and camera will not turn on after the vehicle is taken out of reverse. The system should turn on and off manually when the vehicle is running if you have connected the system as we described in this manual.
