Black & Decker Dustbuster AV1500 Instruction Manual

Automotive vac
Hide thumbs


Quick Links

Automotive Vac
Aspirateur pour véhicule
Aspiradora automotriz
Instruction manual
Manuel d'instructions
Manual de'instrucciones
N° de catalogue
catálogo N°
Thank you for choosing Black & Decker!
To register your new product go to
Please reaD BefOre reTurNiNg This PrODucT fOr aNy reasON.
if you have a question or experience a problem with your Black & Decker
purchase, go to
if you can't find the answer or do not have access to the internet,
call 1-800-544-6986 from 8 a.m. to 5 p.m. esT Mon. - fri. to speak with an agent.
Please have the catalog number available when you call.
save This MaNual fOr fuTure refereNce.
vea el esPaNOl eN la cONTraPOrTaDa.
iNsTrucTivO De OPeraciÓN, ceNTrOs De serviciO y PÓliZa De garaNTÍa.
aDverTeNcia: lÉase esTe iNsTrucTivO aNTes De usar el PrODucTO.
Catalog No. AV1500
July 2014
It is important for you to read and understand this manual. The information it contains relates to
protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help
you recognize this information.
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially haz a rd o us situation which, if not avoided,
may result in minor or mod er ate injury.
Used without the safety alert symbol indicates potentially hazardous
situation which, if not avoided, may result in property damage.
When using an electrical appliances, basic precautions should always be followed, includ-
ing the following:
Read all safety warnings and all instructions. Failure to follow the
warnings and instructions listed below may result in electric shock, fire and/or serious injury.
Some household dust contains chemicals known to the State of
California to cause cancer, birth defects or other reproductive harm such as asbestos and
lead in lead based paint.
To reduce the risk of fire, electrical shock or injury:
Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer's recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around
sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of
dust,lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas
where they may be present.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use without dust bag and/or filters in place.
• This appliance is intended for household use only and not for commercial or industrial use.
• Shock Hazard. To protect against risk of electrical shock, do not put unit in water or other liquid.
• Do not allow the cord to hang over the edge of a table or counter or touch hot surfaces. The unit
should be placed or mounted away from sinks and hot surfaces.
• Plug the unit only in a standard automobile power outlet.
• Unplug the unit from outlet before any routine cleaning or maintenance.
• Do not look into the air vents when the unit is switched on, as sometimes
there is a possibility of small debris being discharged from the air vents, especially after
cleaning / replacement of the filters as debris inside the unit can be disturbed.
FORM NO. 90614017
Risk of Fire. Do not replace any vehicle fuse with a rating higher
than recommended by the vehicle manufacturer. This product is rated to draw 10 amperes
from a 12V vehicle outlet. Ensure that the electrical system in your vehicle can supply this
product without causing the vehicle fusing to open. This can be determined by making sure
the fuse in the vehicle which protects the outlet is rated higher than 10 amperes. Information
on the vehicle fuse ratings are typically found in the vehicle operator's manual. If a vehicle
fuse opens repeatedly, do not keep on replacing it. The cause of the overload must be found.
On no account should fuses be patched up with tin foil or wire as this may cause serious
damage elsewhere in the electrical circuit or cause fire.
Product Features (Fig. A)
1. On/Off slide switch
2. Release button
3. Dust bowl
4. 12V vehicle connector
How To Use
n Make sure that the appliance is switched off.
n Remove the cigarette lighter from the socket.
n Plug the connector (4) into the 12V vehicle outlet / cigarette lighter socket.
n To switch on, slide the on/off switch (1) forward.
n To switch off, slide the on/off switch back.
n The appliance can be used for periods of up to 30 minutes without noticeably affecting
the power of a normally charged car battery in good condition.
Extended use may totally discharge your car battery.
n Do not run the vehicle's engine while cleaning. This can shorten the life of the appliance.
n This appliance is intended for household use only and not for commercial or industrial use.
The appliance is supplied with the following accessories:
n A hard brush (5) for upholstery.
n A crevice tool (6) for confined spaces.
The accessories are stored beneath the rear of the appliance.
To fit an accessory, proceed as follows:
n Take the accessories from the appliance.
n Insert the appropriate accessory into the front of the appliance.
If the product does not work, follow the instructions below. If this does not solve the prob-
lem, please contact your local Black & Decker repair agent.
n Make sure the connector (4) is plugged into the 12V vehicle outlet / cigarette lighter
socket correctly.
n Make sure your vehicle battery system is of the 12 V negative ground type.
Regularly clean the filter.
Cleaning the dust bowl and filters (fig. F, G, H & I)
The filter is re-usable and should be cleaned regularly.
n Press the release button (2) and remove the dust bowl (3) (fig. F).
n Remove any dust from the dust bowl (fig. G).
