- Page 1 Porter & Charles OPERATION MANUAL Ceramic Hob CC30S, CC60-2, CC76-2, CC90-2...
- Page 2 Porter&Charles Congratulations on the purchase of your appliance. We are sure it will provide many years of great cooking experience. You may find that it has different features and characteristics to your last appliance. It is essential you read this operation manual thoroughly to fully understand all of the various functions and operations.
- Page 3 DESCRIPTION HOT PLATES Touch Control 1. Hi-lite heating element 145mm. 1200Watt 2. Hi-lite heating element 180mm. 1800Watt 3. Double circuit Hi-lite heating element 120/210mm. 750/2200Watt 4. Double circuit oval Hi-lite heating element 180/260mm. 750/2200Watt...
- Page 4 Knob Control 1. Radiant heating element 145mm. 1200Watt 2. Radiant heating element 180mm. 1700Watt 3. Hi-lite heating element 145mm. 1200Watt 4. Hi-lite heating element 180mm. 1800Watt 5. Double circuit Hi-lite heating element 120/210mm 750/2200Watt 6. Double circuit oval Hi-lite heating element 180/260mm 750/2200Watt 7 Hi-lite heating...
- Page 5 Using the Appliance WARNING All operations relative to installation and electric connection should be carried out by qualified personnel in conformity with the regulations in force in your country. The specific instructions are described in the booklet section for the installer NOTICE •...
- Page 6 The control is switched on by pressing the On/Off key(key 6) for 1 second, causing a sound signal it will not turn on while the key lock function (key 10) is active(indicated by Led11). The heating element remain switched off (all the digits at 0) until a power level is selected. If this is not done within 10 seconds the control switches off automatically.
- Page 7 While the temperature on the cook top surface is above 65°C, this condition will be shown in the associated display, by means of an “H”. If the cook top is switched off, residual heat is shown by a static “H” in the display. If the cook top is on, but the power level is 0, the associated display will show alternately “H”...
- Page 8 Switches itself off automatically. The timed heating element can be programmed as follow: *Fixed heating element: The timer setting always applies to the same heating element. *Programmable heating element: The user can decide which heating element to time. The selection of a new heating element cancels the previous choice, thus the timer setting can only apply to one heating element at a time.
- Page 9 1. Timer setting: Only allow the timer to work in timer mode. 2. Timer-alarm setting: Allow the timer to work in either timer mode or alarm mode. The working mode is programmed by the user. Configuration examples The following examples detail the basic functioning of the timer combining the timed heating element (fixed/programmable) and timer/timer-alarm settings.
- Page 10 heating element will switch itself off automatically. The corresponding display (5) also switches off or shows an “H” to indicate residual heat and the timer alarm is activated. Alarm mode: if no heating element is selected, the “t” on the displays (5) disappears, enabling the user to set the timer value.
-
Page 12: Installation Instructions
Installation Instructions WARNING The operations indicated below must be followed by qualified personnel, in conformity with the regulations in force. The supplier refuses all responsibility for damages to person or property, resulting from the failure to comply with such provisions. INSTALLATION All units are 230/240 power and 60hz The appliance is designed to be embedded into heat resistant pieces of furniture or kitchen cabinetry. - Page 13 DIMENSIONS AND CUT-OUTS 30CM CERAMIC HOB (12”) Hob: W 288mm D 510mm 1700 / W 11 Inches 20 Inches 1200 Cut-out W 270mm D490mm W10.5 Inches D19 Inches 60CM CERAMIC HOB (24”) 1800 / Hob: W 600mm D 510mm 1200 W 23.5 Inches D 20 Inches Cut-out:...
- Page 14 Hob: W 900mm D510mm 1200 / W 35.5 Inches D20 Inches 750/2200 Cut-out W 860mm D 490mm 1200 / W 34 Inches D 19 Inches 750/2200 Warranty Porter&Charles products are designed and built to the highest standards. We expect your appliances to provide many years of trouble free enjoyment.
- Page 15 Porter&Charles Name:____________________________ Tel no ______________________________________ Address: _______________________________________________________________________ City: ______________________ State:_______________ Zip Code: _______ ________ Where purchased: _________________________ Purchase date ;___________________ Items purchased:_____________________________________________________________________ Serial No. (s): ___________________________________________________________________...
- Page 16 Porter & Charles...
