Summary of Contents for Porter & Charles CC60S
- Page 1 OPERATION MANUAL Ceramic Hob CC30S, CC60S(2), CCK60, CC76-2 COD. 208165-06 - 24.11.2014...
-
Page 2: Table Of Contents
Congratulations on the purchase of your Porter&Charles appliance. We are sure it will provide many years of great cooking experience. You may find that it has different features and characteristics to your last appliance. It is essential you read this operation manual thoroughly to fully understand all of the various functions and operations. - Page 3 WARNING: • The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been...
- Page 4 DESCRIPTION HOT PLATES Touch Control Hi-lite heating element 145 mm 1200 W Hi-lite heating element 180 mm 1800 W Double circuit Hi-lite heating element 120 / 210 mm 750 / 2200 W Double circuit oval Hi-lite heating element 190 / 285 mm 1400 / 2200 W Knob Control Hi-lite heating element...
-
Page 5: Product Description
TOUCH CONTROL 1 - Selection of cooking setting 8 - Selection of timer setting 2 - Cooking setting position 9 - Timer position 3 - Connection key front left 10 - Locking of the cooking surface connection and selection 4 - Connection display front left 11 - Locking display 5 - Display of cooking setting 12 - Connection key rear right... -
Page 6: Using The Appliance
Using the Appliance · WARNING All operations relative to installation and electric connection should be carried out by qualified personnel in conformity with the regulations in force in your country. The specific instructions are described in the booklet section for the installer NOTICE • Use only flat pans and with sufficient thick base, equal to or not much larger than the hot plate selected (fig.1) - Page 7 Switching the double cooking area The control (key 3) or (key 12) can be used to activate 2 heating elements with a double cooking area and one of them with triple area, with 2 sensors to activate or cancel it. Each cooking area has an associated LED (Led 4 and 13).
- Page 8 Safety auto-power-off If the power level is not changed for a present time, the element in question will automatically be turned off. The maximum operating time of an element depends on the cooking level selected. Power Level Max time ON (hours) Thermal protection of the control panel When the control panel detects an ambient temperature above 96°C it turns off the nearest element (selected by software), and an “H” for residual heat shows in the associated display.
- Page 9 * Fixed heating element: The timer setting always applies to the same heating element. * Programmable heating element: The user can decide which heating element to time. The selection of a new heating element cancels the previous choice, thus the timer setting can only apply to one heating element at a time. When we touch the keys (8) of the timer the first time, it will appear as “.” in each heating element display awaiting your selection.
-
Page 10: Cleaning
Programmable timed heating element + timer alarm setting The timer can function in either timer mode or in alarm mode. When the timer is activated a “.” appears on the displays (5) of each of the heating elements. The user has 10 seconds to select the heating he or she wishes to time. To select a heating element, simply press either (+) or (-) (1) sensor of the chosen heating element. - Page 11 Configuration examples The following examples detail the basic functioning of the timer combining the timed heating element (fixed/programmable) and timer/timer-alarm settings. Any combination of the 4 remaining options (see below). Can be added to these examples. Increase of timer value (1 min. /5min.) Indication of timed heating element.
- Page 12 FIGURE 208/240 V2~ AWG 10 / AWG 12...
-
Page 13: Installation Instructions
Installation Instructions WARNING · The operations indicated below must be followed by qualified personnel, in conformity with the regulations in force. The supplier refuses all responsibility for damages to person or property, resulting from the failure to comply with such provisions. INSTALLATION All units are 230/240 power and 60hz The appliance is designed to be embedded into heat resistant pieces of furniture or kitchen cabinetry. -
Page 14: Dimensions And Cut-Outs
DIMENSIONS AND CUT-OUTS 30 CM CERAMIC HOB (12”) Hob: W 288 mm D 510 mm 1800 W W 11 Inches 20 Inches 1200 W Cut-out W 270 mm D 490 mm W 10.5 Inches 19 Inches 60 CM CERAMIC HOB (24”) Hob: W 580 mm D 510 mm... -
Page 15: Warranty
Warranty Porter&Charles products are designed and built to the highest standards. We expect your appliances to provide many years of trouble free enjoyment. In the event of an appliance requiring attention, each appliance is covered by a 2 year warranty from the date of purchase. Refer to warranty policy for complete terms and conditions. - Page 16 Porter & Charles Incorporated Telephone 905-829.8389 Fax 905-829.8409...
