Summary of Contents for Porter & Charles CI76
- Page 1 OPERATION MANUAL INDUCTION CERAMIC HOBS CI76 COD. 208176 - REV 4 - 07.07.2006...
-
Page 2: Induction Cooking
INDUCTION COOKING The induction cooking is a radical change on the traditional way of cooking. The heat is generated from directly in the cooking vessel and maintains a cold cooking surface. For this reason it presents many advantages when compared to other cooking methods. High speed cooking and frying. -
Page 3: Control Description
DESCRIPTION DIMENSIONS: 770 X 510 DIMENSIONS: 580 X 510 1 - Cooking area Ø 160 (1600 W) 2 - Cooking area Ø 220 (2200 W - Booster 3000 W) 3 - Cooking area Ø 190 (1800 W - Booster 2800 W) 4 - Cooking area Ø... -
Page 4: Appliance Operation
SECURITY AND CARE DIRECTIONS Appliance operation: • Make sure that the cooking vessel is externally clean and dry (not greasy) before placing it on the hob. • To avoid damage to persons and fittings read this • Never use vapor devices. The vapor pressure directive carefully before using the hob for the first could damage the surfaces and components time. - Page 5 SECURITY AND CARE DIRECTIONS electrical system before repairing it. • Do not put object with a magnetic nature near the • If there are cracks on the ceramic surface, hob, like credit cards, floppy disks, calculators. disconnect the electricity of the appliance The hobs functions could be compromised as a immediately.
-
Page 6: Installation
INSTALLATION General Instructions refer to the installation diagrams. • The installation of the hob in non-stationary places (i.e.: a ship) must be by skilled technicians to • The installation of the appliance must only be done guarantee appliance safety. by a qualified technician. Refer to a technician •... - Page 7 INSTALLATION 77 CM CERAMIC HOB (30”) Hob: W 770 mm D 510 mm W 30.3 Inches 20 Inches Cut-out W 750 mm D 490 mm W 29.5 Inches 19.3 Inches 58 CM CERAMIC HOB (23”) Hob: W 580 mm D 510 mm W 22.8 Inches 20 Inches Cut-out...
-
Page 8: Electrical Connection
INSTALLATION Attention: To guarantee that the appliance is functioning correctly it is important to provide a surface, during the installation, of a minimum 4 mm spacer for the length of the recess on the front side of the furniture. This is required to assist the electrical controls should temperatures reach over 85°C, where upon the hob controls will automatically turn the appliance off until the temperature returns under the limit... -
Page 9: Start And Use
START AND USE Practical advise for the appliances • Use flat bottom pots with elevated thickness to be sure that these perfectly adhere to the heating use and for best performance: areas. • Use cooking vessels which are compatible with the induction principle (ferromagnetic material). -
Page 10: Booster Function
START AND USE Switching on the applicance: Attention: The “Booster” function brings the power to 3000W for the Ø 220 and to 2800W for the Ø 190. The hob switches on by selecting the n°5 sensor This means that during the operation, the front on the controls area. -
Page 11: Automatic Switch-Off
START AND USE Timer running with cooking areas Switching off the Appliance You can use the timer on all cooking areas, To switch off the appliance it is necessary to push however they can operate only one at a time. To on n°5 sensor. - Page 12 CARE AND CLEANLINESS Never use vapour machines to clean. with a wet cloth. If the cooking zones are switched on and there is residual detergent still there, these • The vapor can reach the electrical conductor could damage the ceramic. components and cause it to short-circuit.
-
Page 13: Problems And Solutions
PROBLEMS AND SOLUTIONS Listed below are some possible fault messages Afterheat for which professional technical support is For safety reasons this information is the most necessary: important: • If the hob is switched off, the zones which show Cooking zone temperature sensor the power are fixed on “H”. -
Page 15: Warranty
Warranty Porter&Charles products are designed and built to the highest standards. We expect your appliances to provide many years of trouble free enjoyment. In the event of an appliance requiring attention, each appliance is covered by a 2 year warranty from the date of purchase. Refer to warranty policy for complete terms and conditions. - Page 16 Porter & Charles Incorporated Telephone 1-866.699-4973 Telephone 905-829.8389 Facsimile 905-829.8409 Email sales@porterandcharles.com...
