Sanyo DC-F430AV Service Manual

-
IFILE No.
Service Manual
1
. . .
Contents
Mini Component System
DC"F430AV
(AU)
Specifications ................................................................... 1
What to do if ..................................................................... 1
Laser beam safety precaution .......................................... 2
Removal and installation ..................................................2
CD changer opration and description ..............................4
CD chenger replacement .................................................6
CD mechanism adjustments ............................................8
c CD pickup maintenance .................................................. 10
CD player adjustments ..................................................... 10
Tape deck adjustments .................................................... 12
Tuner adjustments ........................................................... 14
Exploded view
(Cabinet & Chassis) ...................................................... 15
(Tape mechanism) ........................................................24
(CD changer mechanism 1/2 ) ...................................... 25
(CD changer mechanism 2/2 ) ...................................... 27
(CD base mechanism) ..................................................28
Parts list
(Cabinet & Chassis) ...................................................... 16
(Tape mechanism) ........................................................23
(CD changer mechanism) .............................................26
(CD base mechanism) ..................................................28
PRODUCT CODE
No.
12953005
IC block diagram ..............................................................29
FL display& description ...................................................38
Schematic diagram
(CD) ...............................................................................4l
(DEcK) ..........................................................................43
(FRONT) .......................................................................47
(TUNER) .......................................................................5l
(PRE AMPLIFIER) ........................................................55
(POWER AMPLIFIER) ..................................................57
Wiring diagram
(CD) ...............................................................................4O
(DEcK) ..........................................................................45
(FRONT) .......................................................................49
(TUNER & PRE AMPLIFIER) ........................................ 53
(POWER AMPLIFIER) ..................................................59
Wiring connection
............................................................ 61
IC & Transistor voltages ................................................... 62
--- --- --- --- --- --- --- --- -
'This service manual consists of "DC-F430AVU" (Main unit),
I
1
~RB-F430AV" (Remote control), "SX-F430, SX-CE430, SX-SR430" (Speaker system)u
'i-
--- --- --- --- --- --- --- --- -
REFERENCE
No.
SM580918
