Summary of Contents for Lynx L27

Page 1 User Manual / Installation Instructions Professional Series Grills & Side Burners Models L27(F)(R) L 30(F)(R) L36(F)R L42(F)R L5430(F)R2B L54PS(F)R LSB1&2, LCB1&2 CS 30 (F) LDR 18/21/27/30/36/42/54 LIJ 27/30/36/42/54 ProSear Models w/ IR Main Burners Side Burner Models L 30(A)PS(F)R LSB1, LSB2...
Page 2: Table Of Contents
Table of Contents Safety Practices & Precautions..................Leak Testing......................... Locating the Grill......................... Utility Requirements......................Features and Identification ....................Lighting Instructions......................Match Lighting........................Burner Adjustments......................Using the Grill........................Using the Smoker........................ Using the Rotisserie......................Burner Removal and Cleaning................... ProSear Supplement......................Side Burners........................Service..........................
Page 3: Safety Instructions
Safety Instructions WARNING! Read this manual carefully and completely before using your grill to reduce the risk of fire, burn hazard or other injury, making sure of proper installation and servicing. AVERTISSEMENT FOR YOUR SAFETY If you smell gas: S’il y a une odeur de gaz: 1.
Page 4: Safety Practices & Precautions
Safety Practices & Precautions FOR YOUR SAFETY: 1. Never use natural gas in a unit designed for liquid propane or visa versa. 2. If you smell gas: A. Shut off gas to the appliance. B. Extinguish any open flames. C. Open lid. D.
Page 5 18. Be aware that cooking excessively fatty meats and other such products will cause flareups. Internal fires or damage caused by flare-ups or the grill being left unattended while cooking, are not the responsibility of LYNX and any resulting damage is not covered under the terms and conditions of our Warranty.
Page 6 Safety Practices & Precautions 24. Do not use the grill until a leak check has been performed (see page 6). 25. Do not move grill while in use or hot. 26. Never place more than 30 pounds on a side shelf. Do not lean on shelves. 27.
Page 7: Leak Testing
Leak Testing LP Gas Leak Check Natural Gas Leak Check 90°x1/2” Check points Street Elbow Check hose for 1/2” NPT Nipple signs of abrasion Regulator supplied by others) cracks and leaks Adapter supplied by others) LP Tank Shut-off Valve (supplied by others) DANGER: To prevent fire or explosion hazard: NO SMOKING.
Page 8: Locating The Grill
If the grill is to be placed into a combustible enclosure, an approved insulated jacket is neces- sary and is available from your LYNX dealer. Use only a LYNX insulated jacket as it has been designed and tested specifically for your Grill. Refer to page 8 for cutout dimensions.
Page 9 Allow min. 4” clearance between left side of grill or side burner for bat- tery access. Rev. 04/2005...
Page 10: Utility Requirements
Utility Requirements PROPANE (LP) or NATURAL GAS ONLY Your grill is equipped to use either propane (LP) or natural gas (NAT). It is very important that the grill rating plate agrees with that of the gas supply. The rating plate is located either under the drip tray, the heat shield behind the front panel (remove smoker tray) or on the inside left cabinet wall (most freestanding grills).
Page 11 Utility Requirements L.P. Tank Requirements: A dented or rusty L.P. tank may be hazardous and should be checked by your L.P. supplier. Never use a cylinder with a damaged valve. Always check for leaks after every L.P. tank change. The L.P. gas cylinder must be constructed and marked in accordance with the specifica- tions for L.P.
Page 12 Utility Requirements Electrical Requirements for Built-in Units: Installation should include an outdoor 120VAC 15A GFI electrical outlet located adjacent to the grill. Do not locate motor or outlet on the same side as a Side Burner unless a minimum of 12” clearance is provided. Simply plug in the electrical cord from the transformer provided, into a GFI equipped outdoor outlet.
Page 13 Features and Identification Ignition Switch 30” Professional 42” Professional Smoker Rotis Grill Grill Smoker Rotis Grill Grill Smoker Smoker Grill Light Light Tray Tray Switch Switch Safety Ignition Safety 54” Professional Valve Switch Valve Ignition Switch Rotis Grill ProSear Light Rotis Grill Grill...
Page 14: Features And Identification
Features and Identification Replacing Ignition Batteries Professional and Premier Models Locating the battery: The battery is located in a sealed compartment on the left-hand side of the control panel. To change the battery: 1. Disengage the battery compartment by pushing the battery cover up on Professional models and towards the front of the grill on Premier models (as shown).
Page 15 Features and Identification Flip-over Shelves Cart Features (Professional Models only) Locking Casters Lift-Off Doors Briquette Placement 27” & 36” Models: 28 briquette per tray Note: All Models Place briquette over each round hole as shown Professional 30”: 35 briquettes per tray and ensure they are positioned between the raised slots in the tray Professional 42”: 28 briquettes middle tray...
Page 16 Features and Identification Hood Thermometer Professional Series Only: All Professional Series Grills are equipped with a hood ther- mometer. This thermometer will provide an indication of tempera- tures within the grill. Temperature readings are affected by open- ing and closing the hood and only indicate general temperatures in the grill cooking area.
Page 17: Lighting Instructions
Lighting Instructions WARNING! Before lighting: Prior to using grill please remove tie down wires on brass burners. Inspect the gas supply piping or hose prior to turning the gas "on". If there is evidence of cuts wear, or abrasion, it must be replaced prior to use. The replacement pressure regulators and hose assembly must be the type specified by the man- ufacturer.
Page 18: Match Lighting
Match Lighting Match Lighting: If burners will not light after several attempts, the burners can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Grill Burners: Make sure all knobs are in the OFF position. Keep your face as far away from the grill as possible.
Page 19: Burner Adjustments
Burner Adjustments Burner Air Adjustment: Each grill burner is tested and adjusted at the factory prior to shipment; however, varia- tions in the local gas supply or a conversion from one gas to another may make it necessary to adjust the burners. The flames of the Grill burners should be visually checked and compared to that of the drawing below.
Page 20: Using The Grill
Using The Grill Using The Grill: Grilling requires high heat for searing and proper browning. Most foods are cooked at the "HI" heat setting for the entire cooking time (with the lid open). However, when grilling large pieces of meat or poultry, it may be necessary to turn the heat to a lower setting after the initial browning.
Page 21 Using The Grill Using the Smoker (continued): Units equipped with Rotis Smoker Tray (not all models) the optional Rotisserie include a smoker/flavor tray locat- ed beneath the Infra-Red Rotis Burner. After deciding which wood chips to use (see chart below), soak them in water then place them into the tray.
Page 22: Using The Rotisserie
Using The Rotisserie General: The location of the rotis burner makes it more susceptible to strong wind conditions, more so than the protected grill burners. For this reason you should avoid operating the rotis during windy conditions. As an added safety feature we’ve equipped the burner with an automatic safe- ty valve which will not allow gas to flow to the rotis burner unless the following conditions are present with the knob on: 1.
Page 23: Burner Removal And Cleaning
Burner Removal & Cleaning Stainless Steel: The grill is made from non-rusting and non-magnetic stainless steel. After initial usage, areas of the grill may discolor from the intense heat given off by the burners, this is normal. There are many different stainless steel cleaners available. Always use the mildest cleaning procedure first, scrubbing in the direction of the grain.
Page 24: Orifice Cleaning
Burner Removal & Cleaning Orifice Cleaning: With the burner removed, remove the orifice and shine a flashlight through the opening to ensure there is no blockage. Use a needle to clear any debris. Be extremely careful not to enlarge the hole or break off the needle Grill Rack Ceramic briquette Reassemble The Burners:...
Page 25: Prosear Supplement
Supplement ProSear Models L 30(A)PS(F)R L 42 PS(F)R L54PS(F)R L30PSPOD LPSGE (ProSear Grill Extender) Rev. 04/2005...
Page 26 Supplement ProSear Models SAFETY INSTRUCTIONS WARNING! Read the ‘User Manual / Installation Instructions’ carefully and completely before using your grill to reduce the risk of fire, burn hazard or other injury, making sure of proper Installation and servicing. ProSear Infrared Grill The ProSear Grill has some special components and warnings specific to its’...
Page 27: Lighting The Grill
Supplement ProSear Models Lighting Instructions Purging the Grill When lighting the grill for the first time or after switching LPG tanks it is necessary to purge the gas train. Once the gas connection is complete check that all knobs are turned off. (for LPG, slowly open the valve on the tank.) Open the lid and turn the Rotiss.
Page 28: Burner Cleaning
Supplement ProSear Models Match Lighting: If burners will not light after several attempts, the burners can be match lit. If you had already attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate prior to lighting with match.
Page 29: Side Burners
Lynx Side Burners & ProSear Grill Extender Models LSB1, LSB2 - Built In Burners LPSGEKIT - Cabinet Mtg. Kit LPSGEBKT - Premier Grill Adapter LCB1, LCB2 LSB2PC - Two Burner Prep Center LPSGE - ProSear Grill Extender Rev. 04/2005...
Page 30 Lynx Side Burners & Grill Extender MOUNTING THE SIDE BURNER / GRILL EXTENDER TO A CART 1.Remove the components and hardware for Cart Mount Adaptor Kit (LPSGEKIT) from carton. Contents include the following: · Adaptor cabinet (3 sided) · Rear panel ·...
Page 31 Lynx Side Burners & Grill Extender MOUNTING THE SIDE BURNER / GRILL EXTENDER TO A CART (continued) 7b. When mounting the ProSear Grill Extender (LPSGE) or Side Burner (LSB1 / LSB2) to a 27" or 36" freestanding grill the plumbing must thread through the hole second from the rear of the cabinet.
Page 32 Lynx Side Burners & Grill Extender MOUNTING THE ProSear GRILL EXTENDER OR SIDE BURNER TO YOUR FREE STANDING GRILL 1.Remove right-hand side shelf that is attached to the grill cart. 2.Remove the rear access panel from the freestanding grill cart and make primary plumbing connection.
Page 33 Lynx Side Burners & Grill Extender...
Page 34: Service
Lynx Side Burners & Grill Extender...
Page 35 Lynx Side Burners & Grill Extender Connecting Side Burners LP GAS HOOK-UP (see diagram on page 10) 1. Remove the rear access panel ( cart models only -4 screws) 2. Remove the propane hose assembly. 3. Remove the 90 degree elbow from the BBQ manifold.
Page 36 Lynx Side Burners & Grill Extender Rev. 04/2005...
Page 37 Lynx Side Burners & Grill Extender Rev. 04/2005...
Page 38 Lynx Side Burners & Grill Extender Lighting Instructions WARNING! Before lighting: Prior to using the side burners: Inspect the gas supply piping or hose prior to turning the gas "on". If there is evidence of cuts wear, or abrasion, it must be replaced prior to use.
Page 39: How To Obtain Service
Is there a power outage in the area (lights will not work)? Have you recently refilled the LP Tank? For warranty service, contact your local LYNX authorized service agency. Provide him with the Model Number, Serial Number, and date of installation, and a brief description of the problem. If...
Page 40: Warranty
Lynx will replace or repair parts found to be defective at no cost to the original purchaser. IV. Service & Replacement Parts. Call (888) 289-5969 to report service problems or to obtain replacement components or parts for your Lynx grill.
Page 41 No one has the authority to add to or vary Lynx’s warranty, or to create for Lynx any other obligation or liability in connection with the sale or use of its products.
Page 42: A Message To Our Customers
A MESSAGE TO OUR CUSTOMERS: Thank you for choosing LYNX as your new gas grill. With proper use and care, we’re confident that this Grill will provide years of trouble-free service. Careful attention has been put into every detail of this grill and, by reading this entire manual before your first use, you will be assured maximum performance.
