SERVICE MANUAL
Ver 1.1 2004. 05
Amplifier section
Stereo mode
TE
L 13942296513
Surround mode
* Depending on the source, there may be no sound output.
Inputs (Analog)
Inputs (Digital)
Outputs (Analog)
Outputs (Digital)
CD/DVD system
Laser
Signal format system
Frequency response (at 2 CH STEREO mode)
Signal-to-noise ratio
www
Harmonic distortion
.
Sony Corporation
9-877-629-02
Home Audio Company
2004E02-1
Published by Sony Engineering Corporaton
© 2004.05
http://www.xiaoyu163.com
40 W + 40 W (8 ohms at 1 kHz, THD 0.7 %)
Front: 40 W + 40 W (THD 0.7 %)
Center*: 40 W
Rear*: 40 W + 40 W (8 ohms at 1 kHz, THD
0.7 %)
VIDEO 1, VIDEO 2, TV-AUDIO:
Sensitivity: 150 mV
Impedance: 50 kilohms
VIDEO 2 (Optical):
Sensitivity: –
VIDEO 1 (AUDIO OUT):
Voltage: 2 V
Impedance: 1 kilohms
SUBWOOFER AUDIO OUT:
Voltage: 3 V
Impedance: 1 kilohms
PHONES:
Accepts low- and high-impedance
headphones
DIGITAL OUT OPTICAL (CD/DVD)
Sensitivity: –
Semiconductor laser
(CD: λ = 780 nm, DVD: λ = 650 nm)
Emission duration: continuous
NTSC/PAL
DVD (PCM): 20 Hz to 20 kHz (+0.5 dB, -3.0
dB)
CD: 20 Hz to 20 kHz (+0.5 dB, -3.0 dB)
More than 75 dB (VIDEO 1 (AUDIO)
connectors only)
Less than 0.5 %
x
ao
u163
y
i
http://www.xiaoyu163.com
AVD-LS10
2 9
8
Model Name Using Similar Mechanism
Mechanism Type
Base Unit Name
Optical Pick-up Name
SPECIFICATIONS
FM tuner section
System
Q Q
3
6 7
1 3
1 5
Tuning range:
Antenna
Antenna terminals
Intermediate frequency
AM tuner section
System
Tuning range
North American model:
Antenna
Intermediate frequency
Video section (EURO AV)
Outputs
General
Power requirements
Power consumption
Dimensions (approx.)
Mass (approx.)
Operating temperature
Operating humidity
Supplied accessories
AUDIO CD/DVD RECEIVER
co
.
9 4
2 8
AEP Model
UK Model
DP-5RM
PLL quartz-locked digital synthesizer system
0 5
8
2 9
9 4
2 8
87.5 – 108.0 MHz (50 kHz step)
FM wire antenna
75 ohms, unbalanced
10.7 MHz
Tuner section:
PLL quartz-locked digital synthesizer system
531 – 1,602 kHz (with the interval set at 9 kHz)
Loop antenna
450 kHz
Video: 1 Vp-p 75 ohms
230 V AC, 50/60 Hz
70 W
1.3 W (in the standby mode)
430 x 83 x 355 mm (17 x 3 x 14 inches) (w/h/d)
incl. projecting parts
5.0 kg (11 lb 7 oz)
5°C to 35°C (41°F to 95°F)
5 % to 90 %
See page 14.
— Continued on next page —
