Icom IC-R20 Service Manual page 25

Communications receiver
Hide thumbs Also See for IC-R20:
Table of Contents

Advertisement

• RF UNIT BOTTOM VIEW
• BFO CHECK POINT (LOGIC UNIT TOP VIEW)
• RF UNIT TOP VIEW
L105
Center voltage adjustment (B-BAND)
CP11
Center voltage check point (B-BAND)
L21
Center voltage adjustment (A-BAND)
CP1
Center voltage check point (A-BAND)
5 - 3
CP18
Reference frequency check point
BFO check point
