- Page 1 Viking Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Built-In Gas Cooktops F20334G EN (111008J)
-
Page 2: Important: Please Read And Follow
IMPORTANT: PLEASE READ AND FOLLOW 1. Before beginning, please read these instructions completely and carefully. DESCRIPTION VGSU103 (30” W.) VGSU163 (36” W.) 2. Do not remove permanently affixed labels, warnings, or plates from product. This may void the warranty. Cutout Width - Minimum 26-7/8”... -
Page 3: Proximity To Side Cabinets
PROXIMITY TO SIDE CABINETS DESCRIPTION DGSU100 (30” W.) DGSU160 (36” W.) Cutout Width - Minimum 29-1/8” (74.0 cm) 34-7/8” (88.6 cm) 1. The cooktop may be installed directly to existing base cabinets. Maximum 29-7/8” (75.9 cm) 35-7/8” (91.1 cm) 2. The cooktop CANNOT be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other side vertical Cutout Height - Minimum 3-1/8”... -
Page 4: Wall Installation
CUTOUT DIMENSIONS FOR VGSU AND DOWNDRAFT The bottom of the hood should be 30” (76.2 cm) min. to 36” (91.4 cm) above the countertop.This would typically VGSU103 VGSU163 result in the bottom of the hood being 66” (167.6 cm) to 72” (182.9 cm) above the floor. Refer to the rangehood... - Page 5 34-3/8” 3” 3” (73.3 cm) (87.3 cm) (7.6 cm) min. (7.6 cm) min. 5” (12.7 cm) 18-5/8” VGSU163 18-5/8” VGSU103 (47.3 cm) 36” min. cutout (47.3 cm) 30” min. cutout 6-19/32” (16.7 cm) 12-1/4” 14-5/8” 16-7/8” 17-9/16” 2-1/2” (6.4 cm) (37.2 cm)
- Page 6 DGCU CUTOUT DIMENSIONS 30” W. DGCU Top Dimensions Cutout 21“ 19-3/4” Opening (53.3 cm) (50.2 cm) Min. Max. 30” W. 28-3/4” (73.0 cm) 29-7/8” (75.9 cm) 30-3/4” (78.1 cm) 36” W. 34-1/2” (87.6 cm) 35-7/8” (91.1 cm 45” W. 42-7/8” (108.9 cm) 44-1/8”...
- Page 7 DGSU CUTOUT DIMENSIONS 30” W. DGSU TOP AND HEIGHT DIMENSIONS 21“ (53.3 cm) Cutout 19-3/4” (50.2 cm) Minimum Opening 20-1/8” (51.1 cm) Maximum 30-3/4” (78.1 cm) 4-3/8” 3-1/8” (13.7 cm) (7.9 cm) Min. Max. 1-3/4” 30” W. 29-1/8” (74.0 cm) 29-7/8”...
-
Page 8: Gas Connection
INSTALLATION OF HOLD DOWN BRACKET GAS CONNECTION FOR DGCU AND DGSU MODELS The gas supply (service) line must be the same size or greater than the inlet line of the appliance. All cooktops use a Top of cooktop 1/2” (1.3 cm) I.D. NPT (Sch40) inlet. Sealant on all pipe joints must be resistive to LP/Propane gas. 1. - Page 9 ELECTRICAL CONNECTION There is no connection necessary beyond plugging the unit into a polarized, grounded, 120 volt, 60 Hz, 15 amp circuit. A minimum of 120VAC is required for proper operation of gas ignition systems. DO NOT USE a GFI circuit. This circuit, however, MUST be grounded and properly polarized.
