  • Page 1 BI440ZX Motherboard Product Guide Order Number: 726091-001...

  • Page 2: Revision History

    Disclaimer Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Intel assumes no responsibility for any errors that may appear in this document.

  • Page 3: Table Of Contents

    Contents 1 Motherboard Features Feature Summary ........................ 7 Components......................... 8 Microprocessor........................9 Main Memory ........................9 PCI Enhanced IDE Interface ....................10 Input/Output (I/O) Controller....................10 Real-Time Clock........................11 USB Support ........................11 Accelerated Graphics Port (AGP)..................12 BIOS ...........................12 Expansion Slots........................12 Power Management ......................13 Battery ..........................13 Wake on Ring / Resume on Ring Technologies (Optional)..........13 †...
  • Page 4 Contents 1 Motherboard Features Feature Summary ........................ 7 Components......................... 8 Microprocessor........................9 Main Memory ........................9 PCI Enhanced IDE Interface ....................10 Input/Output (I/O) Controller....................10 Real-Time Clock........................11 USB Support ........................11 Accelerated Graphics Port (AGP)..................12 BIOS ...........................12 Expansion Slots........................12 Power Management ......................13 Battery ..........................13 Wake on Ring / Resume on Ring Technologies (Optional)..........13 Wake on LAN Technology....................14...
  • Page 5 BI440ZX Motherboard Product Guide 4 Technical Reference Motherboard Connectors.....................33 Back Panel Connectors ....................34 Midboard Connectors ....................35 Front Panel Connector....................36 Jumper Blocks........................37 BIOS Setup Configuration Jumper Block ..............37 USB Port 0 Configuration Jumper Block (Optional).............38 A Error Messages BIOS Beep Codes .......................39 BIOS Error Messages ......................39...
  • Page 6 Contents Beep Codes........................39 BIOS Error Messages....................39 Safety Regulations .....................41 EMC Regulations......................41...
  • Page 7 BI440ZX Motherboard Product Guide...

  • Page 8: Motherboard Features

    1 Motherboard Features This chapter gives a feature overview of the BI440ZX motherboard. The remaining chapters discuss: How to add or upgrade components like processors or memory How to invoke the BIOS Setup program to modify the motherboard’s configuration How to upgrade the BIOS...

  • Page 9: Components

    Digital Controller (optional) Battery AGP connector Diskette drive connector Intel 82443ZX PAC IDE connectors PCI bus add-in card connectors Intel 82371EB PIIX4E ISA bus add-in card connector Figure 1. Motherboard Components NOTE Components labeled optional do not come on all BI440ZX motherboards.

  • Page 10: Microprocessor

    For information about Refer to Installing a processor Page 17 Processor support for the BI440ZX motherboard http://support.intel.com/support/motherboards/desktop Main Memory The motherboard has two sockets for installing DIMMs. Minimum memory size is 16 MB; maximum memory size is 256 MB. The motherboard supports the following memory features:...

  • Page 11: Pci Enhanced Ide Interface

    Refer to The location of the IDE connectors Figure 13, page 35 The PIIX4E PCI IDE controller BI440ZX Motherboard Technical Product Specification available through: http://support.intel.com/support/motherboards/desktop Input/Output (I/O) Controller The I/O controller handles the exchange of information between the processor and external devices like the mouse and keyboard or a printer that are connected to the computer.

  • Page 12: Real-Time Clock

    The recommended method of accessing the date in systems with Intel motherboards is indirectly from the Real-Time Clock (RTC) via the BIOS. The BIOS on Intel motherboards and baseboards contains a century checking and maintenance feature that checks the least two significant digits of the year stored in the RTC during each BIOS request (INT 1Ah) to read the date and, if less than 80 (i.e., 1980 is the first year supported by the PC), updates the century byte to 20.

  • Page 13: Accelerated Graphics Port (Agp)

    For information about Refer to The location of the AGP connector Figure 1, page 8 BI440ZX Motherboard Technical Product Specification Features of the AGP interface available through: http://support.intel.com/support/motherboards/desktop BIOS The motherboard’s system BIOS is contained in a flash memory device on the motherboard. The BIOS provides the power-on self test (POST), the BIOS Setup program, and the PCI and IDE auto- configuration utilities.

  • Page 14: Power Management

    APM support. For information about Refer to How the board supports APM and ACPI BI440ZX Motherboard Technical Product Specification available through: http://support.intel.com/support/motherboards/desktop Battery A battery on the motherboard keeps the clock and the values in CMOS RAM current when your computer is turned off.

  • Page 15: Wake On Lan † Technology

    The location of the Wake on LAN technology Figure 13, page 35 connector Wake on LAN technology BI440ZX Motherboard Technical Product Specification available through: http://support.intel.com/support/motherboards/desktop CAUTION For Wake on LAN, the 5-V standby line for the power supply must be capable of delivering +5 V 5 % at 720 mA.

  • Page 16: Installing And Replacing Motherboard Components

    2 Installing and Replacing Motherboard Components This chapter tells you how to: Install and remove the motherboard Install and remove the processor Install and remove memory Replace the battery Before You Begin CAUTION Before you install this motherboard in a chassis, see Appendix B for regulatory requirements and precautions.

  • Page 17: How To Install And Remove The Motherboard

    BI440ZX Motherboard Product Guide How to Install and Remove the Motherboard Refer to your chassis manual for instructions on installing and removing the motherboard. The motherboard is secured to the chassis by eight screws. Figure 2 shows the locations of the mounting screw holes.

  • Page 18: How To Install A Celeron ™ Processor

    Installing and Replacing Motherboard Components ™ How to Install a Celeron Processor To install a processor, follow these instructions: 1. Observe the precautions in “Before You Begin” (see page 15). 2. Raise the socket handle completely (see Figure 3). Figure 3. Raising the Socket Handle 3.

  • Page 19: Closing The Handle

    BI440ZX Motherboard Product Guide 4. Close the handle completely (see Figure 5). Figure 5. Closing the Handle 5. Peel back the plastic cover from the thermal interface on the bottom of the fan heatsink. Place the fan heatsink on top of the processor (see Figure 6).

  • Page 20: Attaching The Fan Heatsink Clip

    Installing and Replacing Motherboard Components 6. Attach the fan heatsink clip to the processor socket (see Figure 7). Fan Heatsink Clip Processor Socket Figure 7. Attaching the Fan Heatsink Clip 7. Connect the processor fan cable to the processor fan connector (see Figure 8). OM07491 Processor Fan Cable Processor Fan Connector...

  • Page 21: How To Remove A Celeron Processor

    The BIOS detects the size and type of installed memory. NOTE All memory components and DIMMs used with the BI440ZX motherboard must comply with the PC SDRAM Specifications. These include: the PC SDRAM Specification (memory component specific), the PC unbuffered SDRAM Specifications, and the PC Serial Presence Detect Specification.

  • Page 22: How To Remove Memory

    Installing and Replacing Motherboard Components 7. Insert the bottom edge of the DIMM into the socket (as shown in Figure 9). 8. When the DIMM is seated, push down on the top edge of the DIMM until the retaining clips snap into place.

  • Page 23: How To Replace The Battery

    BI440ZX Motherboard Product Guide How to Replace the Battery When your computer is turned off, a lithium battery maintains the current time-of-day clock and the values in CMOS RAM current. Figure 10 on page 23 shows the location of the battery.

  • Page 24: Removing The Battery

    Installing and Replacing Motherboard Components To replace the battery, follow these steps: 1. Observe the precautions in “Before You Begin” (see page 15). 2. Turn off all peripheral devices connected to the computer. Turn off the computer. 3. Remove the computer cover. 4.
  • Page 25 BI440ZX Motherboard Product Guide...

  • Page 26: Using The Bios Setup Program

    Change the BIOS language Clear passwords For information about Refer to The BIOS Setup program’s menus, options, and BI440ZX Motherboard Technical Product Specification defaults settings available through: http://support.intel.com/support/motherboards/desktop NOTE For reference purposes, you should write down the current Setup settings. When you make changes to the settings, update this record.

  • Page 27: Function Keys

    BI440ZX Motherboard Product Guide NOTE The Setup menus described in this section apply to BI440ZX motherboards with BIOS identifier 4B4IZOXA.86A. Motherboards with other BIOS identifiers might have differences in some of the Setup menu screens. Table 4 is an overview of the menu screens in the BIOS Setup program.

  • Page 28: How To Upgrade The Bios

    BIOS recovery files ® Intel Flash Memory Update Utility You can obtain the BIOS upgrade file through your computer supplier or from the Intel World Wide Web site: http://support.intel.com/support/motherboards/desktop/ NOTE Please review the instructions distributed with the update utility before attempting a BIOS upgrade.

  • Page 29: Creating A Bootable Diskette

    BIOS.EXE file and type: BIOS.EXE BIOS A: 8. Press <Enter> 9. The diskette now holds the new BIOS files, the Intel Flash Update Utility, and the recovery files.

  • Page 30: Performing The Bios Upgrade

    Using the Setup Program Performing the BIOS Upgrade 1. Boot the computer with the BIOS upgrade diskette in drive A. Press to go to the <Enter> Main Menu. The flash memory update utility screen appears. 2. Select . Press Update flash memory area from a file <Enter>...

  • Page 31: How To Change The Bios Language

    You can use the BIOS upgrade utility to change the language the BIOS uses for messages and the BIOS Setup program. Use a bootable diskette containing the Intel Flash Memory Update Utility and language files (see “Performing the BIOS Upgrade” on page 29).

  • Page 32: How To Clear The Passwords

    Using the Setup Program How to Clear the Passwords This procedure assumes that the motherboard is installed in the computer and the configuration jumper block is set to normal mode. 1. Observe the precautions in “Before You Begin” (see page 15). 2.
  • Page 33 BI440ZX Motherboard Product Guide...

  • Page 34: Technical Reference

    The motherboard’s connectors can be divided into three groups, as shown in Figure 11. For information about Refer to Pin descriptions of the motherboard connectors BI440ZX Motherboard Technical Product Specification available through: http://support.intel.com/support/motherboards/desktop Back panel connectors (see page 34) Midboard connectors (see page 35)

  • Page 35: Back Panel Connectors

    BI440ZX Motherboard Product Guide Back Panel Connectors Figure 12 shows the back panel connectors on the motherboard. OM07465 † PS/2 keyboard or mouse G Serial port B PS/2 keyboard or mouse MIDI/Game port USB port 0 Audio line out USB port 1...

  • Page 36: Midboard Connectors

    Technical Reference Midboard Connectors Figure 13 shows the locations of the midboard connectors. OM07481 CD-ROM, legacy style, 2 mm (optional) Wake on Ring (optional) Video source line-in, blue (optional) Power supply fan control (optional) Auxiliary line in, natural (optional) SCSI LED (optional) Telephony, green (optional) Wake on LAN technology ATAPI CD-ROM, black (optional)

  • Page 37: Front Panel Connector

    BI440ZX Motherboard Product Guide Front Panel Connector Figure 14 shows the location of the front panel connector. 15 16 22 23 24 26 27 OM07470 Power switch Sleep/Resume switch Infrared port Hard drive activity LED Power LED Reset switch Offboard speaker...

  • Page 38: Jumper Blocks

    Technical Reference Jumper Blocks Figure 15 shows the location of the motherboard’s jumper blocks. CAUTION Do not move jumpers with the power on. Always turn off the power and unplug the power cord from the computer before changing jumper settings. Otherwise, the board could be damaged. OM07471 USB Port 0 configuration jumper block (optional) BIOS setup configuration jumper block...

  • Page 39: Usb Port 0 Configuration Jumper Block (Optional)

    BI440ZX Motherboard Product Guide USB Port 0 Configuration Jumper Block (Optional) This 6-pin jumper block enables configuration of USB Port 0. Table 7 describes the jumper settings for configuring USB Port 0. Table 7. USB Port 0 Configuration Jumper Settings...

  • Page 40: A Error Messages

    A Error Messages BIOS Beep Codes Whenever a recoverable error occurs during power-on self test (POST), the BIOS displays an error message describing the problem. The BIOS also issues a beep code (one long tone followed by two short tones) during POST if the video configuration fails (a faulty video card or no card installed) or if an external ROM module does not properly checksum to zero.
  • Page 41 BI440ZX Motherboard Product Guide Table 9. BIOS Error Messages (continued) Error Message Explanation Cache Memory Bad An error occurred when testing L2 cache. Cache memory may be bad. CMOS Battery Low The battery may be losing power. Replace the battery soon.

  • Page 42: B Regulatory And Integration Information

    B Regulatory and Integration Information This appendix contains: Safety standards, electromagnetic compatibility regulations, and product certification markings for this motherboard Instructions and precautions for integrators who are installing this motherboard in a chassis Regulatory Compliance This motherboard complies with the following safety and EMC regulations when correctly installed in a compatible chassis Table 10.

  • Page 43: Installation Precautions

    (94V-0) (Solder side) UL File Number for motherboards: E139761 (Component side) PB Part Number: Intel bare circuit board part number (Solder side) 720848-001 Battery “+ Side Up” marking: Located on the component side of the board in close proximity...

  • Page 44: Ensure Electromagnetic Compatibility (Emc)

    Appropriate protection is provided by a maximum 8-A current limiting circuit or a maximum 5-A fuse or positive temperature coefficient (PTC) resistor. All Intel motherboards now have PTCs on all external ports that provide DC power externally.

  • Page 45: Prevent Power Supply Overload

    BI440ZX Motherboard Product Guide Prevent Power Supply Overload Unless the power supply has inherent overcurrent protection, do not overload the power supply output. To avoid overloading the power supply, make sure that the calculated total current load of all the modules within the computer is less than the output current rating of the power supply. If you do not do this, the power supply could overheat, catch fire, or damage the insulation that separates hazardous AC line circuitry from low-voltage user accessible circuitry.
