Smartpond DP700UV Instructions Manual

Submersible pond pump with uv 700 gallons per hour
Hide thumbs Also See for DP700UV:
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, Manual
REMINDER
CALL 1-866-869-5300
BEFORE RETURNING TO STORE.

PACKAGE CONTENTS

Part
A
B
3/4-in. adapter with flow control

WARNINGS AND CAUTIONS

WARNING
•
Risk of electrical shock. This pump is supplied with a grounding conductor and grounding–type
attachment plug. To reduce the risk of electric shock, be certain that it is connected to only a properly
grounded, grounding-type receptacle (GFCI).
•
Do not exceed the voltage shown on the pump.
•
Always disconnect pump from the power source before beginning any maintenance or work on the
pump.
•
Inspect cord for damage before installation and/or maintenance. Replace the entire pump assembly if
damage is found.
•
Do not remove the grounding pin from the power cord plug.
•
To reduce the risk of electric shock, use only on portable, self-contained fountains no larger than 5 ft. in
any dimension.
•
Risk of electrical shock: This pump has not been investigated for use in swimming pools or marine
areas.
CAUTION
•
This pump has been evaluated for use with water only.
•
Use a proper power source as indicated on the pump label.
•
Keep the cord away from high temperatures or other heat sources.
•
Avoid using the pump when water temperatures fall below 41° F.
•
Do not use the pump in water exceeding 86° F.
•
Do not pump heated liquids.
•
Do not let the pump run dry. Pump must be completely submerged for proper operation and cooling.
•
Operate in fresh water only. Avoid heavily chlorinated water and water with high pH levels.
•
Do not lift the pump by its power cord.
Submersible Pond Pump with UV
700 Gallons Per Hour
Description
Pump
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-866-869-5300, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@smart-pond.com.
Quantity
1
1
1
MODEL/MODELO #DP700UV
B
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP700UV and is the answer not in the manual?

Questions and answers

Related Manuals for Smartpond DP700UV

Summary of Contents for Smartpond DP700UV

  • Page 1 Submersible Pond Pump with UV 700 Gallons Per Hour MODEL/MODELO #DP700UV REMINDER Questions, problems, missing parts? Before returning to your retailer, call our customer service department at CALL 1-866-869-5300 1-866-869-5300, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE.
  • Page 2 CAUTION • UV light may cause irritation to the skin and/or eyes. Avoid exposure. • DANGER – ULTRAVIOLET RADIATION – disconnect power before replacing lamp. • Prolonged or repeated exposure to UV light may have adverse physical effects including, severe damage to your skin and eyes.
  • Page 3 2. Remove the front screw, located on the bottom of the pump and the rear screw located in the center of the rear filter screen. Fig. 4 Fig. 4 3. Remove the front filter screen by firmly pressing in front of the discharge.
  • Page 4 5. Remove filter pad from front filter screen. Clear debris from filter pad by running under warm water. Fig. 7 Front cover Filter pad Fig. 7 6. Remove UV bulb assembly by gently pulling on cable connecting the bulb to the pump. Be careful to pull assembly straight out so as not to damage the UV assembly.
  • Page 5 10. Clean the pump housing where the UV assembly resides insuring that no debris remains. Fig. 12 Clean with soap Fig. 12 11. Remove the impeller cover to expose the impeller assembly. Remove the impeller assembly by gently pulling on the impeller blades.
  • Page 6 UV bulb Lamp holder O-ring Impeller cover Shaft support Washer Impeller assembly Shaft PUMP PERFORMANCE Flow Rates/Flujo (GPH) 12’ 11’ 10’ 9’ 8’ 7’ 6’ 5’ 4’ 3’ 2’ 1’ 0’ DP210 DP330 DP560 DP700UV Pond Pumps Printed in China...
  • Page 7 PL0710, PL1013, PL1320 lifetime ACFK and MFBX500P (pump only) 1 year PBF1200UV (UV filter only) 1 year WGK200 (pump only) 1 year DP700UV, WP1300UV 1 year DPKIS (pump only) 1 year EPDM1520, EPDM1525. EPDM2020 20 years 3 years Application Warranty covers only properly installed and maintained units. Pump warranty is limited to applications pumping fresh water at temperatures between 41°F ―...
