- Page 1 LED Colour Flood 10W / 30W RGB LED floodlight user manual...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 20.08.2012...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 7 Features............................... 12 Installation and starting up........................ 13 Components and functions........................ 16 Cleaning............................... 18 Technical specifications........................19 Protecting the environment......................20 LED Colour Flood 10W / 30W RGB... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a possible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 6 General notes Warning signs Type of danger Warning – suspended load. Warning – danger zone. LED floodlight...
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
- Page 9 Safety instructions WARNING! Eye damage caused by high light intensity Never look directly into the light source. WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. NOTICE! Risk of fire Do not block areas of ventilation.
- Page 10 Safety instructions NOTICE! Voltage supply Connect the device directly to the power grid. It must not be connected to a dimmer. Before connecting the device, you have to ensure that the rated voltage indicated on the device matches the voltage of the power grid available in the operating place.
- Page 11 Safety instructions NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. LED Colour Flood 10W / 30W RGB...
-
Page 12: Features
Features Features The LED floodlight is ideal for professional lighting applications, for example, at events, on stage, in theatres or discotheques Special features of the device: Infrared remote control White, basic colours red, green, blue and mixed colours are selectable Built-in automatic show programmes Suitable for outdoor application due to protection type IP65 LED floodlight... -
Page 13: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 14 Installation and starting up NOTICE! Risk of overheating The distance between the light output and the illuminated surface must be more than 0.5 m (19.7 in). Always ensure sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and...
- Page 15 Installation and starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. Inserting the battery into the Press the lock of the battery holder to the centre of the housing and pull out the battery holder remote control like a drawer.
-
Page 16: Components And Functions
Components and functions Components and functions Remote control 1 [ON]/[OFF] Buttons to switch the unit on or off. 2 Brightness control. 3 Colour selection buttons. Use the [W] button for white light, [R], [G] or [B] button for the basic colours red, green and blue, the coloured buttons to directly select a mixed colour. - Page 17 Components and functions 6 [FADE] Fast automatic change of all colours with blending effect. 7 [SMOOTH] Slow automatic change of all colours with blending effect. LED Colour Flood 10W / 30W RGB...
-
Page 18: Cleaning
Cleaning Cleaning Optical lenses Clean the exterior of accessible optical lenses periodically to optimise light output. The fre‐ quency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device. Clean with a soft cloth using normal glass cleaning products. -
Page 19: Technical Specifications
Technical specifications Technical specifications Item no. 274069 Item no. 274070 RGB multichip 10 W 30 W Dispersion 120 ° Battery (remote control) Lithium coin battery, CR 2025, 3 V Operating voltage supply AC 230 V , 50 Hz Power consumption 16 W 35 W Dimensions (W ×... -
Page 20: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 21 Notes LED Colour Flood 10W / 30W RGB...
- Page 22 Notes LED floodlight...
- Page 24 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
