- Page 1 Model 840/845 Contactless Smart Card Reader Installation Guide GE Interlogix, CASI Division 791 Park of Commerce Boulevard Suite 100 Boca Raton, Florida 33487 (561) 998-6100 Part Number: 460394001E October 2002...
- Page 2 Copyright 1999 - 2002 GE Interlogix All Rights Reserved Printed in the USA Proximity Perfect is a trademark of GE Interlogix. mifare 1 is a trademark of Philips. WARNING This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 3: Table Of Contents
Digital Input (Door Contact and Exit Request) Supervised F/2F Mode Only ................ 13 Testing the Reader ..................22 Troubleshooting Guide .................. 23 Technical Specifications ................. 26 Functional Specifications ................27 Regulatory Notices: ..................30 Models 840/845 Contactless Smart Card Reader... - Page 4 Figure 5: Wiring Diagram, Model 84x - Wiegand 4001 Mode ..16 Figure 6: Wiring Diagram, Model 84x - Unsupervised F/2F Mode ... Figure 7: Wiring Diagram, Model 84x - Omron/Magstripe Strobe Mode 20 Model 840/845 Contactless Smart Card Reader...
-
Page 5: Introduction
The 84x Reader is designed to mount on a standard U.S. single electrical gang box. The Model 845 is identical to the Model 840 except for a built-in twelve position keypad. This feature makes this reader ideal for installations requiring keypad PIN entry in addition to a valid smart card read. -
Page 6: Product Features
Product Features The CASI Model 840/845 Contactless Smart Card Reader offers the following features: • State-of-the-art architecture. ® • The ability to read all MIFARE 1 type Contactless Smart Cards. ® • The ability to read the unique serial number of a MIFARE 1 card and convert the hex format to twelve digits Binary Coded Decimal (BCD). -
Page 7: Installation Steps
The figures listed below begin on the next page. Refer to the appropriate figure for the type of reader you are mounting. Figure 1, “Model 84x Reader - Gang Box Mounting,” on page 4. Figure 2, “Model 84x Reader - Wall Mounting,” on page 5. Model 840/845 Contactless Smart Card Reader... -
Page 8: Figure 1: Model 84X Reader - Gang Box Mounting
FIGURE 1: Model 84x Reader - Gang Box Mounting Model 840/845 Contactless Smart Card Reader... -
Page 9: Figure 2: Model 84X Reader - Wall Mounting
FIGURE 2: Model 84x Reader - Wall Mounting Model 840/845 Contactless Smart Card Reader... -
Page 10: Connecting The Reader
The same functionality is provided by Proximity Perfect readers, "supervised" with four-conductor unshielded cable. Model 840/845 Contactless Smart Card Reader... -
Page 11: Pinouts
TABLE 2: Pinouts for Connector J2 J2 Pin Signal +12VDC Ground Green LED RS-232 Output No Connection Reader Data Reader Data 1 Door DI (Point) Door DI (Return) Exit DI (Point) Exit DI (Return) Model 840/845 Contactless Smart Card Reader... -
Page 12: Figure 3: Model 84X Reader, J2 Connector Location
FIGURE 3: Model 84x Reader, J2 Connector Location Model 840/845 Contactless Smart Card Reader... -
Page 13: Communications Settings
• 4 beeps = Wiegand 4001 • 5 beeps = RS-232 Remove power from the reader. Place a mini-jump over one (1) pin of JP4. Add power to the reader and resume normal operations. Model 840/845 Contactless Smart Card Reader... -
Page 14: Setting The Communications Mode (Casi Mode)
1 push = Supervised F/2F • 2 pushes = Unsupervised F/2F • 3 pushes = Strobe • 4 pushes = Wiegand 4001 • 5 pushes = RS-232 Wait 5 seconds and then remove power from the reader. Model 840/845 Contactless Smart Card Reader... -
Page 15: Setting The Communications Mode (Native Mode)
Simply repeat this step. Modes: • 1 push = Supervised F/2F • 2 pushes = Unsupervised F/2F • 3 pushes = Strobe • 4 pushes = Unused • 5 pushes = RS-232 Model 840/845 Contactless Smart Card Reader... - Page 16 Place a mini-jump over one (1) pin of JP4 and remove JP3. Add power to the reader and resume normal operations. NOTE: Mode 4 is not available in Native Mode. Beeping and flashing LEDs indicate that Mode 4 has erroneously been set in Native Mode. Model 840/845 Contactless Smart Card Reader...
-
Page 17: Digital Input (Door Contact And Exit Request) Supervised F/2F Mode Only
Wire the door contact/end-of-line resistors to pin JP2-8 and pin JP2-9. Install the exit request contact and the two end-of-line resistors (installer-supplied) at the contact. Wire the exit request/end-of-line resistors to pin JP2-10 and pin JP2-11. Model 840/845 Contactless Smart Card Reader... -
Page 18: Figure 4: Wiring Diagram, Model 84X - Supervised F/2F Mode
FIGURE 4: Wiring Diagram, Model 84x - Supervised F/2F Mode Model 840/845 Contactless Smart Card Reader... - Page 19 Model 840/845 Contactless Smart Card Reader...
-
Page 20: Figure 5: Wiring Diagram, Model 84X - Wiegand 4001 Mode
FIGURE 5: Wiring Diagram, Model 84x - Wiegand 4001 Mode Model 840/845 Contactless Smart Card Reader... - Page 21 Model 840/845 Contactless Smart Card Reader...
-
Page 22: Figure 6: Wiring Diagram, Model 84X - Unsupervised F/2F Mode
FIGURE 6: Wiring Diagram, Model 84x - Unsupervised F/2F Mode Model 840/845 Contactless Smart Card Reader... - Page 23 Model 840/845 Contactless Smart Card Reader...
-
Page 24: Figure 7: Wiring Diagram, Model 84X - Omron/Magstripe Strobe
FIGURE 7: Wiring Diagram, Model 84x - Omron/Magstripe Strobe Mode Model 840/845 Contactless Smart Card Reader... - Page 25 Model 840/845 Contactless Smart Card Reader...
-
Page 26: Testing The Reader
Observe that the reader beeps briefly and the yellow LED blinks off. Observe that the green LED turns on indicating a valid access has been granted by the host. Open the door. This verifies that the door strike operates correctly. Model 840/845 Contactless Smart Card Reader... -
Page 27: Troubleshooting Guide
Reconnect the wire on JP2 pin 3 and measure the voltage at JP2 pin 3. Low voltage turns on the green LED. If the voltage is low, check to see if the host system is energizing the door strike. Model 840/845 Contactless Smart Card Reader... - Page 28 If none of the above steps have identified the problem, there may be a significant noise source present in the installation which is interfering with the reader-to-microcontroller communications. If this is the case, use shielded wire for reader-to-microcontroller connections. Model 840/845 Contactless Smart Card Reader...
- Page 29 1K-ohm resistors to the door contact and the exit request inputs or, if the inputs are not used, that a 1K-ohm resistor is installed at the reader connector. See Figure 4, “Wiring Diagram, Model 84x - Supervised F/2F Mode,” on page 14. Model 840/845 Contactless Smart Card Reader...
-
Page 30: Technical Specifications
See Table 1 “Cable Distances,” on page 6. NOTE: The reader will work well with unshielded cable in most environments. No company, including GE Interlogix, can guarantee that data will be reliably transmitted over long distances on unshielded cable in every installation. -
Page 31: Functional Specifications
LED starts flashing slowly (every 2 seconds), and a short triple beep sounds every 30 seconds. Once the reader receives an acknowledgment, it begins reading smart cards again, the beeper stops sounding and the red LED stops flashing. Model 840/845 Contactless Smart Card Reader... - Page 32 Omron/Magstripe Strobe Mode Operation: The reader sends badge data ® to the microcontroller after a valid MIFARE 1 type contactless smart card is presented to the reader. This communications mode does not support the use of PIN codes. Model 840/845 Contactless Smart Card Reader...
- Page 33 To take full advantage of 4-state supervision and all available modes, the Secure Perfect firmware revision must be 2.14 or later and the Picture Perfect revision must be 1.57 or later. Model 840/845 Contactless Smart Card Reader...
-
Page 34: Declaration Of Conformity
Regulatory Notices: Manufacturers Declaration of Conformity Product Identification: Model/type :430134001 (Model 840, Contactless Smart Card Reader) BOM revision level :820=D :430135001 (Model 845, Contactless Smart Card Reader+Keypad) :825=D Category (description) :Contactless Smart Card Reader/Keypad Brand :GE Interlogix/CASI Manufacturer: GE Interlogix, CASI Suite 100 791 Park of Commerce Blvd.
