KB6600 Series
Programmable Keyboard
User' s Manual
Rev. Original
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is like ly to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty will terminate automatically when the machine is opened by any person other
than the author ized technicians. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
This manual is written in an attempt with full strength to assist the user to utilize
the powerful programmable keyboard KB6600 series which consists of a 6 positioned
electronic control key and 84 press keys whic h provides excellent tactile click when
pressed, and an optional magnetic stripe reader for ISO standards. The KB6600 not
only is capable of being programmed to transmit whatever code a standard PC or PS2
keyboard can deliver, but also provides a great variety of programmability such that
contains all capabilities of the most modern programmable keyboards.
The manufacturer of this product heartily apologizes to the user for reserving the right
to change or to modify this manual without notice due to the rapid and constant
progress and improvement on science and technology.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com
or
http://www.posiflex.com.tw
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2004
All brand and product names and trademarks are the property of their
respective holders.
Part 1
P/N: 19170900010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for POSIFLEX KB6600 Series
Summary of Contents for POSIFLEX KB6600 Series
- Page 1 The information in this manual contains only essential hardware concerns for general user and is subject to change without notice. Posiflex reserves the right to alter product designs, layouts or drivers without notification. The system integrator shall provide applicative notices and arrangement for special options utilizing this product.
-
Page 2: Package Contents
OVERVIEW SCOPE The KB6600 series is a series of powerful programmable keyboard suitable for application in PC compatible system, programmable without TSR under DOS, Win98/2000, Win XP embedded and Win XP Pro environment. This series provides 84 keys (max.) of a comfortable size 19 x 19 mm in 6 x 15... -
Page 3: Option List
Ø Posiflex product information CD Ø User’ s manual Ø Key cap (for single key) x 68 A. OPTION LIST MSR (ISO track 1 & 2, ISO track 2 & 3, ISO track 1, 2 & 3, or JIS I track 2 + JIS II) /pc... - Page 4 This numerical keypad is a set of “numerical keys” which is composed of 12 numerical keys each is preprinted with one from the set of “0”, “00”, “.”, “1”, “2”, “3”, “4”, “5”, “6”, “7”, “8” and “9” plus “-“, “+” and a double size “Enter”...
-
Page 5: Keyboard Construction
protuberance Springy wall Fig. 3-2 Fig. 3-3 Fig. 3-4 Single key Fig. 3-5 Numerical keys Double key Fig. 3-6 APPLICATION KEYBOARD CONSTRUCTION Power-on LED MSR indicator 6 position key 6 position key switch 15 x 6 push keys MSR slot Fig. - Page 6 electronic key can be turned to one of the following 6 positions: LP, L0, L1, L2, L3 and L4. It can only be taken out from the switch at positions L0 and L1. The purpose of this electronic key serves 3 folds: When the key is switched to (and extracted from) position L0, the whole keyboard output will be blocked off by hardware to work as a security measure.
-
Page 7: Programming The Keyboard
After completion of the “Setup”, there will be a program group “Posiflex Tools” in the program files. Clicking the program “Posiflex Programmable Keyboard” in this group will activate the KBW.EXE for the KB6600 series. Please select the right model when entering the program. Part 7... -
Page 8: Programmable Keyboard
PC or PST SYSTEM PROGRAMMABLE KEYBOARD EXT. KB PORT PC or PS2 KEYBOARD Fig. 5 - 1 Preparations PROGRAMMING UTILITY (KBM.EXE) QUICK REFERENCE GUIDE Please refer to our web site for every detail in programming these programmable keyboards. The following simplified guide severs as a concise tool for instant application. -
Page 9: Hardware Limitation
On the other hand, when the user wants to save the contents of a programmed keyboard, e.g. when he/she newly receives a programmable keyboard, to a file named “YYY.tpl”, he/she should type in following command in subdirectory “POSIFLEX.D”: Part 9... -
Page 10: Answer Back Code
In other words, transferring a file generated from other programmable keyboard to KB6600 series could mess up the data format inside KB6600 series, and vice versa. - Page 11 The so called “hot key” is a special combination of keys pressed on the standard PC or PS-2 keyboard. In KB6600 series, the “hot key” is defined as pressing and holding the left “Alt” key while pressing the “PRT SC” (“Print Screen”) key on the PC or PS-2 keyboard.
- Page 12 inputs in this mode. The maximum number of key presses acceptable to any key by “hot key programming” is 32. All the input from the standard PC or PS-2 keyboard in this mode will also be sent to the host computer. Exit “hot key programming”...
-
Page 13: Specifications
SPECIFICATIONS CONSTRUCTION: Spill-proof, 84 keys + 6 position control LED COLOR: Power on – Green MSR – Green & Red KEY SWITCH TYPE: membrane plus rubber dome KEY STROKE TRAVEL: 3.2 mm KEY TOP SIZE: 19 x 19 mm for normal keys (ivory) PREPRINTED KEYS: “.”, “00”, “0”... -
Page 14: Output Interface
OUTPUT INTERFACE: 6 pin DIN female connector: connect to host computer 6 pin mini DIN female connector: connect to input PS2 keyboard Connects to PC through Connects to PS2 CCBLA-055-1 keyboard MAGNETIC STRIPE READER: Decoder & interface Built in keyboard wedge interface Tracks......1 &... -
Page 15: Power Consumption
POWER CONSUMPTION: Voltage...... 5VDC±10% Current...... 125 mA max. (Model KB6600) 150 mA max. (Models KB6600M2, KB6600M2/3, KB6600M3, KB6600MJ) MECHANICAL: Dimension in mm..… … 346 mm x 210 mm x 57 mm Dimension in inches.… . 13.6” x 8.3” x 2.2” (W x D x H) ENVIRONMENTAL: Operating temperature..
