- Page 1 KB6000 SERIES 102 - KEY & QWERTY PROGRAMMABLE KEYBOARD USER’S MANUAL Rev. : Original...
- Page 2 SOME IMPORTANT NOTES FCC NOTES This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS OVERVIEW ........1 - 1 SCOPE . - Page 4 KEY TOP LABELING ......4 - 1 KEY TOP REPLACEMENT ..... . 4 - 2 SPECIFICATIONS .
-
Page 5: Overview
OVERVIEW A. SCOPE The KB6000 series is a very useful programmable keyboard suitable for application in PS2 keyboard port of a PC or compatible system and is particularly recommended for use in a Posiflex touch terminal such as a TP7000 system. It is programmable under DOS, or Windows98/NT/2000/XP environment. -
Page 6: Model Numbers & Layouts
Home PgUp PgDn 2. KB6200FR ° ² & é " ¦ è ç à @ ¨ £ Entré e ù ñ § > ñ < Inser Suppr ÿ ÿ Ctrl Alt Gr Ctrl 1 - 2 KB6000 Series User’s Manual... -
Page 7: Kb6200Gr
> •B •E ñ ‚ ¦ ¬ ‚³ ‚» ‚Ð ‚± ‚Ý ‚à ‚Ë ¥ – ‚ ‚ë ‚é ‚ß ÿ «e-Ô¸É ƒJƒ^ƒJƒi Ctrl ÿ Ctrl µ L ´« ´« ‚Ђ炪‚È ¥þ-Ô¸É ƒ••[ƒ}¦r KB6000 Series User’s Manual 1 - 3... -
Page 8: Kb6200Nl
& ¿ ª · ¦ ¬ ¡ Inicio Re Pá g º Ñ ¨ Ç Bloq Mayú s Av Pá g ´ ñ > ñ < Supr ÿ ÿ Ctrl Alt Gr Ctrl 1 - 4 KB6000 Series User’s Manual... -
Page 9: Kb6200Sv
-« Ãø ª÷ ¤k ¤ë ¤} ¤@ ÿ ÿ Ctrl Ctrl 11. KB6200UK ¬ " £ & Home PgUp Caps Lock PgDn ñ < > ¦ ñ ÿ ÿ Ctrl Alt Gr Ctrl KB6000 Series User’s Manual 1 - 5... -
Page 10: Kb6200Us
Double key with cap 5 pcs / pack Blank key 10 pcs / pack Single key top & key cap 10 set / pack Qwerty and numerical key tops 78 pcs / set 1 - 6 KB6000 Series User’s Manual... -
Page 11: Installation
Please follow instructions in TP7000 manual to fix the fixation tags to the base of TP7000 for holding KB6000 series keyboard. Align the cavities on bottom of KB6000 series to the fixation tags on TP7000 to hold the KB6000 in place after the cable connection completed. -
Page 12: Programming Setup
After completion of the “Setup”, there will be a program group “Posiflex Tools” in the program files. Clicking the program “Posiflex Programmable Keyboard” in this group will activate the KBW.EXE for the KB6000 series. Please select the right model when entering the program. D. PROGRAMMING SETUP Before using either “KBM.EXE”... -
Page 13: Programming The Keyboard
The CPU of keyboard detects the contact KB6000 Series User’s Manual 3 - 1... -
Page 14: Programming Utility (Kbw.exe)
“XXX.tpl”, which was saved before, to the programmable keyboard, he/she should type in following command in subdirectory “POSIFLEX.D”: RWM XXX.tpl (enter) This operation is quite recommended to be performed on a daily basis to ensure the system stability. 3 - 2 KB6000 Series User’s Manual... - Page 15 In other words, transferring a file generated from other programmable keyboard to KB6000 series could mess up the data format inside KB6000 series, and vice versa. KB6000 Series User’s Manual 3 - 3...
- Page 16 3 - 4 KB6000 Series User’s Manual...
-
Page 17: Application
Therefore making total key count in KB6000 one less from 102. The structure of KB6000 series allows free replacement of the key tops. The user may purchase single keys, double keys and blank keys in number required to arrange as wish the appearance of the progammable key area. - Page 18 “horizontally” aligned. The location for the key-definition to be programmed for the double key shall then be the bottom or the right position accordingly. 4 - 2 KB6000 Series User’s Manual...
- Page 19 0 - 140 msec COMMANDED TIME DELAY: programmable 0 - 240 sec OUTPUT INTERFACE: 6 pin DIN female connector: connects to host computer 6 pin mini DIN female connector: connects input keyboard KB6000 Series User’s Manual 5 - 1...
- Page 20 Storage temperature.... -20 C to + 70 C Relative humidity....90%, non-condensing Vibration......… 4G Shock........…. 40G RELIABILITY INFORMATION: Push key switch: .....…. 15,000,000 strokes min. Memory: ......…. 100 years min. APPLICABLE CONFORMITY: CE, FCC CLASS A 5 - 2 KB6000 Series User’s Manual...
