POSIFLEX PST KB136 Series User Manual
POSIFLEX PST KB136 Series User Manual

POSIFLEX PST KB136 Series User Manual

Qwerty keyboard

Advertisement

Quick Links

TM
PST KB136 SERIES
QWERTY KEYBOARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PST KB136 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX PST KB136 Series

  • Page 1 PST KB136 SERIES QWERTY KEYBOARD...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS OVERVIEW ..........1 - 1 SCOPE .
  • Page 4 COMMAND LISTING IN VIEW MODE ....4 - 6 COMMAND LISTING IN ASCII-CODE EDITING MODE ............4 - 7 COMMAND LISTING IN SCAN CODE EDITING MODE .
  • Page 5: Overview

    SCOPE The KB136 unit is the optional programmable keyboard segment within the PST systems replacing the original KB112. This keyboard provides in the lower part a “QWERTY” keyboard that resembles the standard PC keyboard and at the top a matrix of 3 by 17 locations for freely programming purpose. Nevertheless, there are 2 more programmable keys within the “QWERTY”...
  • Page 6: Model Numbers

    MODEL NUMBERS MODEL NUMBER COUNTRY / LANGUAGE PSTKBQRTY-FR French PSTKBQRTY-GR Germany PSTKBQRTY-IT Italy PSTKBQRTY-NL Netherlands PSTKBQRTY-PO Portugal PSTKBQRTY-SP Spain PSTKBQRTY-SV Sweden / Finland PSTKBQRTY-UK United Kingdom PSTKBQRTY-US United States ACCESSORIES When the KB136 QWERTY keyboard is supplied with a PST system, the original 112 key programmable keyboard is replaced by the KB136 QWERTY keyboard.
  • Page 7: Standard Layout

    STANDARD LAYOUTS l FRANCE l GERMANY l ITALY l NETHERLANDS l PORTUGAL l SPAIN l SWEDEN/FINLAND l UNITED KINGDOM l UNITED STATES 2 - 1...
  • Page 8: France

    FRANCE ² & é " ñ ÿ Ctrl ° ¦ è \ ç à ù § ÿ Alt Gr 2 - 2 £ Entrée ñ Inser Suppr Ctrl...
  • Page 9: Germany

    GERMANY ° " § ² 3 ³ 4 ò ñ ÿ ÿ Strg & ÿ ÿ Alt Gr \ ´ Pos1 Bild Ende Bild ñ ¦ Einfg Entf Strg 2 - 3...
  • Page 10: Italy

    ITALY ¦ " £ ñ ÿ ÿ Ctrl & é è ç ° ò à ÿ ÿ Alt Gr 2 - 4 ì Invio § # ù Fine ñ Canc Ctrl...
  • Page 11: Netherlands

    NETHERLANDS § " ¬ 1 ¹ 2 ² 3 ³ 4 ¼ 5 ½ 6 ¾ 7 ¶ Caps Lock ß ñ « » ¢ ÿ ÿ Ctrl & £ 8 ± ´ · - ÿ ÿ Alt Gr ¸ Home PgUp °...
  • Page 12: Portugal

    PORTUGAL ¦ " £ 4 § 5 Caps Lock ñ ÿ ÿ Ctrl & Ç ª º ÿ ÿ Alt Gr 2 - 6 » « Home PgUp ´ PgDn ñ Ctrl...
  • Page 13: Spain

    SPAIN ª " · º \ 1 ¦ 2 Bloq Mayús ñ ÿ ÿ Ctrl & ¬ 7 Ñ ´ ÿ ÿ Alt Gr ¿ ¡ Inicio Re Pág Ç Av Pág ñ Supr Ctrl 2 - 7...
  • Page 14: Sweden/Finland

    SWEDEN/FINLAND ½ " § 2 @ 3 £ 4 Caps Lock ñ ÿ ÿ Ctrl & Å ÿ ÿ Alt Gr 2 - 8 \ ´ Home PgUp PgDn ñ ¦ Ctrl...
  • Page 15: United Kingdom

    UNITED KINGDOM ¬ " £ Caps Lock ñ ÿ ÿ Ctrl & ÿ ÿ Alt Gr Home PgUp PgDn ¦ ñ Ctrl 2 - 9...
  • Page 16: United States

    UNITED STATES Caps Lock ñ Shift ÿ ÿ Ctrl & " ÿ ÿ 2 - 10 Home PgUp ¦ Enter PgDn ñ Shift Ctrl...
  • Page 17: Installation

    INSTALLATION HARDWARE INSTALLATION To install KB136 into a PST system originally equipped with KB112, the user should disassemble the KB112 from the PST system according to the instructions given in the Technical Manual of respective PST system. After this disassembly, there are three cables coming from the inside of the PST system, namely, a 2 pin cable for the standby LED, a 4 pin cable for KB signal and a DIN 5 pin cable for the external KB connector.
  • Page 18: Utility Installation

    UTILITY INSTALLATION There are in total three methods to program the programmable keys in KB136 QWERTY keyboard: “RWM.EXE” programming utility; “KBM.EXE” the normal programming utility and the “Hot Key Programming” most suitable to modify the key contents of one or two keys. Installation procedures are required for utilities “KBM.EXE”...
  • Page 19: Input The Content To Be Programmed

    PROGRAMMING HOT KEY PROGRAMMING The KB136 programmable keyboard supports the “hot key programming” method which is most useful in instant modification of a few keys in a preprogrammed keyboard without entering the more sophisticated programming utility. Of course, the user may also use this feature to program through out all 51 keys (3 rows, 17 columns) by 5 pages (LP and L1 to L4) at will.
  • Page 20: Input The Content To Be Programmed

    key while pressing the “PRT SC” (“Print Screen”) key on the PC or PS-2 keyboard. And by doing so, the KB136 will give 2 beeps to notify that it is ready to receive the identification of which key to be programmed. Right after the “hot key” is released, the user shall press the key to be programmed on the programmable keyboard once to identify which key to be programmed.
  • Page 21: Exit "Hot Key Programming" Mode

    EXIT “HOT MODE After the intended content of the key is completely entered, the user shall press the “hot key” again to notify the end of “hot key programming”. The programmable keyboard will give one beep to signify the normal exit of the “hot key programming” mode.
  • Page 22: Programming Utility (Kbm.exe)

    PROGRAMMING UTILITY (KBM.EXE) GENERAL Using the “KBM” utility for KB136 is quite similar to the way to use the “KBM” utility for KB112 though they may be of different versions and should be used distinctively. However, the screen display for KB136 is different from that for KB112 as the physical layout is different.
  • Page 23 P o s i f l e x P r o g r a m m a b l e K e y b o a r d U t i l i t y Cursor position 1A1 1B1 1C1 1D1 1E1 1F1 1G1 1H1 1I1 1J1 1K1 1L1 1M1 1N1 1O1 1P1 1Q1 1A2 1B2 1C2 1D2 1E2 1F2 1G2 1H2 1I2 1J2 1K2 1L2 1M2 1N2 1O2 1P2 1Q2 1A3 1B3 1C3 1D3 1E3 1F3 1G3 1H3 1I3 1J3 1K3 1L3 1M3 1N3 1O3 1P3 1Q3 KLP KL0 KL1 KL2 KL3 KL4...
  • Page 24: Command Listing In View Mode

    COMMAND LISTING IN VIEW MODE ESC – quit the keyboard programming program F1 – get help on command list F3 – enter the configuration screen F5 – enter ASCII-code editing mode F8 – enter scan-code editing mode F10 – quit the keyboard programming program Ins –...
  • Page 25: Command Listing In Ascii-Code Editing Mode

    Alt-W – write key definitions to the programmable keyboard Alt-X – quit the keyboard programming program any other key stoke – will be taken as an input in ASCII-code editing mode, and will give no influence if the current key was last edited in scan- code editing mode COMMAND LISTING IN ASCII-CODE EDITING MODE...
  • Page 26: Command Listing In Scan Code Editing Mode

    any other key stoke – will be taken as an input in ASCII-code editing mode. COMMAND LISTING IN SCAN CODE EDITING MODE ESC – leading code to enter scan code of any key after it into key-content, except “ESC” + “F” for utility version since 2.15.xx ESC-F –...
  • Page 27: Answer Back Code

    any other displayable key stoke – will be taken as an input in scan-code format. any other non-displayable key stroke – will have no influence ANSWER BACK CODE Programming the answer back codes of the 6 position electronic key-lock is also very easy as they are included in the keyboard programming with the locations coded as “KLP”, “KL0”, “KL1”, “KL2”, “KL3”...
  • Page 28: Shortcut Utility (Rwm.exe)

    SHORTCUT UTILITY (RWM.EXE) The feature of this RWM.EXE is designed mainly for the off-line programming purpose and is very useful in quick reproduction of the preprogrammed contents of the programmable keyboard. In such application, the user should have either the preprogrammed keyboard or the preprogrammed file with “.tpl” extension name which is the result of the keyboard programming.
  • Page 29: Details In Programming

    DETAILS IN PROGRAMMING Please refer to our web site for every detail in programming this KB136. The following simplified guide severs as a concise tool for instant application. QUICK KEYBOARD PROGRAMMING REFERENCE GUIDE Keys To Program Esc, F1 - F12, Back Space, Shift, Ctrl, Alt, Insert, Delete, End, Page Up, Page Down, Print Scrn, Scroll Lock, Break, and all Arrow Functions...
  • Page 30 5 - 2...
  • Page 31: Application

    APPLICATION KEYBOARD CONSTRUCTION This keyboard is constructed of three parts on the top surface (ref. Fig. 6-1). A 6 position turning key switch area is at the upper right corner, a 17 x 8 matrix push key switch structure occupies most of the top surface and a up-down slot near the left edge is designed for the Magnetic Stripe Reader options.
  • Page 32: 6 Position Key-Lock

    Stand-By Fig. 6 – 2 Layout in 6 position key switch area The top left LED is for stand-by indication, the top right LED is the power-on indicator and the bottom right LED is the Cap-Lock indicator for the “QWERTY” keyboard.
  • Page 33: Push Key Switch Matrix

    PUSH KEY SWITCH MATRIX The major part on the keyboard surface is constructed in a 17 x 8 matrix providing a possibility of maximum 136 key positions available. This is why this keyboard is named as KB136. However, as indicated before, while the upper 17 x 3 matrix remains in matrix and page dependent, the lower part is organized in “QWERTY”...
  • Page 34 Fig. 6 – 3a Fig. 6 – 3b 6 - 4...
  • Page 35 It is very important to correctly orientate the key tops before they are inserted into the keyboard frame. Failure to do this could result in permanent damage. Looking into the guide hole on the keyboard frame, there is a tab inside the bottom side wall (ref.
  • Page 36: Magnetic Stripe Reader Slot

    Key top Latching tab Fig. 6 – 5a When any key top is to be inserted onto the keyboard frame, the tab on the inside wall of the key top guide hole must mate a corresponding springy latching tab as illustrated above. In this way, the matching stem of a double key must be either at the bottom when the double key is “vertically”...
  • Page 37: Preloaded Pattern

    PRELOADED PATTERN This keyboard is preloaded with some data in the “LP” page of the programmable area as indicated below to help the user’s application at the moment he/she receives this programmable keyboard. Caps Lock ñ Shift ÿ ÿ Ctrl Insert Home PgUp Delete End PgDn...
  • Page 38 6 - 8...
  • Page 39: Hardware Details

    HARDWARE DETAILS PCB LAYOUT CONNECTORS Position Connector Type DIP 5 pin jack 8 x 1 header 4 pin header 90 11 pin lock connector JP12 (7 x 1 header) JP13 (Mini DIN 6 pin jack) JP15 16 pin lock connector JP20 2 pin header JP21...
  • Page 40: Jumper Setting

    JUMPER SETTING POSITION FUNCTION JIS II/ISO ALT + NUM TRACK 1 TRACK 3 TRACK 2 Leading & ending sentinel OFF JP183 STATUS 1-2, 3-4, 5-6, 7-8 short All open 7 - 2 JUMPER SHORT JUMPER OPEN JIS II MSR JP184 STATUS All open 1-2, 3-4 short ISO MSR...
  • Page 41: Part Numbers

    PART NUMBERS Part Number Description PSTKB136 Stroke type keyboard w/o MSR PSTKB136MR2 Stroke type keyboard with 2 track MSR PSTKB136MR3 Stroke type keyboard with 3 track MSR PSTKB136MRJS2 Stroke type keyboard with JIS II MSR PSTKB136CPUMR Keyboard controller CMSRCATRIGE-2 MSR module 2 tracks CMSRCATRIGE-3 MSR module 3 tracks CMSRCATRIGE-4A...
  • Page 42 8 - 2...
