Page 1: Operation Instructions
Glass and dIshwashERs FX/GX sERIEs InstallatIon and opERatIon InstRuctIons Starting from Serial No.: 8652 0001 REV. 17.03.2008... - Page 2 AG-147-C-03-08...
-
Page 3: Table Of Contents
contEnt Page ImpoRtant notEs ..............4 InstallatIon ................5 .1 Location ..................5 . Electrical connection ............... 5 .3 Water connection ................5 .4 Drain connection ................5 contRols .................. 6 staRt-up ..................7 4.1 Detergent ..................7 4. Rinse aid ..................7 4.3 Priming the suction hoses ............... -
Page 4: Important Notes
ImpoRtant notEs use in accordance with Regulations This machine is exclusively to be used to wash ware such as plates, cups, glasses, cutlery, trays etc. do not use for electrically heated cooking and heat conservation appliances. safety Never hose down the machine. The "attention"... -
Page 5: Installation
InstallatIon locatIon – Wall clearence is not required. – Level machine by turning the feet. – Distribute machine weight equally onto all feet. Vapour may escape from the dishwasher door. Therefore adjacent furniture has to be protected to prevent swelling. ElEctRIcal connEctIon must be carried out by an authorized technician according to the local and national codes. -
Page 6: Controls
contRols ➀ Machine on / oFF Pushing this button switches the machine on. As soon as the machine is ready for operation, the wash cycle is started by pushing this button also. By pushing and holding (3 seconds) this button, the drain and self cleaning cycle starts. -
Page 7: Start-Up
staRt-up dEtERGEnt do not use any acidic detergent products with the built-in detergent pump! (the ph-value has to be higher than 7.) – Place the suction hose into the detergent container. Fill the suction hose according to chapter 4.3. RInsE aId Place the suction hose (blue marking) into the rinse aid container. -
Page 8: Softener (Only On Option)
staRt-up soFtEnER (only on option) For the first run, the softener has to be filled with regeneration salt and potable water. Filling the salt reservoir with cleaning agent will damage the water softener. – Open the door. – Unscrew the softener lid and fill the softener with 2 kg of "Granular regeneration salt"... -
Page 9: Run
opERatIon – Place glasses and cups face downwards into the rack. – Remove any food debris before loading plates into rack. – Spray off greasy food soil. – Put rack into the machine and close the door. – Push the on/oFF button ➀... -
Page 10: Switch-Off And Cleaning The Machine
swItch-oFF and clEanInG thE machInE swItch-oFF – Close the door. Push and hold the on/oFF button ➀ – until the button flashes "blue". notE: During the drain cycle, the interior of the machine is cleaned automati- cally. A final inspection is recommended to remove any food debris. –... -
Page 11: Preview Of Temperatures
pREVIEw oF tEmpERatuREs – Press and hold (3 seconds) the program button ➁ until the actual temperatures (°c) are displayed (top = rinse, bottom = wash). The indicators go out 10 seconds after releasing the program button. Permanent temperature display can be activated on request by the service technician. -
Page 12: Settings And Counter Values
sEttInGs and countER ValuEs attEntIon: the machine has to be switched off. open the door. – If the door will be closed or if no button is pressed for 10 seconds, the indicator automatically switches off and the new settings will be saved. -
Page 13: Cycle Counter
sEttInGs and countER ValuEs cyclE countER – Push program button ➁ again. The display will show alternately "p" or the number of wash cycles. – In the lower display ➃ appears the value up to 999. ➄ Thousands will be shown in the upper Display Example: 103 wash cycles Max. -
Page 14: Frost Prevention
FRost pREVEntIon In case of frost or longer operation pauses (e.g. for seasonal operations) the machine must be completely drained. This should be carried out by after sales service. Reset for operation according to chapter 4. maIntEnancE For trouble free operation we recommend you enter into a service contract with your local Service Office. - Page 15 tRouBlEshootInG GuIdE typE oF FaIluRE possIBlE causE REmEdy poor wash result Stripes and staines on Rinse aid concentration too high. Reduce quantity (see instructions). dishes or glasses. Hard water or high mineral content. Check water quality. Obtain details from local water authority. Recommended values: Ideal degree of hardness is 4°...
- Page 16 As continued product improvement is a policy of HOBART, specifications are subject to change without notice. Printed in Germany aG-21427-c-03-08-pc...
Need help?
Do you have a question about the FX series and is the answer not in the manual?
Questions and answers
Good evening how come water is not coming out ,every think is connected but water is not coming out . Can you please tell me what's the problem..thanks
Possible issues if water is not coming out of a Hobart FX series unit despite all connections being made:
1. Water Supply Issue: Ensure the machine is connected to potable water and that the water supply is turned on.
2. Low Water Pressure: The line flow pressure must be at least 0.5 bar. If it is lower, water may not flow properly.
3. Blocked or Incorrect Connection: Check if the water inlet is clear and correctly connected according to installation instructions.
4. Electrical Supply Issue: Ensure the machine is properly connected to an electrical supply that matches the nameplate data.
5. Blown Site Fuse: Check if a fuse has blown, which could prevent the machine from functioning.
6. Softener Issues (if applicable): If the machine has a softener, ensure the correct type of salt is used and that it is functioning properly.
If these checks do not resolve the issue, professional servicing may be required.
