Summary of Contents for Hobart EF 40
- Page 2 EF 40/CHF45 Installation & Operation...
-
Page 3: Table Of Contents
3 - 4 GENERAL INFORMATION............KNOWING YOUR MACHINE............. 6 - 11 INSTALLATION................12 - 18 OPERATING AND MAINTENANCE.......... 19 - 23 SOLUTIONS ................NOTE: Model EF 40 - spec machines are fitted with Drain Pump and Detergent pump as standard... -
Page 4: General Information
GENERAL INFORMATION EF 40 GENERAL INFORMATION AILURE TO RESPECT THE INDICATIONS BELOW MAY COMPROMISE THE SAFETY OF THE MACHINE AND CAUSE THE GUARANTEE TO LAPSE IMMEDIATELY 1. Layout of information The warnings contained in the machine's documentation include instructions that are important for the safety, operation and maintenance of the machine. - Page 5 GENERAL INFORMATION EF 40 3. Important warnings This machine is designed for professional washing of batches of dishes. Despite every effort having been made by the manufacturer to make it simple to operate, install and maintain, it is still intended for use by trained personnel working in accordance with the manufacturer's instructions.
-
Page 6: Knowing Your Machine
KNOWING YOUR MACHINE EF 40 KNOWING YOUR MACHINE 1. Control Panel [1] = Machine ready LED [2] = Cycle start button [3] = Cycle selection button [4] = Machine ON LED [5] = Line button [6] = Cycle 1 LED... -
Page 7: Installation
INSTALLATION EF 40 INSTALLATION HE MANUFACTURER ACCEPTS NO LIABILITY FOR ANY DAMAGE TO OBJECTS OR PERSONAL INJURY ARISING FROM INSTALLATIONS WHICH FAIL TO COMPLY WITH THE INSTRUCTIONS PROVIDED Glossary In this document, the terms Main switch, water supply stop cock and Drain line are defined... - Page 8 INSTALLATION EF 40 Unpacking the appliance Before removing the packaging, check for any signs of damage, noting any defects found on the carrier’s delivery note After removing the packaging inspect the appliance for signs of damage; if damaged, notify your...
- Page 9 EF 40 INSTALLATION Water supply A water supply pipe with a “Stop cock” (see “Glossary”) must be provided for each machine. The water supply line must conform to the specifications indicated in the section “Installation data”, even when other appliances are connected to the supply line.
-
Page 10: Dispenser Settings
INSTALLATION EF 40 Dispenser settings Rinse-aid dispenser Before starting the washing cycle, the dispenser and the delivery pipe must be full. Check that there is sufficient rinse-aid in the container and top up if necessary. The rinse-aid container must never be allowed to empty completely and must not be topped up with corrosive or impure products. - Page 11 EF 40 INSTALLATION After this preliminary calibration, any subsequent adjustment is to be made on the basis of the rinsing results obtained after at least 3 cycles. Turn the screw counter-clockwise to increase and clockwise to reduce the dosage. Bluish streaks on dishes and the formation of foam in the washing solution indicate too much rinse- aid.
- Page 12 EF 40 INSTALLATION Adjust the detergent potentiometer on the electronic control card (consult layout diagram), turning it fully counter-clockwise to obtain zero detergent dosage. Start a wash cycle, with no dishes in the machine, and allow the chamber to fill with water.
-
Page 13: Operating And Maintenance
OPERATING AND MAINTENANCE EF 40 OPERATING AND MAINTENANCE 1. General Warnings HE MANUFACTURER ACCEPTS NO RESPONSIBILITY FOR DAMAGE TO PEOPLE OR PROPERTY RESULTING FROM FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN I. Precautions Proper functioning and the machine's lifespan depend on outside factors such as: preventive maintenance, characteristics of the water and products used for washing, rinsing and sanitisation. -
Page 14: Preparing The Machine
OPERATING AND MAINTENANCE EF 40 IV. Hygiene To ensure that the machine is hygienic, the maintenance operations indicated in the relevant paragraph of this manual must be carried out regularly. In addition, the machine must be treated to sanitise it from time to time using adequate, non-corrosive, commercially available products. -
Page 15: First Cycle
OPERATING AND MAINTENANCE EF 40 II. Machine controls Rinse aid and detergent dosage units (optional) Before starting the cycle, the dosage unit and supply pipes must be full. Check that the rinse aid and detergent levels are sufficient and top up as necessary. -
Page 16: Washing Cycle
EF 40 OPERATING AND MAINTENANCE 4. Washing cycle 1. Prepare the basket of dishes to be washed: use a basket that can handle the dishes (wine glasses, cups, glasses, normal plates, pizza plates, cutlery, etc.) and do not overload it. -
Page 17: Emptying The Machine
OPERATING AND MAINTENANCE EF 40 5. Successive Cycles Check the washing solution. If this is too dirty, or the filters are clogged by residue from previous washes: • Empty the tank as described in the “Emptying the Machine” paragraph. • Clean the machine as indicated in the “Maintenance” paragraph. - Page 18 EF 40 OPERATING AND MAINTENANCE 9. Maintenance I. Routine Maintenance The following operations are to be carried out when residue is found on the tank filter. • Drain the water altogether as described in paragraph 7 “Emptying the machine”. •...
-
Page 19: Operating And Maintenance
OPERATING AND MAINTENANCE EF 40 III. Special Maintenance To ensure prolonged efficient operation, it is advisable to call in a trained technician once a year, to inspect and check the machine. When the machine is unused for long periods of time, lubricate steel surfaces with vaseline and call in trained technicians to prepare the water circuits and dosage units correctly. -
Page 20: Solutions
OPERATING AND MAINTENANCE EF 40 11. Indication of problems with the water supply The machine is fitted with a (“Safe Rinse”) device that controls the flow of water into the machine. If any problem occurs with the water flowing into the machine, a signal will be displayed on the control panel, where the tank and boiler temperatures are normally displayed. - Page 21 OPERATING AND MAINTENANCE EF 40 Energy saving An energy saving function can be enabled on the machine, which allows electricity to be saved when the machine is on standby (the machine comes out of the factory with this function disabled.
- Page 22 OPERATING AND MAINTENANCE EF 40 Load tank time out This type of signal appears some minutes after loading starts if the machine does not take on any water. When this signal is displayed, check that the overflow plug is inserted, check the water supply circuit upstream of the machine (e.g.
- Page 23 OPERATING AND MAINTENANCE EF 40 15. Solution of the most common problems I. Dishes not clean ROBLEM EMEDY Washing arms blocked They must be easy to move by hand. Remove the washing arms and clean carefully. Check and clean the supply pipe to the machine's arms.
- Page 24 OPERATING AND MAINTENANCE EF 40 III. Miscellaneous ROBLEM EMEDY Breakage of dishes due to impact during the Choose and use suitable baskets and avoid overloading. cycle Machine stops during cycle Machine connected along with other appliances. Connect the machine separately, to a switch or fuses that are adequate for the current shown on the data plate.
- Page 25 230V 3~ Black Black Max 6.9kW / 20A Brown Boiler 4.9kW / C Blue Yellow/Green BLUE BLUE RED - RED 2.1kW Optionals WHITE - WHITE 2.8kW WHITE WHITE 400V 3N~ Black Black Max 6.9kW / 13A Brown Boiler 4.9kW / C Blue Yellow/Green CON IL BOILER VUOTO IL DIP 4 DEVE...
- Page 26 EF40 - EF40S B2 Boiler probe Temperaturfühler Durchlauferhitzer Sonde surchauffeur Sonda boiler Palpador de temperatura calderin Sonda de temperatura caldera B4 Tank probe Tanktemperaturefühler Sonde cuve Sonda vasca Palpador de temperatura en la cuba Sonda de temperatura tanque B5 Door switch Reed- Türsicherheitkontaktschalter Micro contact de porte Micro porta...
- Page 27 EF 40 F10* B11* TA N K Boiler Tank OPTIONAL 135/Tp...
- Page 28 DISHWASHER TECHNICAL SPECIFICATIONS EF40 EH60 EH70 EUT30 EUT60 Drain size 22MM 50MM 50MM 50MM 2" Drain hose length 1,5M 1,80M 1,80M 1,80 No Hose Water connection 3/4" 3/4" 3/4" 3/4" 3/4" Water hose length 1,5M Water pressure 1-4BAR 1-4BAR 1-4BAR 1-4BAR 1-4BAR Water temp...
- Page 29 As continued product improvement is a policy of HOBART, specifications are subject to change without notice. Ce catalogue n’est pas contractuel. HOBART se réserve le droit, et sans préavis, d’apporter toutes modifications ou améliorations à ses matériels. HOBART behält sich das Recht vor, an allen Produkten technische Änderungen und Verbesserungen ohne...
