TECHNICAL DATA
& SERVICE MANUAL
INDOOR UNIT:
SPLIT SYSTEM AIR CONDITIONER
Model No.
MPAF188R5TAA
MPAF228R5TAA
MPAF188C5TAA
MPAF228C5TAA
HEAT PUMP MODELS
MPAF188R5TAA
MPAF228R5TAA
Product Code No.
38.7104.033
38.7104.034
38.7104.037
38.7104.038
0.8180.536.1
October 2008
COOLING MODELS
MPAF188C5TAA
MPAF228C5TAA
Advertisement
Table of Contents
Related Manuals for Technibel MPAF188R5TAA
Summary of Contents for Technibel MPAF188R5TAA
- Page 1 TECHNICAL DATA & SERVICE MANUAL HEAT PUMP MODELS COOLING MODELS MPAF188R5TAA MPAF188C5TAA INDOOR UNIT: MPAF228R5TAA MPAF228C5TAA SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. MPAF188R5TAA 38.7104.033 MPAF228R5TAA 38.7104.034 MPAF188C5TAA 38.7104.037 MPAF228C5TAA 38.7104.038 0.8180.536.1 October 2008...
- Page 2 IMPORTANT! • Ground the unit following local electrical codes. Please read before installation • The Yellow/Green wire cannot be used for any connection different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. PERFORMANCE DATA 3-1 Air Throw Distance Chart 4. ELECTRICAL DATA 4-1 Electric Wiring Diagram 4-2 Wiring System Diagrams 5. FUNCTION 5-1 Cool Mode Operation 5-2 Heat Mode Operation 5-3 Auto (cool/heat) Mode Operation... -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications MPAF188R5TAA MPAF188C5TAA 220 - 240 V ~ 50 Hz Power source 230 V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity 880 / 710 / 580 Air circulation High/Med./Low... - Page 5 MPAF228R5TAA MPAF228C5TAA 220 - 240 V ~ 50 Hz Power source 230 V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity 880 / 710 / 580 Air circulation High/Med./Low m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit...
-
Page 6: Major Component Specifications
1-2 Major Component Specifications MPAF188R5TAA MPAF188C5TAA Controller PCB SAC ON-OFF IDU Part No. Controls Microprocessor 250 V - 3,15 A Control circuit fuse 2,54mm-5pcs Jumper setting JP1..JP5 SAC W-REM Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. - Page 7 MPAF228R5TAA MPAF228C5TAA Controller PCB SAC ON-OFF IDU Part No. Controls Microprocessor 250 V - 3,15 A Control circuit fuse 2,54mm-5pcs Jumper setting JP1..JP5 SAC W-REM Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 88 / L 746 Q'ty …….
-
Page 8: Other Component Specifications
1-3 Other Component Specifications A040C5026AA Trasformer (TR) AC 230 V, 50 Hz Rating Primary 13 V - 5VA Secondary Thermal cut-off temp. (PTC) (on the board) C 883 - 120°C NTC-THERMISTOR Thermistor ( Coil sensor ) 10 at 25 °C Resistance kΩ... -
Page 9: Dimensional Data
2. DIMENSIONAL DATA REAR WIEW DRAIN HOSE D.18 WIDE TUBE MPAF188xx - D.12,7 (1/2") MPAF228xx - D.15,88 (5/8") CENTER OF TUBING HOLE (2 PLACES) NARROW TUBE D.6,35 (1/4") dimension in mm... -
Page 10: Performance Data
3. PERFORMANCE DATA 3-1 Air Throw Distance Chart Cooling Room air temp. : 27°C Fan speed High Horizontal distance (m) : Flap angle 0° , : Axis air velocity 0° : Flap angle 30°, : Axis air velocity 30° Heating Room air temp. -
Page 11: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagram HEAT PUMP MODELS COOLING MODELS... -
Page 12: Wiring System Diagram
4-2 Wiring System Diagram HEAT PUMP MODELS 1-phase 3-phase MPAF228R5T GRF228R7T MPAF188R5T GRF188R5T MPAF228R5T GRF228R5T COOLING MODELS 1-phase 3-phase GRF188L7T MPAF188C5T MPAF188C5T GRF228L7T GRF188L5T MPAF228C5T model power supply control line delayed fuse 15 (85 * ) GRF188 16 A 15 (65 * ) GRF228 * 3 Phase version... -
Page 13: Function
5.FUNCTION 5-1 Cool Mode Operation In Cooling Mode, the operation of the compressor (CM), Outdoor Fan (FMO) and Indoor Fan (FMI) are determined by the difference between the room air temperature (RAT) and the set point temperature (SPT) as shown in the graph. NOTES 1. -
Page 14: Heat Mode Operation
5-2 Heat Mode Operation HEAT PUMP MODELS The Heating mode operation is similar to the Cooling mode operation. The CM, FMO and FMI are mainly controlled by the value of (RAT – SPT). In the graph above, the FMI is operating in AUTO speed mode. Therefore, the FMI speed changes automatically according to the (RT - SPT). -
Page 15: Auto (Cool/Heat) Mode Operation
5-3 Auto (cool/heat) Mode Operation HEAT PUMP MODELS In Auto Mode, the unit switches automatically between the Auto Cooling and Auto Heating in order to maintain the room temperature (RAT) at the prescribed set point (SPT). The switching between the two modes is according to the above graph. Refer to the sections 5.1 COOLING MODE and 5.2 HEATING MODE for system operation details. -
Page 16: Dry Mode Operation
5-4 Dry Mode Operation Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the ambient temperature. This is done cycling ON and OFF indoor and outdoor units according to below. ROOM DRY LEVEL TEMP Operation according to COOLING mode ≥... -
Page 17: Forced Mode
5-7 Forced Mode In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by means of the MODE button of the indoor unit control board. The operation modes can be selected pressing the button in a cyclic way (OFF COOL HEAT OFF…). -
Page 18: Protection Operations In Heat Mode
5-9 Protection operations in Heat Mode HEAT PUMP MODELS 5-9.1 Cold draft This feature prevents the supply of cold air forcing the indoor fan to a speed which cannot be changed by the user. As soon as the protection mode is exited speed can be changed manually through the remote controller. - Page 19 5-9.3 Overheat This feature prevents the build up of high pressure in the indoor heat exchanger during heating operation ICT (°C) MPAF188R5 MPAF228R5 A (°C) (°C) (°C)
-
Page 20: I Feel Function
5-10 I FEEL Function As standard configuration the air conditioner operates detecting the room temperature through the sensor equipped in the wireless remote controller (icon I FEEL shown on the display). This feature provides a personalised environment since the temperature can be detected where the remote controller is located. It is possible to de-activate this option pressing the I FEEL button on the remote controller. -
Page 21: Diagnostic
5-12 Diagnostic With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. NOTES The troubles are showed according a priority list that is in case of more than one trouble present, is always showed, at first, the one with the highest priority (1... -
Page 22: Jumpers Configuration
5-13 JUMPERS CONFIGURATION Jumpers are located on the indoor PCB near the MODE button. HEAT PUMP MODELS COOLING MODELS Unit is shipped with jumpers set according to the following table: JUMPER STATUS HEAT PUMP MODELS COOLING MODELS open open open closed open open... -
Page 23: Contacts For Building Automation
5-14 Contacts for Building Automation 5-14.1 INPUT CONTACT (J4 - green) The status of this input affects system operation according to the following: Contact OPEN : system does not operate (always OFF) – inputs from wireless remote controller are not processed Contact CLOSED: system operates in the normal way according to the inputs coming from wireless remote controller 5-14.2 OUTPUT CONTACT (J12) -
Page 24: Maintenance
5-15 Maintenance Changing the Address of the Air Conditioner In case of more than one air conditioner operating in the same room, it may be necessary to assign an address to each unit in order to avoid operation conflicts. Address is set acting on the dip-switches located on the indoor PCB and on the remote controller. -
Page 25: Troubleshooting
6 TROUBLESHOOTING 6-1 Check Before and After Troubleshooting (A) Check power supply wiring. • Check the power supply wires are correctly connected. (B) Check power supply. • Check that voltage is in specified range (±10% of the rating). • Check that power is being supplied. •... -
Page 26: Unit And Compressor Do Not Run
2 • The unit does not run. 6-4 Unit and Compressor Do Not Run The unit does not run when air conditioner is in the follwing conditions: • When the room temperature is below the setting temperature. • During the protection modes. -
Page 27: Some Parts Of The Air Conditioner Do Not Operate
6-5 Some Parts of the Air Conditioner Do Not Operate... -
Page 28: Air Conditioner Operates, But Abnormalities Aer Observed
6-6 Air Conditioner Operates, but Abnormalities are Observed... -
Page 30: Poor Cooling Or Heating
6-7 Poor Cooling or Heating... -
Page 31: Excessive Cooling Or Hating
6-8 Excessive Cooling or Heating 6-9 A Sensor Is Defective... -
Page 32: Checking Eletrical Components
7 CHECKING ELETRICAL COMPONENTS 7-1 Measurement of Insulation Resistance The insulation is in good condition if the resistance exceeds 1 MOhm a) Power Supply Wires Clamp the earthed wire of the power supply wires with the lead clip of the insulation resistance tester and measure the resistance by placing a probe on either of the power wires (fig.1). -
Page 33: Checking Continuity Of Fuse On Pcb Assy
7-2 Checking Continuity of fuse on PCB assy Remove PCB assy from electrical component box (fig.5) Then pull out the fuse from PCB assy Check continuity of fuse by the multimeter (fig.6) 7-3 Checking Motor Capacitor Remove the lead wires from the capacitor terminals, and then place a probe on the capacitor terminals as shown in fig.7. - Page 34 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
