ASROCK Fatal1ty 990FX Killer Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for ASROCK Fatal1ty 990FX Killer Series

Summary of Contents for ASROCK Fatal1ty 990FX Killer Series

  • Page 2: Copyright Notice

    (including damages for loss of proits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535; 7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive, DTS Neo:PC are trademarks of DTS, Inc. Product includes sotware. ©...
  • Page 4 Fatal1ty Story Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I actually played competitive billiards in professional tournaments and won four or ive games of guys who played at the highest level. I actually thought of making a career of it, but at that young age situations change rapidly.
  • Page 5 LIVIN’ LARGE Since my irst big tournament wins, I have been a “Professional Cyberathlete”, traveling the world and livin’ large with lots of International media coverage on outlets such as MTV, ESPN and a 60 Minutes segment on CBS to name only a few. It's unreal - it's crazy. I’m living a dream by playing video games for a living.

  • Page 6: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Speciications Unique Features Motherboard Layout I/O Panel Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Jumpers Setup Onboard Headers and Connectors and Quad SLI Operation Guide 2.7.1 Installing Two SLI...
  • Page 7 Chapter 3 Software and Utilities Operation Installing Drivers F-Stream Killer Network Manager 3.3.1 Installing Killer Network Manager 3.3.2 Using Killer Network Manager Start8 XSplit Broadcaster 3.5.1 Live Streaming Your Gameplay 3.5.2 Recording Your Gameplay Chapter 4 UEFI SETUP UTILITY Introduction 4.1.1 UEFI Menu Bar 4.1.2 Navigation Keys...
  • Page 8 4.4.8 Trusted Computing Tools Hardware Health Event Monitoring Screen Boot Screen Security Screen Exit Screen...

  • Page 9: Chapter 1 Introduction

    If you require technical support related to this motherboard, please visit our website for speciic information about the model you are using. You may ind the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 10: Speciications

    1.2 Speciications • ATX Form Factor Platform • Premium Gold Capacitor design (100% Japan-made high- quality conductive polymer capacitors) • Purity Sound A-Style Gaming CPU Power • Hi-Density Power Connector Armor VGA Card • 15μGold Finger in VGA PCIe Slots (PCIE2/PCIE3) • SLI/CrossFireX Power Connector Internet • Qualcomm®...
  • Page 11 Fatal1ty 990FX Killer Series • Max. capacity of system memory: 64GB (see CAUTION2) • Supports Intel® Extreme Memory Proile (XMP) 1.3 / 1.2 • Supports AMD Memory Proile (AMP) • 3 x PCI Express 2.0 x16 Slots (PCIE2/PCIE3 @ x16 mode;...
  • Page 12 • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) • HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone • 5 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, Storage RAID 1, RAID 0+1, JBOD and RAID 5), NCQ, AHCI and Hot Plug...
  • Page 13 2. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 8 / 7. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation. You can use ASRock XFast RAM to utilize the memory that Windows® cannot use.

  • Page 14: Unique Features

    Fatal1ty Mouse Port, Energy Saving and XFast RAM. ASRock Instant Boot ASRock Instant Boot allows you to turn on your PC in just a few seconds, provides a much more eicient way to save energy, time, money, and improves system running speed for your system.
  • Page 15 Fatal1ty 990FX Killer Series ASRock Crashless BIOS ASRock Crashless BIOS allows users to update their BIOS without fear of failing. If power loss occurs during the BIOS updating process, ASRock Crashless BIOS will automatically inish the BIOS update procedure ater regaining power. Please note that BIOS iles need to be placed in the root directory of your USB disk.
  • Page 16 Windows® 8 brings the ultimate boot up experience. he lightning boot up speed makes it hard to access the UEFI setup. ASRock Restart to UEFI allows users to enter the UEFI automatically when turning on the PC. By enabling this function, the PC will enter the UEFI directly ater you restart.

  • Page 17: Motherboard Layout

    Fatal1ty 990FX Killer Series 1.4 Motherboard Layout CPU_FAN1 CPU_FAN2 CHA_FAN2 USB 2.0 T: USB0 B: USB1 USB 3.0 T: USB1 B: USB2 USB 3.0 T: USB3 B: USB4 USB 2.0 T: USB2 B: USB3 USB6_7 USB8_9 USB 2.0 Top: T: USB4...
  • Page 18 No. Description Chassis Fan Connector (CHA_FAN2) ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) CPU Fan Connector (CPU_FAN2) 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1) 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2) ATX Power Connector (ATXPWR1) USB 2.0 Header (USB8_9) USB 2.0 Header (USB6_7) USB 3.0 Header (USB3_5_6) Vertical Type A USB 3.0 (USB3_7)

  • Page 19: I/O Panel

    Fatal1ty 990FX Killer Series 1.5 I/O Panel No. Description No. Description PS/2 Mouse Port Rear Speaker (Black) USB 2.0 Ports (USB_01) Line In (Light Blue) USB 3.0 Ports (USB3_12) Front Speaker (Lime)** USB 3.0 Ports (USB3_34) Microphone (Pink) Fatal1ty Mouse Port (USB2) Optical SPDIF Out Port USB 2.0 Port (USB3)
  • Page 20 * here are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection Blinking Data Activity Orange...

  • Page 21: Chapter 2 Installation

    Fatal1ty 990FX Killer Series Chapter 2 Installation his is an ATX form factor motherboard. Before you install the motherboard, study the coniguration of your chassis to ensure that the motherboard its into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 22: Installing The Cpu

    2.1 Installing the CPU Unplug all power cables before installing the CPU.
  • Page 23 Fatal1ty 990FX Killer Series...

  • Page 24: Installing The Cpu Fan And Heatsink

    2.2 Installing the CPU Fan and Heatsink Ater you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.

  • Page 25: Dual Channel Memory Coniguration

    Fatal1ty 990FX Killer Series 2.3 Installing Memory Modules (DIMM) his motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel coniguration, you always need to install identical (the same brand, speed, size and chip-type) DDR3 DIMM pairs.
  • Page 26 English...

  • Page 27: Expansion Slots (Pci Express Slots)

    Fatal1ty 990FX Killer Series 2.4 Expansion Slots (PCI Express Slots) here are 5 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched of or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 28: Jumpers Setup

    2.5 Jumpers Setup he illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. he illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.

  • Page 29: Onboard Headers And Connectors

    Fatal1ty 990FX Killer Series 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.
  • Page 30 Power LED Header Please connect the chassis PLED- (3-pin PLED1) power LED to this header PLED+ PLED+ (see p.9, No. 18) to indicate the system’s power status. Serial ATA3 Connectors hese ive SATA3 (SATA3_1: connectors support SATA see p.9, No. 17) data cables for internal (SATA3_2: storage devices with up to...
  • Page 31 Fatal1ty 990FX Killer Series Front Panel Audio Header his header is for PRESENCE# MIC_RET (9-pin HD_AUDIO1) connecting audio devices OUT_RET (see p.9, No. 27) to the front audio panel. O U T 2 _ L J _ S E N S E...
  • Page 32 CPU Fan Connectors his motherboard pro- FAN_SPEED_CONTROL CPU_FAN_SPEED (4-pin CPU_FAN1) vides a 4-Pin CPU fan +12V (see p.9, No. 3) (Quiet Fan) connector. If you plan to connect a 1 2 3 4 (3-pin CPU_FAN2) 3-Pin CPU fan, please G ND +12V (see p.9, No.
  • Page 33 Fatal1ty 990FX Killer Series Serial Port Header his COM1 header (9-pin COM1) supports a serial port (see p.9, No. 25) module. SPDIF Out Connector Please connect the (2-pin SPDIF_OUT1) SPDIF_OUT connector of SPDIFOUT (see p.9, No. 26) a HDMI VGA card to this header with a cable.

  • Page 34: Sli Tm And Quad Sli Tm Operation Guide

    2.7 SLI and Quad SLI Operation Guide ® his motherboard supports NVIDIA and Quad SLI (Scalable Link Interface) technology that allows you to install up to two identical PCI Express x16 ® graphics cards. Currently, NVIDIA and Quad SLI technology supports ®...
  • Page 35 Fatal1ty 990FX Killer Series Step 3 Align and insert the ASRock SLI_ Bridge_2S Card to the goldingers on each graphics card. Make sure the ASRock SLI_ Bridge_2S Card is irmly in place. SLI_Bridge_2S Card ASRock SLI_Bridge_2S Card Step 4 Connect a VGA cable or a DVI cable to the...

  • Page 36: Driver Installation And Setup

    2.7.2 Driver Installation and Setup Install the graphics card drivers to your system. Ater that, you can enable the ® Multi-Graphics Processing Unit (GPU) in the NVIDIA nView system tray utility. Please follow the below procedures to enable the multi-GPU. For SLI and Quad SLI mode...

  • Page 37: Tm And Quad Crossfirex

    Fatal1ty 990FX Killer Series 2.8 CrossFireX , 3-Way CrossFireX and Quad CrossFireX Operation Guide his motherboard supports CrossFireX , 3-way CrossFireX and Quad CrossFireX that allows you to install up to three identical PCI Express x16 graphics cards. Currently CrossFireX...

  • Page 38: Installing Three Crossfirex

    Step 3 Connect a VGA cable or a DVI cable to the monitor connector or the DVI connec- tor of the graphics card that is inserted to PCIE2 slot. 2.8.2 Installing Three CrossFireX -Ready Graphics Cards Step 1 Insert one graphics card into PCIE2 slot, another graphics card to PCIE3 slot, and the other graphics card to PCIE5 slot.

  • Page 39: Driver Installation And Setup

    Fatal1ty 990FX Killer Series 2.8.3 Driver Installation and Setup Step 1 Power on your computer and boot into OS. Step 2 Remove the AMD drivers if you have any VGA drivers installed in your system. he Catalyst Uninstaller is an optional download. We recommend using this utility to uninstall any previously installed Catalyst drivers prior to installation.

  • Page 40: M.2_Ssd (Ngff) Module Installation Guide

    2.9 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2_SSD (NGFF) Socket 3 can accommodate either a M.2 SATA3 6.0 Gb/s module or a M.2 PCI Express module up to Gen 2 x2 (10 Gb/s).
  • Page 41 Fatal1ty 990FX Killer Series Step 4 Hand tighten the standoff into the desired NUT on the motherboard. Step 5 A l ig n a nd gent ly i nser t t he M. 2 (NGFF) SSD module into the M.2 slot.

  • Page 42: Chapter 3 Software And Utilities Operation

    Chapter 3 Software and Utilities Operation 3.1 Installing Drivers he Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. he CD automatically displays the Main Menu if “AUTORUN”...

  • Page 43: F-Stream

    Fatal1ty 990FX Killer Series 3.2 F-Stream F-Stream is an all-in-one tool to ine-tune diferent system functions in a user- friendly interface, it includes Hardware Monitor, Fan Control, Overclocking, Fatal1ty Mouse Port, Energy Saving and XFast RAM. In Hardware Monitor, it shows the major readings of your system.

  • Page 44: Hardware Monitor

    Hardware Monitor In the Hardware Monitor section, it shows the major readings of your system. he main readings include Clock, Fan & Temperature, and Voltage. In Clock, there are CPU speed and CPU ratio. In Fan & Temperature, there are CPU temperature and CPU fan speed.
  • Page 45 Fatal1ty 990FX Killer Series Overclocking In the Overclocking section, there are Clock and Voltage chapters for users to adjust settings and pursuit optimal system performance. You are able to ine-tune the CPU ratio, CPU frequency, and respective voltages by clicking the “+/-” at the display panel.
  • Page 46 Energy Saving Featuring an advanced proprietary hardware and sotware design, Energy Saving is a revolutionary technology that delivers unparalleled power saving. he voltage regulator can reduce the number of output phases to improve eiciency when the CPU cores are idle. In other words, it is able to provide exceptional power saving and improve power eiciency without sacriicing computing performance.

  • Page 47: Killer Network Manager

    3.3.1 Installing Killer Network Manager When you install the all-in-one driver to your system from ASRock’s support CD, Killer Network Manager will be auto-installed as well. Ater the installation, you will ind the icon “Killer Network Manager“...
  • Page 48 Performance Performance allows you to view in real time your system performance and current network utilization for download and upload traic. Network Network allows you to set your preferred upload/download speeds and test the network speed. * You must have Adobe Flash Player installed to run the network speed test.
  • Page 49 Fatal1ty 990FX Killer Series Killer Ethernet Killer Ethernet displays the network information.

  • Page 50: Start8

    3.4.1 Installing Start8 Install Start8, which is located in the folder at the following path of the Support CD: \ ASRock Utility > Start8. 3.4.2 Coniguring Start8 Style Select between the Windows 7 style and Windows 8 style Start Menu. hen select...
  • Page 51 Fatal1ty 990FX Killer Series Conigure Conigure provides coniguration options, including icon sizes, which shortcuts you want Start Menu to display, quick access to recently used apps, the functionality of the power button, and more. Control...
  • Page 52 Control lets you conigure what a click on the start button or a press on the Windows key does. Desktop Desktop allows you to disable the hot corners when you are working on the desktop. It also lets you choose whether or not the system boots directly into desktop mode and bypass the Metro user interface.

  • Page 53: Xsplit Broadcaster

    Fatal1ty 990FX Killer Series 3.5 XSplit Broadcaster XSplit Broadcaster is a desktop application designed to make your multimedia broadcasting, live-streaming and recording a lot easier and more fun to do, we are giving away the 3 months premium license which is worth US$24.95 for free! 3.5.1 Live Streaming Your Gameplay...
  • Page 54 Step 3 Go to Broadcast > Add Channels…. Step 4 Click Add..Step 5 Select a platform for live streaming. *Before you start streaming, you need to register an account for the streaming service website, such as Twitch.tv, USTREAM, or other livestreaming services.
  • Page 55 Fatal1ty 990FX Killer Series Step 6 Fill in your platform's Username and Password. Based on your needs, conigure the Video and Audio Encoding settings. Click OK. Step 7 he channel then appears in your broadcast list. Click Apply and OK to save the...

  • Page 56: Recording Your Gameplay

    Step 8 Go to Broadcast and select the platform to enable live streaming. A link to view your live Broadcast has been copied for you automatically. Simply press CTRL-V or right click and choose Paste to paste the link into the browser, and you can see your broadcast.

  • Page 57: Chapter 4 Uefi Setup Utility

    Fatal1ty 990FX Killer Series Chapter 4 UEFI SETUP UTILITY 4.1 Introduction his section explains how to use the UEFI SETUP UTILITY to conigure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right ater you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 58: Navigation Keys

    4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 59: Main Screen

    Fatal1ty 990FX Killer Series 4.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Active Page on Entry Select the default page when entering the UEFI setup utility.

  • Page 60: Oc Tweaker Screen

    4.3 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI sotware is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.

  • Page 61: Spread Spectrum

    ASRock UCC (Unlock CPU Core) feature simpliies AMD CPU activation. As long as a simple switch of the UEFI option “ASRock UCC”, you can unlock the extra CPU core to enjoy an instant performance boost. When UCC feature is enabled, the dual-core...

  • Page 62: Dram Timing Coniguration

    CPU Frequency Multiplier For safety and system stability, it is not recommended to adjust the value of this item. CPU Voltage It allows you to adjust the value of CPU voltage. However, for safety and system stability, it is not recommended to adjust the value of this item. NB Frequency Multiplier For safety and system stability, it is not recommended to adjust the value of this item.

  • Page 63: Channel Interleaving

    Fatal1ty 990FX Killer Series DRAM Timing Control DRAM Slot Use this item to view SPD data. DRAM Timing Control Use this item to control DRAM timing. Power Down Enable Use this item to enable or disable DDR power down mode.
  • Page 64 CPU Voltage Ofset Conigure the dynamic CPU voltage added to the CPU. NB Voltage Use this to select NB Voltage. he default value is [Auto]. HT Voltage Use this to select HT Voltage. he default value is [Auto]. CPU VDDA Voltage Use this to select CPU VDDA Voltage.

  • Page 65: Advanced Screen

    Fatal1ty 990FX Killer Series 4.4 Advanced Screen In this section, you may set the conigurations for the following items: CPU Coniguration, North Bridge Coniguration, South Bridge Coniguration, Storage Coniguration, Super IO Coniguration, ACPI Coniguration, USB Coniguration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 66: Cpu Coniguration

    4.4.1 CPU Coniguration Cool 'n' Quiet Use this item to enable or disable AMD’s Cool ‘n’ Quiet technology. he default value is [Enabled]. Coniguration options: [Enabled] and [Disabled]. If you install ® Windows 8 / 7 / Vista and want to enable this function, please set this item to [Enabled].
  • Page 67 Fatal1ty 990FX Killer Series CPU Thermal Throttle Use this item to enable CPU internal thermal control mechanism to keep the CPU from overheated. he default value is [Auto].

  • Page 68: North Bridge Coniguration

    4.4.2 North Bridge Coniguration IOMMU Use this to enable or disable IOMMU. he default value of this feature is [Disabled].

  • Page 69: South Bridge Coniguration

    Fatal1ty 990FX Killer Series 4.4.3 South Bridge Coniguration Onboard HD Audio Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and automatically disable it when a sound card is installed. Front Panel Enable/disable front panel HD audio.

  • Page 70: Storage Coniguration

    4.4.4 Storage Coniguration SATA Controller(s) Enable/disable the SATA controllers. SATA Mode IDE: For better compatibility. AHCI: Supports new features that improve performance. RAID: Combine multiple disk drives into a logical unit. If you set this item to RAID mode, it is suggested to install SATA ODD driver on SATA3_5 or eSATA3 port.

  • Page 71: Aggressive Link Power Management

    Fatal1ty 990FX Killer Series If you want to build RAID on SATA3_5 and eSATA3 ports, please disable this item. Aggressive Link Power Management Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power. It is only supported by AHCI mode.

  • Page 72: Super Io Coniguration

    4.4.5 Super IO Coniguration Serial Port Enable or disable the Serial port. Serial Port Address Select the address of the Serial port. Infrared Port Enable or disable the Infrared port.

  • Page 73: Acpi Coniguration

    Fatal1ty 990FX Killer Series 4.4.6 ACPI Coniguration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. Check Ready Bit Enable to enter the operating system ater S3 only when the hard disk is ready, this is recommended for better system stability.
  • Page 74 Ring-In Power On Allow the system to be waked up by onboard COM port modem Ring-In signals. RTC Alarm Power On Allow the system to be waked up by the real time clock alarm. Set it to By OS to let it be handled by your operating system.

  • Page 75: Usb Coniguration

    Fatal1ty 990FX Killer Series 4.4.7 USB Coniguration USB Controller Enable or disable all the USB 2.0 ports. USB 3.0 Controller Enable or disable all the USB 3.0 ports. Legacy USB Support Enable or disable Legacy OS Support for USB 2.0 devices. If you encounter USB compatibility issues it is recommended to disable legacy USB support.

  • Page 76: Trusted Computing

    4.4.8 Trusted Computing Security Device Support Enable to activate Trusted Platform Module (TPM) security for your hard disk drives.
  • Page 77 In order to prevent users from bypassing OMG, guest accounts without permission to modify the system time are required. UEFI Tech Service Contact ASRock Tech Service if you are having trouble with your PC. Please setup network coniguration before using UEFI Tech Service. Easy RAID Installer Easy RAID Installer helps you to copy the RAID driver from the support CD to your USB storage device.

  • Page 78: Network Coniguration

    Save UEFI iles in your USB storage device and run Instant Flash to update your UEFI. Internet Flash ASRock Internet Flash downloads and updates the latest UEFI irmware version from our servers for you. Please setup network coniguration before using Internet Flash.
  • Page 79 Fatal1ty 990FX Killer Series Dehumidiier Function If Dehumidiier Function is enabled, the computer will power on automatically to dehumidify the system ater entering S4/S5 state. Dehumidiier Period Conigure the period of time until the computer powers on and enables Dehumidiier ater entering S4/S5 state.

  • Page 80: Hardware Health Event Monitoring Screen

    4.6 Hardware Health Event Monitoring Screen his section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. CPU Fan 1 & 2 Setting his allows you to set the CPU fan 1 & 2 speed. Coniguration options: [Full On] and [Automatic Mode].

  • Page 81: Boot Screen

    Fatal1ty 990FX Killer Series 4.7 Boot Screen his section displays the available devices on your system for you to conigure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device.
  • Page 82 AddOn ROM Display Enable AddOn ROM Display to see the AddOn ROM messages or conigure the AddOn ROM if you've enabled Full Screen Logo. Disable for faster boot speed. Boot Failure Guard If the computer fails to boot for a number of times the system automatically restores the default settings.

  • Page 83: Security Screen

    Fatal1ty 990FX Killer Series 4.8 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 84: Exit Screen

    4.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save coniguration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...

  • Page 85: Contact Information

    Fatal1ty 990FX Killer Series Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp...
