MA1102-EA
Your watch may differ somewhat from the one shown in the
illustration.
Notes
Some water resistant models are equipped
with a screw lock crown.
With such models, you must unscrew the
crown in the direction noted in the illustration
to loosen it before you can pull it out. Do not
pull too forcibly on such crowns.
Also note that such watches are not water
resistant while their crowns are loosened. Be
sure to screw the crowns back in as far as
they will go after making any setting.
Setting the Time and Day
To set the day
1.
Pull the crown out to Click 1.
2.
Rotate the crown to set the day.
Avoid changing the day setting between 9:00 p.m. and
1:00 a.m. (If you do, the day indication may not change at
midnight).
3.
Push the crown back in to the normal position.
To set the day of the week and time
1.
Pull the crown out to Click 2 when the second hand is at
12 o'clock. The second hand will stop.
2.
Set the hands by rotating the crown. As you do, the day of the
week changes accordingly.
3.
After setting the day of the week, rotate the crown to set the
time. Make sure to distinguish between AM and PM.
4.
On a time signal, push the crown back in to the normal
position.
For watch with the elapsed time bezel
Rotate the elapsed time bezel to align the
mark with the minute hand.
After certain amount of time elapsed, read the
graduation on the elapsed time bezel which the
minute hand points to.
The elapsed time is indicated.
Module No.
5228
Operation Guide 5228
Crown (Normal position)
Click 1
(Day setting)
Click 2
(Time and day of
week setting)
Day
Day of the week
Elapsed time bezel

Specifications

Accuracy at normal
Battery type
temperature
±20 seconds per month
SR916SW
Approx. 3 years
Battery life
1
