Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
21
cast iron
GAL
vertical air compressor
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2013 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 15a
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 61693
Summary of Contents for Central Pneumatic 61693
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Table Of Contents
Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. Addresses practices not related to personal injury. Page 2 For technical questions, please call 1-888-866-5797. ITEM 61693... -
Page 3: Safety
Ensure the switch is in the off-position before connecting to power source or moving the compressor. ITEM 61693 For technical questions, please call 1-888-866-5797. Page 3... -
Page 4: Air Compressor Safety Warnings
State of California to cause cancer and birth defects or other reproductive harm. (California Health & Safety Code § 25249.5, et seq.) SAVE THESE INSTRUcTIONS. Page 4 For technical questions, please call 1-888-866-5797. ITEM 61693... -
Page 5: Compressors With Three Prong Plugs
Cubic Feet per Minute flow Canadian Standards Association Cubic Feet per Minute flow ScFM Underwriters Laboratories, Inc. at standard conditions National pipe thread, tapered Volts Alternating Current National pipe thread, straight Amperes ITEM 61693 For technical questions, please call 1-888-866-5797. Page 5... -
Page 6: Specifications
Oil Sight Glass (34) Tank pressure Gauge (64) Safety Tank pressure Output pressure Valve Gauge (64) Gauge (63) Safety (59) Valve (59) Figure B: controls Drain Valve (73) Figure A: Functions Page 6 For technical questions, please call 1-888-866-5797. ITEM 61693... - Page 7 3. Slide the Handle (67) into the two fittings on the Tank and secure it in place with four Bolts (66). See Figure D. Handle (67) Tank Bolt (66) Figure D ITEM 61693 For technical questions, please call 1-888-866-5797. Page 7...
-
Page 8: Checking The Oil
Quick Coupler (55) and fully 6. Set the ON/OFF Power Lever to OFF. open all regulators and valves. 7. Unplug the Power Cord and 3. Plug in the Power Cord. remove the male coupler. Page 8 For technical questions, please call 1-888-866-5797. ITEM 61693... - Page 9 The shutoff valve should be a ball valve because it can be closed quickly. ITEM 61693 For technical questions, please call 1-888-866-5797. Page 9...
- Page 10 Page 10 For technical questions, please call 1-888-866-5797. ITEM 61693...
- Page 11 ITEM 61693 For technical questions, please call 1-888-866-5797. Page 11...
-
Page 12: Operation
Close the Valve after moisture has drained out. Do not remove the Drain Valve. 17. Clean, then store the Air Compressor indoors. Page 12 For technical questions, please call 1-888-866-5797. ITEM 61693... -
Page 13: Automatic Shut Off System
Reset Button to start the compressor. See Figure I. 3. Correct any issues before further use to avoid damage to the compressor. d. Resume operation. Reset Button Figure I ITEM 61693 For technical questions, please call 1-888-866-5797. Page 13... -
Page 14: Maintenance
Look for air bubbles. ** To clean the compressor surface, wipe with *** Use SAE 30W, non-detergent, a damp cloth, using a mild detergent or mild solvent. Air Compressor Oil only (sold separately). Page 14 For technical questions, please call 1-888-866-5797. ITEM 61693... - Page 15 4. When all the pressure and moisture has been released, close the Drain Valve by moving the Drain Valve Lever perpendicular to the valve, as shown in the drawing on the right side of Figure J. ITEM 61693 For technical questions, please call 1-888-866-5797. Page 15...
-
Page 16: Troubleshooting
7. High altitude reducing air output. 7. Higher altitudes require compressors with greater output. Follow all safety precautions whenever diagnosing or servicing the compressor. Disconnect power supply before service. Page 16 For technical questions, please call 1-888-866-5797. ITEM 61693... -
Page 17: Please Read The Following Carefully
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. ITEM 61693 For technical questions, please call 1-888-866-5797. Page 17... -
Page 18: Parts List And Diagram
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 18 For technical questions, please call 1-888-866-5797. ITEM 61693... -
Page 19: Assembly Diagram
Assembly Diagram ITEM 61693 For technical questions, please call 1-888-866-5797. Page 19... -
Page 20: Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
