CHEVROLET/GMC
X009-GM2 9"
Installation Manual
˜ Model: Full Size Truck
˜ Model Year: 2007-2013
˜ Trim Level: Upper Dash Radio
(Not compatible with Classic and LTZ models)
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by the store that you purchased it from.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
Model
SILVERADO
CHEVROLET
SILVERADO 2500HD
SILVERADO 3500HD
SIERRA
GMC
SIERRA 2500HD
SIERRA 3500HD
Chevrolet/GMC
FULL SIZE TRUCK
Year
2007 - 2013
2007 - 2013
2007 - 2013
2007 - 2013
2007 - 2013
2007 - 2013
˜ 1/13
Advertisement
Related Manuals for Alpine X009-GM2 9”
Summary of Contents for Alpine X009-GM2 9”
- Page 1 ˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manuals.
- Page 2 Chevrolet/GMC FULL SIZE TRUCK ˜ 2/13 Types of Precautions Indicates actions that are forbidden Indicates actions that are (must not be performed) mandatory (must be performed) Forbidden Mandatory Indicates that disassembly is Marks content that should receive forbidden. your full attention. Forbidden Warning Do not disassemble or modify the product.
- Page 3 Chevrolet/GMC FULL SIZE TRUCK ˜ 3/13 When installing and grounding the product, do not use any of the bolts or nuts of the steering wheel, brakes, fuel tank, or the like. Doing so could make the brakes stop working or lead to fire. Forbidden Do not install the product near the passenger-side airbag.
-
Page 4: Accessory List
X009 Head Unit X009 Camera Harness AUX/Pre Out Harness GPS Antenna USB Extension Cable 8mm x 8 Screws Quick Reference Guides Registration Cards Alpine NAVTEQ Audio Navigation Registration Card Registration Card iDatalink Maestro Box Parts (ALP-MRR V2.0/ALP-HRM-GM2 V2.1) Main Harness... - Page 5 Chevrolet/GMC FULL SIZE TRUCK ˜ 5/13 Installation Kit Parts (G-KTX-009-GM2) X009-GM2 Radio Bezel Key Harness Side Mounting Brackets 4WD Rotary Switch Panel Optional Button Extension Cable HVAC Spacers Cigarette Lighter Extension USB/AUX Extension Cable 4WD Rotary Switch Extension Cable Cable...
- Page 6 Chevrolet/GMC FULL SIZE TRUCK ˜ 6/13 Component Locations GPS Antenna Head Unit Maestro Chime Speaker Location GPS Antenna Location Maestro Chime Speaker Location Maestro Chime Speaker Location...
- Page 7 Chevrolet/GMC FULL SIZE TRUCK ˜ 7/13 Factory Radio Removal Process Remove the fuse panel cover. Extract 2x Phillips screws from instrument panel cover and remove it. Remove the radio bezel by unsnapping it. Extract 2x Phillips screws, 1x 10mm bolt from the Extract 6x 7/32”...
- Page 8 Chevrolet/GMC FULL SIZE TRUCK ˜ 8/13 Flashing the iDatalink Maestro Module INSTALL THE WEBLINK PLUG-IN CONNECT YOUR MAESTRO MODULE Go to: Use the included USB cable to connect your Maestro module to your idatalinkmaestro.com/plugin and follow the installation steps. Review the System Requirements before installing. LOG INTO WEBLINK Go to: idatalinkmaestro.com/login.
-
Page 9: Installation Instructions
Chevrolet/GMC FULL SIZE TRUCK ˜ 9/13 Installation Instructions Connect the Maestro module to the X009 main Place the GPS antenna on the OEM GPS antenna harness. location as illustrated and feed the cable to the radio cavity. Use the supplied metal base for the best signal strength. -
Page 10: Exploded View Diagram
Chevrolet/GMC FULL SIZE TRUCK ˜ 10/13 Exploded-View Diagram Parts assembly diagram for the X009-GM2 kit. X009 Source Unit Left Mounting Bracket X009-GM2 Radio Bezel OEM Switch Panel Assembly Right Mounting Left HVAC Spacer Bracket Right HVAC Spacer (If 4WD Equipped) OEM Rotary 4WD Switch OEM Cigarette... - Page 11 Chevrolet/GMC FULL SIZE TRUCK ˜ 11/13 Wiring Installation Procedure Connect and route the key unit harness as shown Connect the factory cigarette lighter and optional in the diagram below. Using a piece of tape secure button extensions. it to the X009 source unit. With the key harness run to the front, mount the source unit and HVAC spacers using the 7mm factory screws.
- Page 12 Chevrolet/GMC FULL SIZE TRUCK ˜ 12/13 Trimming procedure for factory HVAC panel The factory HVAC control needs to be trimmed to fit properly in the kit. Trim the top edges of the HVAC control as shown in the diagram below. Cut out –...
- Page 13 Chevrolet/GMC FULL SIZE TRUCK ˜ 13/13 X009-GM2 System Wiring for All Non-Navigation Equipped Vehicles To Vehicle Connectors Chime Speaker To ODB II Connector 2-pin Black Connector USB Extension iDatalink MAESTRO Module Cable GPS Antenna HDMI Input X009 Head Unit To SXM (Not included) To X009-GM Key Panel...
