TOYOTA TUNDRA
X009-TND 9"
Installation Manual
˜ Model: Full Size Truck
˜ Model Year: 2007-2013
˜ Trim Level: All
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by the store that you purchased it from.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
Model
TOYOTA
TUNDRA
FULL SIZE TRUCK
Year
2007 - 2013
Toyota
˜ 1/14
Advertisement
Related Manuals for Alpine X009-TND 9”
Summary of Contents for Alpine X009-TND 9”
- Page 1 ˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manuals.
- Page 2 Toyota FULL SIZE TRUCK ˜ 2/14 Types of Precautions Indicates actions that are forbidden Indicates actions that are (must not be performed) mandatory (must be performed) Forbidden Mandatory Indicates that disassembly is Marks content that should receive forbidden. your full attention. Forbidden Warning Do not disassemble or modify the product.
- Page 3 Toyota FULL SIZE TRUCK ˜ 3/14 When installing and grounding the product, do not use any of the bolts or nuts of the steering wheel, brakes, fuel tank, or the like. Doing so could make the brakes stop working or lead to fire. Forbidden Do not install the product near the passenger-side airbag.
-
Page 4: Accessory List
X009 Head Unit X009 Camera Harness AUX/Pre Out Harness GPS Antenna USB Extension Cable 8mm x 8 Screws Quick Reference Guides Registration Cards Alpine NAVTEQ Audio Navigation Registration Card Registration Card iDatalink Maestro Box Parts (ALP-MRR V2.0/ALP-HRN-TND V2.0) Main Harness... - Page 5 Toyota FULL SIZE TRUCK ˜ 5/14 Installation Kit Parts (G-KTX-009-TND) X009-TND Radio Bezel Key Harnesses Side Mounting Brackets USB/HDMI Extension Connector Microphone...
- Page 6 Toyota FULL SIZE TRUCK ˜ 6/14 Component Locations Head Unit GPS Antenna Microphone GPS Antenna Location Location...
- Page 7 Toyota FULL SIZE TRUCK ˜ 7/14 Factory Unit Removal Process Remove the door sill and kick panels. Remove the cigarette lighter panel using a panel removal tool. Remove the HVAC control unit using a panel Extract 2x 10mm bolts at the bottom of the knee removal tool.
- Page 8 Toyota FULL SIZE TRUCK ˜ 8/14 Programming the iDatalink Maestro Module INSTALL THE WEBLINK PLUG-IN CONNECT YOUR MAESTRO MODULE Go to: Use the included USB cable to connect your Maestro module to your idatalinkmaestro.com/plugin and follow the installation steps. Review the System Requirements before installing. LOG INTO WEBLINK Go to: idatalinkmaestro.com/login.
-
Page 9: Installation Instructions
Toyota FULL SIZE TRUCK ˜ 9/14 Installation Instructions Connect the Maestro Module to the main harness. Remove the center top dash cover using a panel removal tool. Place GPS antenna as illustrated and feed the cable down to the X009. Using a cutting tool, trim the marked gray area. - Page 10 Toyota FULL SIZE TRUCK ˜ 10/14 Installation Instructions Attach the side brackets using the provided Connect the X009-TND radio bezel and press it screws. into place. Connect the USB/HDMI extension and run it to the HVAC location. Press the HVAC and other panels into place. With the key harness ran below the head unit, mount the head unit using the 4x 10mm factory bolts.
- Page 11 Toyota FULL SIZE TRUCK ˜ 11/14 Exploded-View Diagram X009 Head Unit X009-TND Radio Bezel OEM/HVAC Switch Panel Assembly Side Mounting Bracket OEM/HDMI Port Bezel Wiring Diagram 20-pin 8-pin 8-pin Microphone Input for BT Hand Free...
- Page 12 Toyota FULL SIZE TRUCK ˜ 12/14 X009-TND Basic System Wiring 2-pin Black Connector 3.5mm Aux 3 /iPod Video X009 Camera Harness 3.5mm Aux 3 /iPod Video Factory Rearview Camera 3.5mm iDatalink Audio...
- Page 13 Toyota FULL SIZE TRUCK ˜ 13/14 X009-TND Amplified System Wiring OBDII Extension Cable 2-pin Black Connector 3.5mm Aux 3 /iPod Video X009 Camera Harness 3.5mm Aux 3 /iPod Video Factory Rearview Camera 3.5mm iDatalink Audio...
- Page 14 Toyota FULL SIZE TRUCK ˜ 14/14 X009-TND Camera, Amplified and Navigation Equipped System Wiring Aftermarket White (Ground) Black Black (Power 5V+) Green/Yellow Gray (Video -) Brown (Video +) Yellow OEM Camera adapter for navigation equipped vehicles Factory Camera Adapter Harness OBDII Extension Cable 2-pin Black Connector 3.5mm Aux 3...
