- Page 1 X3102r user manual V. 2.0 © Copyright 2002 XAVi Technologies Corporation All rights reserved. 1 / 33...
-
Page 2: Table Of Contents
X3102r user manual V. 2.0 Overview ..................3 Packaging ..................5 III. Hardware Installation..............7 IV. Management ................8 Default Values ................9 VI. Software Upgrade ..............10 Appendix A Specifications ............11 Appendix B..................13 B-1 Product Warranty............13 B-2 FCC Part 15 Notice ............14 B-3 IC CS-03 Notice............. 15 I. -
Page 3: Overview
Overview X3102r is a 2-Wire SHDSL CPE, complied with PAM16 Line Code, G.991.2 and G.994.1 standards, and equipped with one Ethernet switch with 4 * 10/100BaseTX auto-sensing ports. X3102r SHDSL Router provides a basic Internet access via 10/100Mbps Ethernet switch and SHDSL WAN port with routing function over SHDSL. - Page 4 X3102r user manual V. 2.0 Local OAM&P through command line interface via RS-232 Craft port Configuration and management by local Telnet, SNMP, and WEB Browser through the Ethernet interface and remotely through SHDSL interface Firmware upgradeable through TFTP High performance, simple operation and low power...
-
Page 5: Packaging
X3102r user manual V. 2.0 II. Packaging This package consists of the following items X3102r ADSL unit device RJ-45 cable RJ-11 cable AC adapter 1. 1. Manual CD 5 / 33... -
Page 6: Front Panel
X3102r user manual V. 2.0 Appearance Front Panel ALM: “Blink” while booting up, and “On” when there is an error. WAN: “Blink” while training with DSLAM and “On” when SDSL link is ready LAN: “On” while one of Ethernet ports is properly connected to a LAN or PC ACT: “Blink”... -
Page 7: Hardware Installation
1. Connect the DSL cable, as (1) indicated, to the LINE port of RJ-11 socket. 2. Use a RJ-45 cable, as (2) indicated, to connect the X3102r to the LAN or a PC with Ethernet adapter installed. 3. Use a 9-pin RS-232 cable, as (3) indicated, to connect the... -
Page 8: Management
V. 2.0 Management X3102r supports simple, flexible and easy-to-operate methods for management purpose. X3102r can be managed via the following paths. Refer to Appendix B for detailed information. ! Console Port – use the RS-232 cable for connecting X3102r to a console terminal or a PC running terminal emulation program, such as Hyper Terminal, see Appendix A for proper console setup. -
Page 9: Default Values
X3102r user manual V. 2.0 Default Values X3102r is pre-configured with the following parameters; you may also re-load the default parameters by selecting Default from the main menu. For hub operation, only half-duplex mode will be allowed. Default Mode: Bridge... -
Page 10: Software Upgrade
Extract the ZIP file for updated firmware. Connect X3102r via the local Ethernet port or remote DSL link, make sure the X3102r Ethernet IP address and your terminal are properly configured so that you can successfully “ping”... -
Page 11: Appendix A Specifications
X3102r user manual V. 2.0 Appendix A Specifications Hardware Specifications Local Interface • 4 * 10/100BaseTX Ethernet switch, IEEE 802.3u, RJ-45 connectors • 10 Half, 10Full, 100Half, 100Full, Auto Negotiation configurable for each port • Support port-based VLAN WAN SHDSL Line Interface •... -
Page 12: Software Specifications
X3102r user manual V. 2.0 Software Specifications • ATM Cell over SHDSL, AAL5 • Support UBR & CBR & VBR-nrt & VBR-rt • VPI Range (0-4095) and VCI range (1-65535) • Support up to 8 PVCs for bridge and 5 PVCs for router •... -
Page 13: Product Warranty
X3102r user manual V. 2.0 Appendix B Warranties and FCC Regulations B-1 Product Warranty 1. XAVi Technologies warrants that the ADSL unit will be free from defects in material and workmanship for a period of twelve (12) months from the date of shipment. -
Page 14: Fcc Part 15 Notice
X3102r user manual V. 2.0 repair or replace a defective product covered under warranty within ten (10) days of receipt of the product. The warranty period for the replaced products shall be ninety (90) days or the remainder of the warranty period of the original unit, whichever is greater. -
Page 15: Ic Cs-03 Notice
X3102r user manual V. 2.0 B-3 IC CS-03 Notice The Industry Canada label identifies certified equipment. This certification means that equipment meets certain telecommunications network protective, operational, and safety requirements as prescribed in appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee that the equipment will operate to the user’s... -
Page 16: Console Set Up
X3102r user manual V. 2.0 C C C C h h h h a a a a r r r r p p p p t t t t e e e e r r r r h h h h... -
Page 17: How To Switch Between Bridge And Router
X3102r user manual V. 2.0 − Line delay: 0 milliseconds − Character line feeds incoming line ends: enable II. How to Switch between Bridge and Router Please see the command below for detailed command setting. MODE Select the device as Bridge or router mode... - Page 18 X3102r user manual V. 2.0 EXAMPLE >>mode (with “enter” key to execute) Please select bridge or router: (b/r,r) b (with “enter” key to execute) Current mode is bridge. 2. Set Up RFC 1483 Bridge 2.1 RFC1483 bridging connection. Allow only one client passing ADSL modem to access WAN network.
-
Page 19: Seting Up Router
X3102r user manual V. 2.0 The following (example) will be displayed for checking your setting. Configuration MODE: Bridge FUNCTION: R1483 Spanning Tree: Enable # VPI Package filter 1: 2 Preserve the configuration (y/n): (select “y” to use the setting or “n” to leave without change. Start... -
Page 20: Set Up 1483 Routing
X3102r user manual V. 2.0 MODE Select the device as Bridge or router mode Parameters: The default is bridge mode. Syntax: mode EXAMPLE >>mode (with “enter” key to execute) Please select bridge or router:(b/r,b) r (with “enter” key to execute) - Page 21 X3102r user manual V. 2.0 2.2 Step by Step Setting >>quick (with “enter” key to execute) R1483(r)/ IPoA(i)/ PPPoA(p)/ PPPoE(pe): (select “r” for 1483 routing) Ethernet IP (192.168.1.1): (set LAN IP address) Subnet Mask (255.255.255.0): (set mask) VPI(0-1023): (set VPI value)
- Page 22 X3102r user manual V. 2.0 2.3 NAT function This function will enable PC users in your LAN environment to access outside with only one IP address (IP sharing) and one access account. Use the following example to enable NAT function for RFC1483 routing.
-
Page 23: Set Up Ipoa Routing
X3102r user manual V. 2.0 2.4 Save the configuration to router permanently and make settings effective by following steps below >pat> home (with “enter” key to execute) You can use “show” command to check your setting again. >>save (with “enter” key to execute) Use “save”... - Page 24 X3102r user manual V. 2.0 3.2 Step by Step Setting >> quick R1483(r)/ IPoA(i)/ PPPoA(p)/ PPPoE(pe): (select “i” for IPoA routing) Ethernet IP (192.168.1.1): (set LAN IP address) Subnet mask (255.255.255.0): (set mask) VPI(0-1023): (set VPI value) VCI(1-65535): (set VCI value)
- Page 25 X3102r user manual V. 2.0 Use the following example to enable NAT function for IPoA routing. >pat ( with “enter” key to go to pat director) >pat>setpat 192.168.1.3 enable >pat>setpat 192.168.1.3 enable (Enable NAT function for IPoA routing for specific WAN IP address.
-
Page 26: Set Up Pppoa Routing
X3102r user manual V. 2.0 >> save (with “enter” key to execute) Wait until the following message displayed on your screen completely. Don’t power off the modem during this stage. Saving configuration... Configuration saved. Updating flash filing system ... SDRAM size = 0x800000 Booting... - Page 27 X3102r user manual V. 2.0 R1483(r)/ IPoA(i)/ PPPoA(p)/ PPPoE(pe): (select “p” for PPPoA routing) Ethernet IP (192.168.1.1): (set LAN IP address) Subnet mask (255.255.255.0): (set mask) VPI(0-1023): (set VPI value) VCI(1-65535): (set VCI value) Authentication(PAP(p)/CHAP(c)/None(n)): (select authentication method) User name: (set user name from ISP)
- Page 28 X3102r user manual V. 2.0 If you have any application or server in your LAN environment, which is available for outside uses, please configure the PAT (port address translation) table to enable this kind of service by following the example below, otherwise continue to section 4.4...
-
Page 29: Set Up Pppoe Routing
X3102r user manual V. 2.0 5 Set up PPPoE Routing 5.1 PPPoE (PPP over Ethernet) routing connection. Allow one client or multi-clients (need extra HUB) passing ADSL modem, using PPPoE routing to access WAN network. 192.168.1.50 210.62.8.2 210.62.8.1 DSLAM ISP/Corporate... - Page 30 X3102r user manual V. 2.0 The following (example) will be displayed for checking your setting Setup Configuration FUNCTION: PPPOE Ethernet IP: 192.168.1.1 Subnet Mask: 255.255.255.0 # VPI AUTH USERID 1: 8 xavi Preserve the configuration (y/n): (“y” to use the setting or “n”...
-
Page 31: Set Up Dhcp Server Function
X3102r user manual V. 2.0 (434- port number of services or application to offer) (udp – protocol used. Use ”tcp” for tcp/ip services) (210.18.35.10 – IP address of server offered for access from outside. Use correct IP Address instead) 5.4 Save the configuration to router permanently and make settings effective by following steps below >pat>... - Page 32 X3102r user manual V. 2.0 commands) >lan>dhcpserver 192.168.1.1 192.168.1.10 192.168.1.20 192.168.1.30 (There are two range of IP segment allowed for DHCP server. Both segment must be in the same subnet with LAN IP address. Refer to the LAN IP address set for the routing function (RFC1483 or IPoA or PPPoA or PPPoE) previously.
-
Page 33: Dns Relay Setting
X3102r user manual V. 2.0 7 DNS (Domain name server) Relay Setting The DNS relay function allows DNS request to be terminated in the router. To make this function effective, the DNS address on PCs should be set to the LAN IP address of router. Refer to the LAN IP address set for the routing function (RFC1483 or IPoA or PPPoA or PPPoE) previously.
