X8121r User’s Manual Version 1.1 Revision Date Notes V 1.0 May 8, 2003 Software: 3.51XAT1.8121A/138030331a3 V 1.1 June 10, 2003 Software: 3.51XAT1.8121A/138030331a3 5 / 71...
I. Overview X8121r is multi-mode ADSL Router, compliant with ANSIT1.413 Issue 2, ITU G.992.1 (G.dmt) Annex A/B, G.992.2 (G.lite). X8121r provides high-speed Internet access via one WAN port over ATM over ADSL, and also connects to a corporate network via one 10/100BaseT Ethernet port.
X8121r User’s Manual Version 1.1 II. Features High speed asymmetrical data transmission on a single twisted copper pair Full rate operations up to 8Mbps downstream (12Mbps to be provided) and up to 1Mbps upstream. G.lite operation up to 1.5Mbps downstream and 512Kbps upstream...
X8121r User’s Manual Version 1.1 III. Packaging This package consists of the following items: X8121r ADSL device unit RJ-45 Cable RJ-11 Cable AC Adapter User’s Manual CD 8 / 71...
X8121r User’s Manual Version 1.1 Appearance Front Panel Label Color Description Status 100M Green 100M Ethernet transmitting. Green 10M Ethernet transmitting. Green Power supply is connected. Blinking Green Training with DSLAM.
RJ-45 port; connect to a PC or LAN. RESET Reset the modem back to factory settings by holding down on this button. RJ-11 or RJ-45 port; connect to the ADSL outlet. X8121r uses RJ-11 Cable. X8121r-B uses RJ-45 Cable. 10 / 71...
RJ-11 cable and X8121r-B uses RJ-45 cable) 2. Use a RJ-45 cable to connect one end to the Ethernet port of X8121r, and the other end to the LAN or a PC with an Ethernet adapter installed. 3. Plug in the AC adapter to the AC power socket, and then connect the DC jack to the PWR inlet of X8121r.
Local Ethernet Port (Telnet) – connect the Ethernet port to your local area network or directly to a PC. “Telnet” X8121r from any workstation in the LAN. The default local Ethernet IP address is “192.168.1.1”. Local Ethernet Port (Web Browser) – connect the Ethernet port to your local area network or directly to a PC.
X8121r User’s Manual Version 1.1 VII. Default Values X8121r is pre-configured with the following parameters; you may also re-load the default parameters by rebooting the router into the Default configuration from the web browser. Default Mode: Bridge Login Name: admin...
Then reboot to the default values of X8121r with new software. Note 1: X8121r software may also be upgraded through the web interface. See Chapter 2: G. Admin, 3. Image Upgrade Note 2: Strictly maintain stable power to X8121r while upgrading its software.
X8121r User’s Manual Version 1.1 Chapter 2 Web Interface Management I. Overview The Web management is provided in order to manage the ADSL device as easily as possible. It provides a very user-friendly configuration and graphical interface through a Web based platform.
X8121r User’s Manual Version 1.1 III. Login The window Enter Network Password will pop up while starting the configuration. With the window open, type admin for both the Username and the Password. You can also edit the Username and Password or add new users. (For further details, see G.
X8121r User’s Manual Version 1.1 A. HOME After logging in, the first tab that will be displayed is the Home tab. Under this tab, the System View page is displayed. This page displays a summary of the interfaces and their settings.
Page 18
X8121r User’s Manual Version 1.1 This page is divided into five sections. The table below describes each section. Section Name Description Device Displays model name, hardware/software version, device mode, uptime, current time, time zone, daylight savings time, and domain name.
X8121r User’s Manual Version 1.1 B. LAN Click on the LAN tab to view its sub-menu’s and configure the LAN settings. The four sub-menu’s are: LAN Config, DHCP Mode, DHCP Server, and DHCP Relay. Each sub-menu is described below. 1. LAN Config...
Page 20
X8121r User’s Manual Version 1.1 2. DHCP Mode Click on the DHCP Mode link to select a DHCP setting. From the drop down list, select DHCP Server, DHCP Relay, or None. Click on the Submit button when completed. 3. DHCP Server Click on the DHCP Server link to view the DHCP Server settings.
X8121r User’s Manual Version 1.1 4. DHCP Relay Click on the DHCP Relay link to view the DHCP Relay settings. Fill in the DHCP server IP address in the text boxes and select an interface name from the dorp down list, then click on the Add button to complete the DHCP Relay configuration.
Page 22
X8121r User’s Manual Version 1.1 a) DSL Parameters Click on the DSL Param button to view the DSL parameters. Another window will then display the DSL parameters, which may be different due to the type and speed of the network.
Page 23
X8121r User’s Manual Version 1.1 b) DSL Stats Click on the Stats button to view the DSL status. Another window will then display the DSL status, which may be different due to the type and speed of the network. Click on the Close button to close the window, or click on the Refresh button to refresh the status.
Page 24
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. First select a VC interface from the drop down list. Then enter the VPI, VCI values into the text box. Select a Mux type from the drop down list, and then enter the number of protocols per AAL5 in the text box.
Page 25
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. The following is a list of field names and their descriptions. After filling in the table click on the Submit button when completed.
Page 26
X8121r User’s Manual Version 1.1 Interface Sec Type Select between public, private, or DMZ. Status Select start, stop, or start on data. Protocol Select between PPPoA or PPPoE. Service Name Enter a name for this service in the text box.
Page 27
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. The following is a list of field names and their descriptions. After filling in the table click on the Submit button when completed.
Page 28
X8121r User’s Manual Version 1.1 IP over ATM (IPoA) Click on the IPoA link to view the IP over ATM configuration table. This table displays IPoA information such as: interface name, interface security type, lower interface, config IP, network IP, subnet mask gateway IP, and status.
X8121r User’s Manual Version 1.1 D. Bridging Click on the Bridging tab to view its sub-menu’s and configure the bridge settings. The six sub-menu’s are: Bridging, LAN Config, DSL, ATM VC, and RFC 1483 Interface (EoA). The bridging sub-menu is described below.
X8121r User’s Manual Version 1.1 E. Routing Click on the Routing tab to view its sub-menu’s and configure the routing settings. The eight sub-menu’s are: IP route, IP address, LAN Config, DSL, ATM VC, PPP, EoA, and IPoA. The IP route sub-menu is described below.
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. The following is a list of field names and their descriptions. After filling in the table click on the Submit button when completed.
Page 32
X8121r User’s Manual Version 1.1 The three options are: NAT Global Info, NAT Rule Entry, and NAT translations. Each one is described below. a) NAT Global Info The table displays the idle times for several protocols; you may change the times and then click on the Submit button.
Page 33
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. The following is a list of field names and their descriptions. After filling in the table click on the Submit button when completed.
Page 34
X8121r User’s Manual Version 1.1 down list, or enter it into the text box. Destination Port To Select a destination port from the drop down list, or enter it into the text box. Local Port Select a local port from the drop down list, or enter it into the text box.
Page 35
X8121r User’s Manual Version 1.1 Firewall Click on the Firewall link to view the Firewall Configuration table. The Firewall adds security to your network by protecting it from Internet intruders. 35 / 71...
Page 36
X8121r User’s Manual Version 1.1 The following is a list of field names and their descriptions. After filling in the table click on the Submit button Field Name Description Blacklist Status Select enable or disable blacklist. Blacklist Period Enter a time period to hold the blacklist.
Page 37
X8121r User’s Manual Version 1.1 Click on the Session to view the IP filter sessions. You may delete a session by clicking on the trash can icon. Click on the Close button to close the window. ...
Page 38
X8121r User’s Manual Version 1.1 The following is a list of field names and their descriptions. After filling in the table click on the Submit button Field Name Description Rule ID Enter a Rule ID. Direction Select an incoming or outgoing direction.
Page 39
X8121r User’s Manual Version 1.1 In Interface Select an incoming interface from the drop down list. Security Level Select a security level: high, medium, or low. Log Tag Enter a name for the log. Start Time Enter a start time for the IP filter.
Page 40
X8121r User’s Manual Version 1.1 5. Domain Name Service (DNS) Click on the DNS link to view the DNS Configuration table. This page is used for adding and deleting DNS server IP addresses. You may also enable/disable DNS relay from this page.
X8121r User’s Manual Version 1.1 G. Admin Click on the Admin tab to view its sub-menu’s and configure the admin settings. The six sub-menu’s are: User Config, Commit & Reboot, Local Image Upgrade, Remote Image Upgrade, Alarm, Diagnostics, and Port Settings. Each one is described in detail below.
Page 42
X8121r User’s Manual Version 1.1 After you click on the Add button, another window will pop-up. The following information is required in order to create a new user. Click on the Submit button when completed. Field Name...
Page 43
X8121r User’s Manual Version 1.1 2. Commit & Reboot Click on the Commit & Reboot link to view the reboot options. This page is used to save the changes into the device’s memory and reboot the device using different options.
Page 44
X8121r User’s Manual Version 1.1 3. Local Image Upgrade Click on the Local Image Upgrade link to upgrade the software on the modem. You may easily upgrade X8024r embedded software by obtaining the compressed upgrade kit from the service provider and then following the steps: a.
Page 45
X8121r User’s Manual Version 1.1 4. Remote Image Upgrade Click on the Remote Image Upgrade link to upgrade the software on the modem. Enter the IP address where the software is located, the name of the software, and the User name and password of the site.
Page 46
X8121r User’s Manual Version 1.1 6. Diagnostics Click on the Diagnostics link to test the device. Results will be displayed as pass, fail, or N.A, depending on your settings. Click on the Submit button to begin the diagnostic tests.
X8121r User’s Manual Version 1.1 Chapter 3 Quick Protocol Setup Overview This chapter provides quick steps on setting up the protocols on this device. From this point on, configuration steps are listed for each of the protocols in their respective sections. The seven sections are: A.
X8121r User’s Manual Version 1.1 A. RFC 1483 Bridge Configuration Table: Protocol RFC1483 Bridge Mode. WAN IP The ISP assigns the IP address, or have an IP address assigned from an external/internal DHCP server. Modem IP 192.168.1.1 Gateway IP None.
Page 49
X8121r User’s Manual Version 1.1 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. 4. Click on the EoA link below the WAN tab.
Page 50
X8121r User’s Manual Version 1.1 6. Click on the Bridging tab to view its sub-menu’s and configure the bridging settings, then click on the Bridging link below it. 7. Select EOA-1 from the drop down list, and click on the Add button.
X8121r User’s Manual Version 1.1 B. PPPoE Route Configuration 1. Click on the WAN tab to view its sub-menu’s and configure the WAN settings, then click on the PPP link below it. 2. You will then see the PPP Configuration table. Click on the Add button to add a new PPPoE setting.
X8121r User’s Manual Version 1.1 C. RFC 1483 + NAT Configuration Table: Protocol RFC1483 Mode + NAT. LAN IP 192.168.1.xxx or assigned by DHCP server. Modem IP 192.168.1.1 WAN IP 210.62.8.3 VPI/VC Value 8/81 1. Click on the WAN tab to view its sub-menu’s and configure the WAN settings, then click on the ATM VC link below it.
Page 53
X8121r User’s Manual Version 1.1 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. 4. Click on the EoA link below the WAN tab.
Page 54
X8121r User’s Manual Version 1.1 7. Click on the Services tab to view its sub-menu’s and configure the NAT settings, then click on the NAT link below it. 8. Select NAT Rule Entry from the NAT configuration drop down list. Then click on the Add button to add a NAT entry.
X8121r User’s Manual Version 1.1 D. PPPoA Route Configuration Configuration Table: Protocol PPPoA Route Mode. LAN IP 192.168.1.xxx Modem IP 192.168.1.1 Gateway IP Not required. VPI/VCI 8/81 Username From ISP. Password From ISP. 1. Click on the Routing tab to view its sub-menu’s and configure the Routing settings, then click on the ATM VC link below it.
Page 56
X8121r User’s Manual Version 1.1 4. Click on the PPP link in the Routing tab, and then click on the Add button to add a PPPoA configuration. 5. Select an interface name: PPP-1 6. Select a protocol: PPPoA 7. Default Route: Enable 8.
Page 57
X8121r User’s Manual Version 1.1 13. Select the Reboot from last configuration option from the drop down list, and the click on the Commit and Reboot button. 57 / 71...
X8121r User’s Manual Version 1.1 E. IPoA Route Configuration Configuration Table: Protocol IPoA Route Mode LAN IP 192.168.1.xxx Modem IP 192.168.1.1 Gateway IP 210.62.8.1 VPI/VCI 8/81 WAN IP 210.62.8.2 1. Click on the Routing tab to view its sub-menu’s and configure the Routing settings, then click on the ATM VC link below it.
Page 59
X8121r User’s Manual Version 1.1 4. Click on the IPoA link in the Routing tab, and then click on the Add button to add an IPoA configuration. 5. Select an interface name: IPoA-0 6. Conf. IP Address: From ISP 7. Net mask: From ISP 8.
X8121r User’s Manual Version 1.1 F. DHCP Configuration 1. Click on the LAN tab to view its sub-menu’s and configure the LAN settings, then click on the DHCP Mode link below it. 2. From the drop down list, select DHCP Server, and click on the Submit button.
Page 61
X8121r User’s Manual Version 1.1 4. Start IP Address: Enter the Start IP Address (192.168.1.2) 5. End IP Address: Enter the End IP Address (192.168.1.13) 6. Net mask: based on IP address (255.255.255.0) 7. Domain Name: Enter a name here 8.
X8121r User’s Manual Version 1.1 G. NAT Configuration 1. Click on the Services tab to view its sub-menu’s and configure the NAT settings, then click on the NAT link below it. 2. From the NAT Options drop down list, select NAT Rule Entry.
Page 63
X8121r User’s Manual Version 1.1 4. Rule Flavor: Select a Rule flavor from the drop down list (Basic) 5. Rule ID: Enter a number here 6. Local Address From: Address from where this device will receive IPs 7. Local Address to: 255.255.255.255 (broadcast) or other 8.
X8121r User’s Manual Version 1.1 Appendix A – Specifications A1. Hardware Specifications Local Interface One 10/100BaseT Ethernet port, IEEE 802.3, RJ-45 connector WAN ADSL Line Interface For ADSL over POTS, compliant with ITU G.992.1 (G.dmt) Annex A, ITU G.992.2 (G.lite), and ANSI T1.413 issue 2...
X8121r User’s Manual Version 1.1 Appendix B – Warranties B1. Product Warranty 1. XAVi Technologies warrants that the ADSL unit will be free from defects in material and workmanship for a period of twelve (12) months from the date of shipment.
X8121r User’s Manual Version 1.1 B2. Warranty Repair 1. During the first three (3) months of ownership, XAVi Technologies will repair or replace a defective product covered under warranty within twenty-four (24) hours of receipt of the product. During the fourth (4th) through...
X8121r User’s Manual Version 1.1 Appendix C – Regulations C1. FCC Part 15 Notice Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 to the FCC rules.
X8121r User’s Manual Version 1.1 C2. IC CS-03 Notice The Industry Canada label identifies certified equipment. This certification means that equipment meets certain telecommunications network protective, operational, and safety requirements as prescribed in appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee that the equipment will operate to the user’s satisfaction.
X8121r User’s Manual Version 1.1 C3. UL Notice The following markings and instructions are provided as bellow. "Disconnect TNV circuit connector before removing cover" or equivalent. "Disconnect TNV circuit connector(s) before disconnecting power." (Instruction) Including the following: -Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
X8121r User’s Manual Version 1.1 Contact Information You can help us serve you better by sending us your comments and feedback. Listed below are the addresses, telephone and fax numbers of our offices. You can also visit us on the World Wide Web www.xavi.com.tw...
