XAVI Technologies Corp. X7005Q User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X7005Q
ADSL USB MODEM
Copyright
2002 XAVi Technologies Corporation
©
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X7005Q and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XAVI Technologies Corp. X7005Q

Summary of Contents for XAVI Technologies Corp. X7005Q

  • Page 1 X7005Q ADSL USB MODEM Copyright 2002 XAVi Technologies Corporation © All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents ABOUT THIS MANUAL .......................... 1 PREFACE..............................2 X7005Q DSL USB M ..................... 2 ODEM ANUAL CHAPTER 1: OVERVIEW........................3 ADSL ............................3 BOUT ................... 3 ROTOCOL AND EVICE RIVER ELECTION ............................. 5 EATURES CHAPTER 2: HARDWARE AND SOFTWARE INSTALLATION ............6 ........................

  • Page 3: About This Manual

    About This Manual This manual provides a comprehensive user’s guide and installation manual for X7005Q DSL USB Modem. It has been organized in such a way to make it easy to be followed by users worldwide. In order to ensure optimal comprehension, the following list provides brief descriptions of the terms used throughout the manual.

  • Page 4: Preface

    Preface X7005Q DSL USB Modem User Manual This manual contains information regarding the installation, operation, and configuration of X7005Q DSL USB Modem. Additionally, it outlines the usage of the Control Panel Application. There are 6 chapters. Chapter 1: • “Overview” offers a brief description of ADSL, protocol and device driver selection, and the features of the X7005Q DSL USB Modem.

  • Page 5: Chapter 1: Overview

    C as applicable. Protocol and Device Driver Selection X7005Q DSL USB Modem can be easily connected to a USB port on the PC via a standard USB cable. X7005Q DSL USB Modem’s new features are easily upgraded by downloading a new version of the device driver onto your PC from our company’s FTP site.
  • Page 6 Chapter 1: Overview modem appear as a local area network (LAN) device to the operating system. RFC 1577 – this is another local area network like protocol for IP address and ATM address mapping. Point to Point Protocol (PPP) Over Ethernet (RFC 2516) - This protocol makes the modem appear as a local area network (LAN) device to the operating system.

  • Page 7: Features

    Chapter 1: Overview Features • Compliant with Universal Serial Bus Specification Revision 1.1 • USB bus-powered; an external power supply is not required • Supports three device drivers: Microsoft NDIS 4.0 WAN Miniport, NDIS 4.0 LAN Miniport or NDIS 5.0 ATM Miniport •...

  • Page 8: Chapter 2: Hardware And Software Installation

    Chapter 2: Hardware and Software Installation The following information may be required for software installation. Contact your DSL service provider before proceeding with software installation. • IP Address Settings – the software installation process allows the server to assign IP Address dynamically.

  • Page 9: Hardware Installation

    SETUP.EXE to run the setup program. 5. Plug the square end of the USB cable into the USB port of the X7005Q DSL USB Modem, when prompted. (See figure 1 below) 6. Plug the other rectangular end of a USB cable into the USB port of your PC.

  • Page 10: Software Installation

    SETUP.EXE to run the setup program. 3) Use one USB cable to connect X7005Q modem with your PC. 1. When the Installation CD is inserted, a “Welcome” dialogue will appear. Click Next. 2. A “License Agreement” dialogue will be displayed. Click Accept.
  • Page 11 Chapter 2: Hardware and Software Installation 3. Select “Other Service Provider” and click Next. 4. Select the driver type you want to install and click Next. You could get ATM, LAN and WAN information from your service provider. 5. In the “Communication Settings” dialogue, check the VPI, VCI, Encapsulation and Modulation information provided by your service provider.
  • Page 12 Chapter 2: Hardware and Software Installation You can review the current settings in the “Ready to Install” dialogue. Click Back to change the settings, or click Next to accept it. 7. Installation program is searching for the USB modem. Plug in the USB modem now if you haven’t plugged it in to your computer yet.
  • Page 13 Chapter 2: Hardware and Software Installation 9. After rebooting the computer, click Finish to start using USB modem. 10. You have to input the location information for WAN and ATM applications and then click Note: For WAN and ATM applications, dial-up is required to connect to the Internet. Go to Start Settings Network and Dial-up Connections...

  • Page 14: Chapter 3: Customizing Communication Settings

    Chapter 3: Customizing Communication Settings Chapter 3: Customizing Communication Settings Once X7005Q DSL USB Modem and software have been plugged in and installed, the communication settings are easily updated by the following steps: 1. From your PC desktop click Start...

  • Page 15: Chapter 4: Control Panel Application

    Status flashes in green indicates that a connection has been made. The Data Activity flash in yellow indicates Transmitting and Receiving. 3. In the “System Info” tab, it displays the release number of the X7005Q DSL Modem driver, the firmware release number, and the control panel version that you are currently...
  • Page 16 Chapter 5: Control Panel Application 4. In the “Configuration” tab, it offers driver appropriate Modulation, Encapsulation, and VPI and VCI values. If you are using a WAN or ATM driver, only Modulation type will be displayed and. In the LAN applications, Modulation type, Encapsulation type, and VPI and VCI values will be displayed.

  • Page 17: Chapter 5: Uninstallation

    Chapter 5: Uninstallation Chapter 5: Uninstallation Remove the X7005Q DSL USB Modem software drivers by the following steps: Note: The USB cable should not be unplugged until the uninstallation process has been completed. For Windows 98 applications, the cable must be unplugged immediately following the steps as below.
  • Page 18 Chapter 5: Software Uninstall 5. Please unplug your modem from the computer now. Click OK. 6. The “Setup Complete” window indicates successful completion of the uninstall process. Remove any disks from the drives, select the Yes, I want to restart my computer now option.

  • Page 19: Appendix A: Modifying Tcp/Ip Networking Options

    Appendix A: Modifying TCP/IP Options – WAN USB Driver Appendix A: Modifying TCP/IP Networking Options WAN USB Driver Microsoft Windows 98, First and Second Editions TCP/IP settings are automatically set up during the software installation process. The following procedure may be used to change TCP/IP settings, if necessary. 1.
  • Page 20 Appendix A: Modifying TCP/IP Options – WAN USB Driver 5. Please follow the steps below: • Change the IP address to a user defined address by selecting Specify an IP address and typing the address in the space. • Change the Domain Name Server addresses to a user defined address by selecting Specify domain name server addresses and type the addresses in the space.

  • Page 21: Microsoft Windows 2000

    Appendix A: Modifying TCP/IP Options – WAN USB Driver Microsoft Windows 2000 1. From your PC desktop, right click the My Network Places icon and select Properties. 2. In the “Network and Dial-Up Connections” window, right click the Dial-Up PPP Connection icon and click Properties.
  • Page 22 Appendix A: Modifying TCP/IP Options – WAN USB Driver 5. In the “Internet Protocol (TCP/IP) Properties” dialogue, it is the place to modify the IP address and DNS Server addresses. • Change the IP address to a user defined address by selecting Use the following IP address and type the address in the space.
  • Page 23 Appendix A: Modifying TCP/IP Options – WAN USB Driver...

  • Page 24: Microsoft Windows Me

    Appendix A: Modifying TCP/IP Options – WAN USB Driver Microsoft Windows Me 1. From your PC desktop, open the Dial-Up Networking window (Start Settings Dial- Up Networking). 2. In the “Dial-Up Networking” dialogue, right click the Dial-Up PPP Connection icon and select Properties.
  • Page 25 Appendix A: Modifying TCP/IP Options – WAN USB Driver • Change the IP address to a user defined address by selecting Specify an IP address and type the address in the space. • Change the Domain Name Server addresses to user defined addresses by selecting Specify name server addresses and type the addresses in the space.

  • Page 26: Microsoft Windows 98, First And Second Editions

    Appendix A: Modifying TCP/IP Options – LAN USB Driver LAN USB Driver Microsoft Windows 98, First and Second Editions TCP/IP settings are automatically set up during the software installation process. The following procedure may be used to change TCP/IP settings, if necessary. 1.
  • Page 27 Appendix A: Modifying TCP/IP Options – LAN USB Driver 4. To remove a previously installed gateway, highlight the one in the Installed gateways list and click Remove. • To add a new gateway, type the address in the New gateway field and click Add. The new gateway will appear in the Installed gateways list.
  • Page 28 Appendix A: Modifying TCP/IP Options – LAN USB Driver Microsoft Windows 2000 1. From the PC desktop, right click My Network Places icon and select Properties. 2. Double click the Local Area Connection icon from the “Network and Dial-Up Connections” dialogue. 3.
  • Page 29 Appendix A: Modifying TCP/IP Options – LAN USB Driver Note: The Advanced button of the “Internet Protocol (TCP/IP) Properties” window may be used to alter IP settings, DNS server addresses, WINS addresses, IP security options, and TCP/IP filtering options. 5. Click OK after the new setting. 6.
  • Page 30 Microsoft Windows Me 1. From the PC desktop, right click My Network Places icon and select Properties. 2. In the configuration tab, select TCP/IP -> X7005Q USB ADSL LAN Modem. Click Properties. 3. In the IP Address tab, select either the Obtain an IP address Automatically or Specify an IP Address option, depending on your network setting.
  • Page 31 Appendix A: Modifying TCP/IP Options – LAN USB Driver 4. In the “Gateway” tab, you can add or remove gateways. Contact with your network administrator to determine which option is the best result for your needs. • To add a new gateway, type the address in the New gateway field and click Add. The new gateway will appear in the Installed gateways list.

  • Page 32: Microsoft Windows 98, Second Edition

    Appendix A: Modifying TCP/IP Options – ATM USB Driver ATM USB Driver Microsoft Windows 98, Second Edition TCP/IP settings are automatically set up during the software installation process. Change TCP/IP settings by the following procedure. 1. From your PC desktop, double click the My Computer icon. 2.
  • Page 33 Appendix A: Modifying TCP/IP Options – ATM USB Driver • Select Specify an IP address Change the IP address to a user defined address and type the address in the space. • Select Specify name server addresses and change the Name Server addresses to a user defined address by and type the addresses in the space.
  • Page 34 Appendix A: Modifying TCP/IP Options – ATM USB Driver Microsoft Windows 2000 1. From your PC desktop, right click My Network Places icon and select Properties. 2. From the “Network and Dial-Up Connections” window, right click the Dial-Up PPP Connection icon and click Properties. 3.
  • Page 35 Appendix A: Modifying TCP/IP Options – ATM USB Driver Note: The “Advanced” button of the “Internet Protocol (TCP/IP) Properties” dialogue may be used to alter DNS address, WINS address and IP security settings. 5. Click OK after the new setting. 6.
  • Page 36 Appendix A: Modifying TCP/IP Options – ATM USB Driver Microsoft Windows Me 1. From your PC desktop, open the Dial-Up Networking window (Start Settings Dial- Up Networking). 2. In the “Dial-Up Networking” dialogue, right click the Dial-Up PPP Connection icon and click Properties.
  • Page 37 Appendix A: Modifying TCP/IP Options – ATM USB Driver • Change the default gateway by leaving the box blank to the left of Use default gateway on remote network. Click OK. 5. The “ Dial-Up PPP Connection” window will be redisplayed. Click OK to complete the whole setting.

  • Page 38: Appendix B: Point-To-Point Protocol Over Ethernet

    The PPP Protocol information is encapsulated within an Ethernet frame. X7005Q DSL USB Modem supports PPPoE by installing the third party Ethernet software. The installation procedure as follows: 1. Install X7005Q DSL USB Modem by selecting LAN (RFC1483) driver.

  • Page 39: Appendix C: Specifications

    Appendix C: Specifications Appendix C: Specifications Data Transfer Rates ANSI T1.413 / ITU G.992.1 Data Rates Data rates for DMT mode are partitioned at 32 kb/s increments for both the upstream and downstream data rates adhering to the DMT Standards. The downstream data rates extend from 32 kb/s to 8.064 Mb/s.

  • Page 40: Software Requirements

    • Microsoft Windows XP Hardware Requirements X7005Q DSL USB Modem is a complete reference design. Substitution of components specified by XAVi with unspecified components may cause degradation in performance. XAVi cannot guarantee performance when components have been substituted, thus altering the reference design.

  • Page 41: Appendix D: Fcc/Industry Canada Required Information

    Appendix D: FCC Required Information Appendix D: FCC/Industry Canada Required Information FCC Required Information: 1. This equipment complies with Part 68 of the FCC rules. This unit bears a label, which contains the FCC registration number and ringer equivalence number (REN). If requested, this information must be provided to the telephone company.

  • Page 42: Industry Canada Required Information

    Appendix D: FCC Required Information Industry Canada Required Information EQUIPMENT ATTACHMENTS LIMITATIONS To ensure that certified equipment is attached correctly and only to the networks of participating carriers, the following statement shall accompany each unit of certified equipment offered for sale. This statement must be included conspicuously in written or electronic format, at or near the front of each copy of the operating manual, or accompany other technical information, or be included as a separate sheet.
