UTStarcom PPC6800 Quick Start Manual page 7

No. Item
14 Jog Wheel
15 OK Button
16 VOICE COMMAND Button Press to start Voice Speed Dial; press and hold to record a voice note.
17 WLAN Switch
18 Camera
19 Flash Light
20 Speaker
21 Battery Cover Latch
22 Battery Cover
23 POWER Button
24 COMM MANAGER Button
25 CAMERA Button
Function
While on the Today screen or using applications, scroll up or down to navigate through
menus or program instructions; press the wheel to carry out a selection. During a call or
while playing music, scroll up or down to adjust the sound volume.
Press to confirm your data entries, or to exit the program in use.
Slide up to turn Wi-Fi on, down to turn Wi-Fi off.
Use the camera to take still photos and record video clips.
When turned on, it illuminates your subject and allows you to capture clear photos or
video in dark-lit environments.
Used when speaker mode has been enabled, and to listen to media.
Press downward to release the battery cover.
After pressing down the cover latch, remove the battery cover to access the battery
compartment.
• Press and hold to turn on the device.
• Press to turn off the display temporarily. This switches your device to Sleep mode. You
can still receive calls and messages when your device is in Sleep mode.
• Press and hold (for about 5 seconds) to turn off the power completely. All functions
including the phone will be unavailable for use.
Press to open the Comm Manager. Comm Manager lets you easily turn on/off your
device's connections (such as Bluetooth, Wi-Fi, enable 'Flight Mode' and cellular data
connection), ringer, phone, etc.
Press to launch the Camera; press again to take a photo or video clip, depending on the
specified capture mode.
7
