No. Item
1
MESSAGING Button
2
Notification LED 1
3
Earpiece
4
Notification LED 2
5
INTERNET EXPLORER
Button
6
Hardware Keyboard
7
Touch Screen
8
Left and Right SOFT
KEYS
9
TALK Button
10
START Button
11
NAVIGATION
Control/ ENTER
12
OK Button
13
END Button
Function
Press to access your messages.
This LED shows the following:
A blinking Blue light when the Bluetooth system is powered-up and ready to transmit radio
frequency signal.
A blinking Green light when Wi-Fi is enabled.
When both Bluetooth and Wi-Fi are enabled, their lights will blink alternately.
Listen to phone calls.
This LED shows the following:
A solid Amber light when the battery is charging; a solid Green light when the buttery is
fully charged.
A blinking Green light when the device is connected to CDMA network
Press to open Internet Explorer Mobile.
This is a QWERTY-style keyboard just like the computer keyboard. Slide the touch-screen
panel to the left to reveal the keyboard.
Tap the screen with the stylus to write, draw, or make a selection.
Press to execute the command shown on screen above the button.
Press to answer an incoming call or go to the phone dialer screen.
Press to open the Start menu.
Press this multi-directional control up, down, left, or right to move through menus and
program instructions; carry out the selection by pressing the center of this control.
Press to confirm your data entries, or to exit the program in use.
Press to end a call or to return to the Today screen.
5
