- Page 1 User Manual SC51T PTN Compact Scaler Switcher All Rights Reserved Version: SC51T (with PoC)_2014V1.5 www.PTN-electronics.com...
-
Page 2: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. PTN Electronics Limited www.PTN-electronics.com... - Page 3 Please refer to the dealers for the latest details. This manual is copyright PTN Electronics Limited. All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited.
-
Page 4: Table Of Contents
4.4.1 Installation/uninstallation of RS232 Control Software ......14 4.4.2 Basic Settings ..................14 4.4.3 RS232 Communication Commands ............16 4.4.4 Control SC51T or 3rd Party Device from Local ........23 4.4.5 Control SC51T from Local or Remote............ 24 4.5 Operations in OSD Menu................. 25 PTN Electronics Limited www.PTN-electronics.com... - Page 5 4.5.3 Sound ....................27 4.5.4 Setup ..................... 28 4.6 Instructions of VGA Converting Cable ............. 29 5. Specification ......................30 6. Panel Drawing ......................32 7. Troubleshooting & Maintenance ................32 8. After-sales Service ....................34 PTN Electronics Limited www.PTN-electronics.com...
-
Page 6: Introduction
1. Introduction 1.1 Introduction to SC51T SC51T is a compact mini scaler switcher with 5 video inputs (3 HDMI, 2 VGA) and 6 audio inputs (3 HDMI audio & 2 VGA audio: switched following the video; 1 MIC audio input). As the VGA input supports VGA, YPbPr and C-video, so the scaler switcher is compliant with multiple video signals. -
Page 7: Product Appearance
Please confirm if the product and the accessories are all included, if not, please contact with the dealers. 2. Product Appearance 2.1 SC51T Front Panel ① Power indicator Illuminate red when power on, turn green in standby mode. ② LCD screen Show real-time system working status ③... - Page 8 ⑩ MIC- Used as MIC volume down button. Used as direction button MOVE DOWN in menus. Pictures shown in this manual are for reference only, different model and Note: specifications are subject to real product. PTN Electronics Limited www.PTN-electronics.com...
-
Page 9: Sc51T Rear Panel
Audio output port, the audio comes from the input audio corresponding to the selected video source and mixed with MIC audio. ③ IR OUT 5 in total, connect with IR emitters to control local source devices or SC51T from remote, switched along with corresponding video source. ④ IR IN Connects with IR receiver (with carrier wave only), to receive IR signal send by the IR remote or remote controller of other input/output device. -
Page 10: System Connection
2) All of the power switches, plugs, sockets and power cords should be insulated and safe. 3) All devices should be connected before power on. 3.2 System Diagram TPHD402PR Rs232 PTN control panel Projector HDTV Laptop DV Camera PTN Electronics Limited... -
Page 11: Connection Procedure
The audio of HDMI can be embedded or external by sending the right command. Step3. Connect a HDMI display device to HDMI output port of SC51T with HDMI cable. Step4. Connect TPHD402PR to HDBaseT output port of SC51T with twisted pair. -
Page 12: Line Input
” connect to ground, and “+” connects to signal. 2) Balanced connection: “+” connects to positive, “-” connects to negative and “ ” connects to ground. LINE input LINE input has a low frequency characteristics, and wide frequency response. PTN Electronics Limited www.PTN-electronics.com... -
Page 13: Application
2) Balanced connection: “+” connects to positive, “-” connects to negative and “ ” connects to ground. 3.5 Application SC51T has a good application in various occasions, such as computer realm, monitoring, conference room, big screen displaying, television education, command & control center and smart home etc. 4. System Operations 4.1 Operations of Front Panel Buttons... -
Page 14: Switching Operations
Once rebooted, SC51T will automatically enter auto-switching mode, and then detect all inputs and memorize their connection status for future rebooting using. If the last displayed signal is still available, SC51T will output the signal. If not, there will be no signal on output devices. -
Page 15: Volume Adjusting
Connect INPUT 3 with a source device, and then it will choose INPUT 3 to output. Remove the signal of INPUT 3, SC51T will detect from INPUT 1 to INPUT 5. And when it detects that input 2 is available, it will choose INPUT 2 to output. -
Page 16: Operations Of Ir
4.2 Operations of IR 4.2.1 IR Remote As IR signal can be transmitted bi-directionally between SC51T and TPHD402PR, it is able to use the IR remote at the far-end to control SC51T or HDMI source devices (via CEC function buttons). ① Standby button Enter/ exit standby mode ②... -
Page 17: Ir Operations
1) Control far-end device from local Control SC51T or far-end display device from local through corresponding IR remote. 2) Control local device from remote Control SC51T or local device from local through corresponding IR remote. -
Page 18: Operations Of Cec Function
HDMI INPUT ports 1~3 support CEC, if the connected source devices also support CEC and their CEC are on, users can control the source device via the IR remote of SC51T. The working status related to CEC and STANDBY is showed as below:... -
Page 19: Operations Of Rs232 Control
As RS232 can be transmitted bi-directionally between SC51T and TPHD402PR, so it is able to control a third party RS232 device from local or control SC51T from remote. When to control a third party RS232 device, the baud rate of this device should be 2400, 4800, 9600, 19200, 38400, 57600 or 115200. - Page 20 Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. PTN Electronics Limited www.PTN-electronics.com...
-
Page 21: Rs232 Communication Commands
LINE Unmute 50721% Unmute LINE audio & MIC audio MIC Unmute 50722% Mute MIC audio MIC Mute 50723% Unmute MIC audio MIC Unmute 50694% Enable Mic precedence Mic precedence: enable 50695% Disable Mic precedence Mic precedence: disable PTN Electronics Limited www.PTN-electronics.com... - Page 22 Resolution: 1024x768 Change the resolution to 1280X720 50627% Resolution: 1280x720 720P Change the resolution to 1280X800 50628% Resolution: 1280x800 WXGA Change the resolution to 1920X1080 Resolution: 1920x1080 50629% 1080P Change the resolution to1920X1200 50620% Resolution: 1920x1200 WUXGA PTN Electronics Limited www.PTN-electronics.com...
- Page 23 Enable MIC Volume Icon display Volume Icon: enable Disable MIC Volume Icon display Volume Icon: disable 50647% 50648% Enable HDMI embedded audio output Embedded Audio Output: enable Disable HDMI embedded audio output Embedded Audio Output: disable 50649% PTN Electronics Limited www.PTN-electronics.com...
- Page 24 EDID: initial 50768% Bypass EDID data from output to input EDID: bypass Upload custom EDID data to the Please send edid data within 10 50769% switcher secs! EDID: initial 50770% Inquire EDID status EDID: bypass EDID: user PTN Electronics Limited www.PTN-electronics.com...
- Page 25 MIC Volume: xx (xx=0~66) Input: xx (xx= HDMI1/ HDMI2/ 50631% Check the input source HDMI3/ VGA1/ VGA2/ YPbPr1/ YPbPr2/ AV1/ AV2) Resolution: xx (xx=1920×1200/ 1920×1080/ 1600×1200/ 1360 Check the output resolution 50632% ×768/ 1280×800/ 1280×720/ 1024×768 PTN Electronics Limited www.PTN-electronics.com...
- Page 26 Check whether the MIC audio is mute 50752% MIC Mute/Unmute or not 50753% Check the freeze status Freeze: enable/disable 50754% Check the panel locked status Front Panel Lock/UnLock Display statues including MIC, LINE Line Volume:XX 50783% audio, Resolution, Output Audio Mic Volume:XX PTN Electronics Limited www.PTN-electronics.com...
- Page 27 CEC cmd: menu 50904% Retreat CEC cmd: rev 50905% Forward CEC cmd: fwd CEC cmd: up 50906% 50907% Down CEC cmd: down 50908% Left CEC cmd: left Right CEC cmd: right 50909% 50910% Conform command CEC cmd: select PTN Electronics Limited www.PTN-electronics.com...
-
Page 28: Control Sc51T Or 3Rd Party Device From Local
Firstly, connect the RS232 port of SC51T to RS232 port of PC. Secondly, send command 50787% (serial control mode 1, factory default) via RS232 communication software. Lastly, send the right command of SC51T or other remote RS232 device connected in present system. Connect as below: PTN Electronics Limited... -
Page 29: Control Sc51T From Local Or Remote
4.4.5 Control SC51T from Local or Remote Control SC51T from local Firstly, connect the RS232 port of SC51T to RS232 port of PC. Secondly, send command 50788% via RS232 communication software. Lastly, send the right command to control SC51T. Connect as below: Control SC51T from local ... -
Page 30: Operations In Osd Menu
Control SC51T from remote 4.5 Operations in OSD Menu SC51T provides a powerful OSD operation menu, contains 4 parts: optional settings, image settings, audio settings and system setting etc. Press MENU button on front panel (or MENU button on IR remote/send command 50616%) to enter in OSD menu, so it is able to do some settings through the OSD menu. - Page 31 HDMI3 Audio Select: switch between Embedded and Line to choose the desired audio output port for HDMI3. Software Update (USB): Insert the USB flash disk with updating file to USB port of SC51T, to update the software through this menu. PTN Electronics Limited www.PTN-electronics.com...
-
Page 32: Picture
Screen: (not for HDMI source): Includes Auto Adjust, Horizontal, Vertical, Size, and Phase. Color Range (not for VGA format): 0~255, use ENTER button to select the color range. 4.5.3 Sound Including Sound Mode, Surround Sound and EQ Please check the picture below: PTN Electronics Limited www.PTN-electronics.com... -
Page 33: Setup
Surround Sound: Includes Off, Surround and SRS Trusurround XT. EQ: To adjust the sound balance. 4.5.4 Setup Including OSD Language, Restore Factory Default, Blending, HDMI CEC, OSD Duration and version inquiry PTN Electronics Limited www.PTN-electronics.com... -
Page 34: Instructions Of Vga Converting Cable
VERSION: Displays software version 4.6 Instructions of VGA Converting Cable As VGA source supports YPbPr and C-video source, SC51T provides with 2 VGA converting cables to compliant with these signals. When need to select these signals as input source, please switch to channel INPUT 4 (or INPUT 5), and then set the signal type in OSD. -
Page 35: Specification
1 IR IN Output 5 IR OUT Input Output 3.5mm mini jack 3.5mm mini jack Connector Connector Video General HDMI:4.95Gbps(1.65Gb 1920x1200, ps per color) 1920x1080, Resolution Bandwidth C-Video:150MHz 1600x1200, 1360x768, YPbPr: 170MHz 1280x800, 1280x720, VGA: 375MHz PTN Electronics Limited www.PTN-electronics.com... - Page 36 Temperature -10 ~ +40℃ Humidity 10% ~ 90% 8W, supply power to SC51T and Power Power DC12V ± 0.5V TPHD402PR separately Supply Consumption 16W, SC51T supplies power to TPHD402PR Dimension 220x 44x 148mm Weight 0.65Kg (W*H*D) PTN Electronics Limited www.PTN-electronics.com...
-
Page 37: Panel Drawing
Check with oscilloscope or switching output end multimeter if there is any signal at the input/ output end. Fail or loose connection Make sure the connection is good The switcher is broken Send it to authorized dealer for repairing. PTN Electronics Limited www.PTN-electronics.com... - Page 38 Send it to authorized by RS232 / IR remote / been broken. dealer for repairing. front panel buttons If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. PTN Electronics Limited www.PTN-electronics.com...
-
Page 39: After-Sales Service
Compact Scaler Switcher (with PoC) 8. After-sales Service If there appear some problems when running SC51T, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: PTN warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 40 PTN Electronics Limited Tel: +86-755-2846 1819 Fax: +86-755-8471 7796 Email: info@PTN-electronics.com Website: www.PTN-electronics.com...
